12~24W EF20-2outputs 5/5V.12/12V flyback transformer,used in auxiliary power transformer,DC-DC converter, drive transformers,digital cameras,switch-mode power supplies.
brand:
MCTitem no.:
12~24W EF20 Flyback Transformershipping port:
Shanghai PortPower flyback transformer often used in switching power supplies, chargers, alarm system, TV/CRT monitor displays, UPS, VCD/DVD players,audio/visual equipment, OA machines and inverter. We also produce and design other series power flyback transformers, such as 15~35W EF25 flyback transformer , 30~60W ERL28 flyback transformer , 70~140W ETD39 flyback transformer, etc, larger core with high power transformers.
Hefei Mycoil Technology Co.,LTD is ISO9001:2008 certification factory, we located in Anhui province(near to Shanghai). We have about 200 workers working at the factory, 5 main engineers and about 10 works as QC, 8 sets Automatic CNC Winding Machines, 50 sets semi-auto CNC Winding Machines.
Quick Details
|
Part No: 12~24W EF20 Flyback Transformer |
|
Brand name: MCT |
|
The operating frequency: 20kHz-500KHz |
|
Custom made: Available |
|
Working temperature: -40 ℃ to + 125 ℃ |
|
Logo: Can be customized |
|
Storage temperature: -25 ℃ to + 85 ℃ |
|
Packing: Carton,can custom |
|
Storage humidity: 30 to 95% |
|
Certification: ISO9001,ROHS,CE |
|
Power range: 0.5W~24W |
|
OEM: Available |
|
Shape type: horizontal, vertical |
|
Shipping: Air, Ship, etc |
|
Lead time: 25 days after payment |
|
MOQ: Any quantity |
Part Information
Product Name: 12~24W EF20 Power Flyback Transformer For Switching Power Supply
SIZE EF20- 2 OUTPUTS:5/5V OR 12/12v flyback transformer, our PN includes MCTEF2001, MCTEF2002.
SIZE E25-3 OUTPUTS:5+ 12/12v or 24v flyback transformer, our PN is MCTEF2003.
Applications: Single-phase Transformer, DC-DC converter, Driving transformer, Power transformer, Digital camera, hand-held switching mode power charger.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Lily Yu
