EFD25 pcb mounting transformer. 6+6 pin single slot SDM bobbin. Bobbin Size=31.5mmX25.0mmX12.6mm. Pin pitch=4.0mm. We have bobbin tooling now, samples are available.
brand:
MCTitem no.:
MCT-EFD2526(H6+6P)shipping port:
Shanghaipayment:
T/T in advanceEFD25 SMD horizontal bobbin, sinlge slot wire bobbin, big discount and fast delivery time.
Quick Details
|
Part No: MCT-EFD2526 |
Brand Name: MCT |
|
Material: PM-9630 |
Color: Black |
|
UL REC: 94V-0 |
Logo: Can be customized |
|
Lead Time: 20 days after payment |
Custom Made: Available |
|
Certification: ISO9001,ROHS,CE |
Packing: Carton, accept customize |
|
OEM: Available |
MOQ: Any quantity |
Part Information
Product Name: EFD25 High Frequency Power Transformer Bobbin
Product Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: switching power suppies,converters,comsumer electronics,UPS,ect.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: By air, By ship, etc.
Product Specification
FAQ?
1. What's your lead time for mass production?
5-20 working days for production.
2.Do you provide core samples?
Yes, we can provide matched cores for testing.
3.Do you accept customized and OEM service?
Yes, we can help customers to finish design and accept OEM service.
4.What kind of payment method do you accept?
We accept T/T, PayPal.
5.How about your warranty for prodcts?
We guarantee 5 years for our items.
For more details, welcome to contact us.
Email: sales003@mycoiltech.com
Skype: live:sales003_125
Contact: Miss Lily
