brand:
MCTitem no.:
UU Series Ferrite Coreshipping port:
Shanghai
China electronic components manufacture Hefei Mycoil Technology Co., LTD. We are skilled at producing and designing electronic transformers, filter inductors, relays, magnetic cores and other electronic components. All magnetic cores design meets the UL certification.
Quick Details
|
Part Number: UU Series Ferrite Core |
Brand Name: MCT |
|
Material: Mn-Zn/Ni-Zn ferrite core |
Logo: Can be customized |
|
Type: Power core/ High permeability core |
OEM: Available |
|
Features: switching power supply, transformers,choke coils |
MOQ: Any quantity |
|
Packing: Carton,can be customized |
Custom Made: Available |
|
Lead Time: 25 days after payment |
Certification: ISO9001,ROHS,CE |
Part Information
Product Name: High Frequency and Low-loss Big UU Series Ferrite Core
Products Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: Filter common mode transformers. Color TV sets. Inverter welding machine, Plating Power Supply. Computers, monitors and other electronic equipment.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: By air, By ship, etc.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Product Details
UU Series Ferrite Core
|
TYPE |
Dimension:mm |
Weight: g |
|||||
|
A |
B |
C |
D |
E |
F |
||
|
UU64 |
65.0±1.5 |
63.5±1.0 |
40.0±0.5 |
20.0±0.5 |
24.4min |
43.0±0.7 |
1130 |
|
UU66 |
66.0±1.5 |
55.0±1.0 |
39.6±0.6 |
19.5±0.5 |
25.0min |
36.5±1.0 |
960 |
|
UU80 |
80.0±3.0 |
85.0±1.0 |
40.0±1.0 |
20.0±0.5 |
40.0min |
65.0±1.0 |
1600 |
|
UU93 |
93.0±2.0 |
76.0±1.0 |
30.0±0.6 |
28.0±0.6 |
34.6min |
48.0±1.0 |
1440 |
|
UU101 |
101.0±2.5 |
57.0±1.0 |
25.4±0.8 |
25.4±0.6 |
49.5min |
31.95±1.0 |
1000 |
|
UU120 |
120.0±3.0 |
117.5±1.5 |
40.0±0.8 |
30.0±0.6 |
59.0min |
87.5±1.5 |
3300 |
|
UU126 |
126.0±4.0 |
91.0±1.0 |
20.0±0.8 |
28.0±0.6 |
68.0min |
63.0±2.0 |
1360 |
|
TYPE |
Effective parameter |
AL（nH/N2）（AL±25%） |
||||||
|
C1 (mm-1) |
Ae (mm2) |
Le (mm) |
Ve (mm3) |
MP4 |
M5P |
M7P |
M10P |
|
|
UU64 |
0.355 |
806 |
286 |
230000 |
7000 |
|
|
|
|
UU66 |
0.343 |
759 |
260 |
197000 |
6800 |
|
|
|
|
UU80 |
0.543 |
801 |
435 |
348000 |
5500min |
|
|
|
|
UU93 |
0.409 |
860 |
351 |
302000 |
5500 |
|
|
|
|
UU101 |
0.484 |
637 |
309 |
197000 |
5060min |
|
|
|
|
UU120 |
0.470 |
1200 |
564 |
677000 |
5200 |
|
|
|
|
UU126 |
0.850 |
560 |
480 |
268800 |
2679 |
|
|
|
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Lily Yu
