Customized EMI ferrite core noise filter, which has the ability to receive an electrostatic pulse absorbing EMI absorption ring, the electronic equipment to achieve electromagnetic compatibility (EMI / EMC ) and the corresponding international standard electrostatic discharge.
brand:
MCTitem no.:
EMI Ferrite Coreshipping port:
ShanghaiEMI absorption ring / bead multi-strand cable on the EMI suppression, including noise and spike noise on the power line, it also has the ability to receive an electrostatic pulse absorbing EMI absorption ring, the electronic equipment to achieve electromagnetic compatibility (EMI / EMC ) and the corresponding international standard electrostatic discharge, the use may be more than one core cable or a bundle of multi-strand cables through therein. Wear once to strengthen its effectiveness. Typically impedance value and 25MHz to measure the absorption characteristics of the core.
Quick Details
|
Part No: EMI Ferrite Core |
Brand name: MCT |
|
EMI suppression |
Custom made: Available |
|
Samples time：5-7 days |
Logo: Can be customized |
|
Packing: Carton, can custom |
Shipping: Air, Ship, etc |
|
Lead time: 25 days after payment |
MOQ: Any quantity |
|
Certification: ISO9001,ROHS,CE |
OEM: Available |
Part Information
Product Name: EMI Soft Ferrite Core for EMI Suppression
Applications: Data communication, Industrial equipment power supply, Medical equipment, Testing equipment, Computers, tele-communication equipment and consumer's electronics,
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages: Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Product Details
|
MCT PN |
FIG |
DIMENSION:mm |
Impendence(Ω)min |
|||||
|
A |
B |
C |
D |
E |
25MHz |
100MHz |
||
|
MCT-RC35B |
|
13±1 |
11.8±1 |
5±0.8 |
25.5±1 |
2.5±1 |
70 |
170 |
|
MCT-RC50 |
|
16.5±1 |
/ |
5±0.8 |
29.5±1 |
/ |
65 |
160 |
|
MCT-RC70 |
|
15.5±1 |
14±1 |
7±0.8 |
18±1 |
22±1 |
40 |
110 |
|
MCT-RC70B |
|
16.5±1 |
15±1 |
7±0.8 |
30±1 |
2.5±1 |
75 |
170 |
|
MCT-RC90A |
|
20±1 |
/ |
9±0.8 |
31.5±1 |
35.5±1 |
75 |
205 |
|
MCT-RC90B |
|
19.5±1 |
18±1 |
9±0.8 |
35±1 |
5.5±1 |
80 |
200 |
|
MCT-RC130B |
|
30±1 |
/ |
13±0.8 |
34±1 |
39±1 |
110 |
240 |
|
MCT-RC1330B |
|
23.5±1 |
22.2±1 |
13.5±0.8 |
36±1 |
10.5±1 |
65 |
165 |
|
MCT-NF65 |
|
17.5±1 |
19.5±1 |
6.5±0.8 |
32.5±1 |
/ |
120 |
315 |
|
MCT-NF100 |
|
22±1 |
23.5±1 |
10±0.8 |
33±1 |
/ |
70 |
235 |
|
MCT-NF130 |
|
29±1 |
30±1 |
13±0.8 |
32±1 |
/ |
120 |
200 |
|
MCT-RC16-13-8 |
|
19.5±1 |
23±1 |
8±0.8 |
17±1 |
23±1 |
40 |
85 |
|
MCT-RC16-16-8 |
|
19.5±1 |
23±1 |
8±0.8 |
19.5±1 |
/ |
60 |
140 |
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
QQ: 2783136957
Contact: Miss Lily Yu
EFD25 Flyback Transformer Horizontal Frame
EFD25 5+5 pins DIP bobbin, single slot EFD25 coil former, 5 bobbin. Row distance=26.50mm. Pin pitch=5.0mm. Bobbin Size=30.0mmX25.0mmX15.4mm. EFD25 high frequency transformers widely used in electrical equipment, DC converters, medical equipment, communication equipment, power supplies, computer SMPS, vehicle electronic equipment.
Common Mode Filter Inductor Horizontal bobbin, UU9.8 Bobbin
2+2 Pins DIP Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=7mm Parallel Distance=8mm Size=12.6mmX10.6mmX11.8mm
EFD20 SMD Transformer Horizontal Bobbin
EFD20 electronic transformer. SMD EFD20 8+8 pin horizontal coil bobbin for power transformer. Bobbin size=28.65X24.0X10.8mm. Pin pitch=3.0mm. PM9630 material EFD20 transformer bobbin. Customized design and OEM service are accepted.
EE13 Switching Power Supply Transformer Bobbin
EE13 charger transformer. Horizontal 4+4 pins EE13 bobbin. Phenolic material EE13 coil bobbin. Parallel Distance=12.5mm. Pin pitch=3.8mm. Coil former Size=18.0mmX14.0mmX14.85mm. We produce and design various EE13 electronic transformers, mainly used for power supplies, lighting, UPS, computer equipment, telecom communication systems, welding machines and other industries.
Main Power Transformer ETD44 Bobbin Cover
ETD44 case for bobbin, SMPS transformer ETD44 core. Cover Size=50.3mmX50.0mmX30.0mm. ETD44 bobbin cover with phenolic material. We manufacture SMPS transformers, welcome OEM and custom designed transformer.
RM4 High Frequency Power Transformer Clips
High voltage transformer RM4 bobbin clip. Switching power transformer design. RM4 electronic transformer widely used in home appliances, smart home, lighting, SMPS, digital products, etc. welcome for customized wounded components.
EE25 Horizontal 5+5 Pin Transformer Bobbin Double Slots
EE25 power transformer bobbin pin 5+5. EE25 horizontal type transformer bobbin. Bobbin Size=25.mmX19.1mmX21.7mm. Pin Pitch=5mm. Parallel Distance=15.1mm. EE25 PBT transformer bobbin. DIP transformer bobbin. UL REC:94V-0.
EF16 Vertical Bobbin Dip Bobbin Phenolic Material With 3+3 Pins
3+3 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.75mm Parallel Distance=11.5mm Size=16.6mmX12.8mmX18.2mm
RM14 Switching Power Transformer Frame
6+6 pin vertical RM14 coil former. We supply MP4/MP44/MP95 material soft ferrite cores. Parallel Distance=25.2mm. Bobbin Size=42.0mmX28.5mmX21.8mm. RM14 bobbin mainly used for communication transformer, high frequency Transformer, main power transformer and SMPS transformer.
ETD29 Horizontal Bobbin With Clips For Transformer
Stainless steel ETD29 transformer clips. Silver transformer iron clamps. Clips Size=34.75mmX8mmX8.5mm. Clips Material: stainless steel material clips. UL REC:94V-0. Accept custom design.
ET28 Four Slots Transformer Bobbin For Inductor Base
ET28 no pins transformer bobbin. ET28 vertical/horizontal type coil former. ET/UT28phenolic material bobbin. We can make tooling to meet different dimensions. Bobbin Size=21.6mmX16mmX6.9mm. UL REC: 94V-0
24VA UI39 Type Electronic Encapsulated Transformer for Power Supply
Vacuum UI39 encapsulated transformer output power up to 30.0 VA. Vacuum-encapsulated, bobbin type with dual chamber Windings. Excellent temperature fluctuation resistance properties. High electrical safety and long service-life features. Self-extinguishing cast housing and sealing material. RoHS Directive-compliant.
