ET28 horizontal/vertical common mode chokes are applied to supply and return pairs of conductors, are ideal for EMI filtering of signal and power lines.
brand:
MCTitem no.:
ET28 Series Common Mode Chokeshipping port:
Shanghai Port
ET28 common mode chokes with inductance range 1.8mH~35.0mH are suitable for lighting application, switching mode power suppliers, AC/DC converters and other application. ET28 series common mode choke has small size and large inductance, low cost and high reliability, excellent attenuation characteristics in low frequency, so its convenient to inserted into PCB.
Quick Details
Part No: ET28 Series Common Mode Choke |
|
Brand name: MCT |
Working frequency range:20kHz-500kHz |
|
Custom made: Available |
Operating temperature range: -40℃~+125℃ |
|
Logo: Can be customized |
Storage temperature: +85℃~-25℃ |
|
Packing: Carton,can custom |
Storage humidity: 30 to 95% |
|
Certification: ISO9001,ROHS,CE |
Inductance range: 1.8mH~35mH |
|
OEM: Available |
Rated current: 1.0~4.0 50Hz(A) |
|
Shipping: Air, Ship, etc |
DC resistance: 0.05Ω~0.8Ω @25°C |
|
MOQ: Any quantity |
Shape type: horizontal, vertical Weight≈30g |
|
Lead time: 25 days after payment |
Part Information
Product Name: ET28 Common Mode Choke For EMI Suppression And Power EMI Noise Filter
Applications: Switching power supply, Lighting equipment, Data transmission, Wind generators, Frequency Converter.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
