ERL28 flyback transformer for switching power supply, kinds of high-frequency circuit. It has small volume,light weight,nice appearance.It palys important role in oscillating and separating.
brand:
MCTitem no.:
30~60W ERL28 Flyback Transformershipping port:
ShanghaiERL28 single phase high frequency flyback transformer has many advantages, such as moisture, high pressure anti - interference ability, size is small, convenient to install. It can change with the temperature changes, when the temperature rises, the efficiency is also higher.
We use high - quality raw materials to make sure power flyback transformer will have long life, ERL28 power transformer has excellent performance and environmental quality. If you need different cores, you can choose PC40 / 44/95, we can design as your requirements. We have our own quality control department, strict quality control links, all products we produced are double tested, also with advanced manufacturing process.
Quick Details
Part No: 30~60W ERL28 Flyback Transformer |
|
Brand name: MCT |
The operating frequency: 20kHz-500KHz |
|
Custom made: Available |
Working temperature: -40 ℃ to + 125 ℃ |
|
Logo: Can be customized |
Storage temperature: -25 ℃ to + 85 ℃ |
|
Packing: Carton,can custom |
Storage humidity: 30 to 95% |
|
Certification: ISO9001,ROHS,CE |
Power range: 30W~150W |
|
OEM: Available |
Shape type: horizontal, vertical |
|
Shipping: Air, Ship, etc |
Lead time: 25 days after payment |
|
MOQ: Any quantity |
Part Information
Product Name: ERL28 High Frequency Power Supply Flyback Transformer
Applications: Single-phase Transformer, DC-DC converter, LED Driving transformer, Power transformer, Digital camera, hand-held switching mode power charger.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Product Specification
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Lily Yu
