BP40 vertical transformer bobbin. 5+5 Pins Bobbin.
Parallel Distance=24mm. Pin Pitch=5mm. UL REC:94V-0.
Bobbin Size=28.3mmX24mmX8.1mm. BP40 phenolic bobbin.
brand:
MCTitem no.:
MCT-BP4001(V5+5P)shipping port:
ShanghaiWe are professional electronic components manufacturer, specialized in producing and designing various high frequency electronic transformer bobbins. Such as EE, ER/EC/ERL, EPC, EFD, PQ, ETD, EF, RM, PQ, etc. If you have any requests, welcome to contact us.
Quick Details
|
Part Number: MCT-BP4001(V5+5P) |
Brand Name: MCT |
|
Material: Phenolic |
Color: Black |
|
UL REC: 94V-0 |
Logo: Can be customized |
|
Lead Time: 20 days after payment |
Custom Made: Available |
|
Certification: ISO9001,ROHS,CE |
Packing: Carton, accept customize |
|
OEM: Available |
MOQ: Any quantity |
Part Information
Product Name: 5+5 Pins BP Transformer Bobbin For Inductors Vertical Type Bobbin
Product Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: switching power supply transformers, toroidal inductors, choke coils, high frequency transformers, filters.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: By air, By ship, etc.
Advantages: Professional transformer winding bobbin factory, complete specifications.
Our Factory is made up of 500 people, huge output can be finished every day.
All materials are environmental protected. We accept custom made and design service.
Any request, please contact us, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
Product Specification
EE85/26 Soft Magnet Ferrite Core Vertical Bobbin
Ferrite EE85 transformer bobbin. Bobbin Size=54.24mmX53.20mmX64.50mm. Pin Pitch=5.5mm, Parallel distance=46.7mm. We are China transformer bobbin factory, we have various series bobbins tooling, for special size bobbin, we can make new tooling to meet reuirement.
EF20 Horizontal Bobbin 5+5 Pins For Ferrite Core
EF20 5+5 pins horizontal bobbin. Single slot EF20 transformer bobbin. Bobbin Size=21mmX20mmX15.7mm. Parallel Distance=15.2mm. Pin pitch=4mm. Phenolic material EF20 bobbin. DIP transformer bobbin.
Common Mode Choke Inductor Base With 2+2P T375HF Material Base
2+2 Pins Dip Base,LCP Material,UL REC:94V-0 Inductor base size=15mmX10mmX10mm
Transformer Bobbin EF25 Vertical 4+4 Pins Bobbin
EF25 vertical bobbin 4+4 pins. EF25 single slot transformer bobbin. Bobbin Size=37mmX18.5mmX20.4mm. Parallel Distance=17.3mm. Pin pitch=4.5mm. Nylon and PET material bobbin. DIP transformer bobbin.
Vertical Encapsulated Common Mode Choke Coils with High Frequency
Vertical encapsulated common mode choke has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.It is excellent EMI suppressor.
EF20 Power Transformer Horizontal Bobbin Pin 4+4
EF20 soft ferrite core. 4+4 pins EF20 bobbin. Bobbin Size=21.0mmX20.8mmX18.4mm. Pin pitch=5.0mm. Parallel Distance=15.0mm. EF20 horizontal coil bobbin. EF20 transformer DIP bobbin. PA66 material transformer bobbin.
EF25 Power Charger Transformer Horizontal Bobbin
EF25 SMPS transformer. 5+5 pin horizontal bobbin EF25. Bobbin Size=24.0mmX23.8mmX21.5mm. Pin pitch=2.5mm. Parallel Distance=20.5mm. PC40 material EF25 ferrite core. DIP type transformer bobbin.
EE35 Horizontal Flyback Transformer
Single slot EE35 bobbin. Horizontal EE35 26 pins coil former. Parallel distance=27.8mm. Pin pitch1=2.5mm.Pin pitch2=5.0mm. EE35 Bobbin Size=42.8mmX31.0mmX29.0mm. DIP pin transformer bobbin. EE35 PBT material bobbin.
Double Slots UU16 Horizontal Transformer Bobbin With 2+2 Pins
2+2 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=10mm Parallel Distance=13mm Size=18.5mmX17mmX20.2mm
EL19 High Voltage Transformer 4+6 Pins
EEL19 ferrite cores. 4+6 pins vertical bobbin for EL19 transformer. Parallel distance=12.0mm. Pin Pitch1=2.8mm. Pin Pitch2=3.45mm. Dip bobbin. Bobbin Size=17.8mmX16.3mmX20.9mm. Manufacture final EL19 electronic transformer.
ETD39 High Flyback Transformer Bobbin 18+18 Pins
18+18 pins ETD39 vertical bobbin, ETD39 through hole transformer frame. Parallel Distance=25.3mm. Bobbin Size=47.7mmX31.6mmX29.6mm. Pin pitch=2.5mm, ETD39 electronic transformer has high magnetic flux and low loss magnetic materials, mainly used in PCB circuits, computers, monitors, printer, scanner, duplicator, mobile adapters, other equipment and instruments.
EE25 Horizontal 5+5 Pin Single Slot Transformer Bobbin
Horizontal EE25 bobbin 5+5 pin. Single slot EE25 transformer bobbin. EE25 PET transformer bobbin. Parallel Distance=15.2mm. Pin Pitch=5mm. Size=25.7mmX19.1mmX21.7mm. DIP transformer bobbin. UL REC:94V-0.
