  • 8+8 pin EE65 transformer Bobbin
    EE65 High Power Transformer Horizontal Frame

    EE65 single phase transformer. Horizontal EE65 bobbin 8+8 pins. Bobbin Size=51.5mmX43.7mmX54.8mm. Parallel Distance=44.5mm. Pin pitch=5.0mm. Good quality EE65 encapsulated transformer, singled packed with carton.

  • 6+6 Pins EF30 Vertical Bobbin
    EF30 Power Transformer Vertical Bobbin 6+6 Pin

    EF30 rectifier transformer. 6+6 pins vertical EF30 coil former. Bobbin Size=35.3mmX19.0mmX34.8mm. Pin pitch=5.08mm. Parallel Distance=15.24mm. SMPS transformer has small size, high power and low cost, we design and manufacture high frequency transformer.

  • PQ50 Electronic Transformer Bobbin
    PQ50 Vertical High Frequency Transformer 6+6 Pin Bobbin

    6+6 pins PQ50 coil former. PQ phenolic material bobbin. Bobbin Seize=51.5mmX50.8mmX51.5mm. Parallel Distance=45.65mm. PQ50 Vertical bobbin for power transformer. Make bobbin tooling.

  • Electronic Impedance Matching and Maximum Power Transformers
    High Frequency Matching Transformer for Switching Power Supplies

    High Frequency Electronic Matching Transformers are intended for measuring electric signal voltages or currents which contain useful data. They match the signal source with the load ensuring the minimum signal distortion. Along with active components (such as transistors and lamps) they are included into devices amplifying electric oscillations that work within a wide frequency band.

High Frequency flyback transformer(FBT), also called aline output transformer(LOPT), it's the simplest and most commonly used topology in switch mode power supply forsmall power supply applications. Switch mode power supply is higher efficiency because of low power losses.

Flyback Transformers
