CMC Choke for Converter Base 3+3 Pins

EMI filter for AC&DC line Base 3+3 Pins.The base of the inductor needs to isolate the winding from the external circuit to prevent leakage short circuit. The PHENOLIC material has excellent insulation properties, with a volume resistivity of 10¹⁴-10¹⁶Ω · cm, a breakdown voltage resistance exceeding 15kV/mm, and stable performance under high temperature and high humidity conditions. It can ensure that the inductor operates at the rated voltage and is suitable for scenarios with high insulation requirements such as power adapters.

product origin:
China
brand:
MCT
item no.:
MCT-BASE96

contact now

product description

The High power converter inductor base.The base of the inductor should fix the windings and magnetic cores and resist shock and vibration. The PHENOLIC material (glass fiber reinforced type) features high mechanical strength, with a bending strength of 80-120 mpa and a compressive strength exceeding 150MPa. It has a low coefficient of linear expansion, is less prone to deformation under temperature changes, and can prevent inductance value drift caused by component displacement, ensuring consistent performance.

Production Specification

EMI filter for AC&DC line
