EFD20 horizontal transformer bobbin. 6+6 pins EFD20 bobbin. Pin pitch=2.7mm. Pin pitch2=4.6mm. Parallel distance=13.64mm. Phenolic material coil bobbin. Bobbin Size=17.8mmX16.9mmX9mm. DIP bobbin. UL REC:94V-0.
brand:
MCTitem no.:
MCT-EFD2006(H6+6P)shipping port:
ShanghaiHot selling high efficiency and good performance EFD20 coil former, 6+6 pin horizontal EFD20 bobbin, we can provide samples for customer's testing, OEM service also acceptable.
Quick Details
|
Part No: MCT-EFD2006(H6+6P) |
Brand Name: MCT |
|
Material: Phenolic |
Color: Black |
|
UL REC: 94V-0 |
Logo: Can be customized |
|
Lead Time: 20 days after payment |
Custom Made: Available |
|
Certification: ISO9001,ROHS,CE |
Packing: Carton, accept customize |
|
OEM: Available |
MOQ: Any quantity |
Part Information
Product Name: EFD20 PCB Mounting Transformer Bobbin 6+6 Pins
Product Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: switching power supply transformers, toroidal inductors, choke coils, high frequency transformers, filters.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: By air, By ship, etc.
Advantages: Professional transformer winding bobbin factory, complete specifications.
Our Factory is made up of 500 people, huge output can be finished every day.
All materials are environmental protected. We accept custom made and design service.
Any request, please contact us, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
