EL19 vertical coil former. 4+6 pin transformer bobbin. Phenolic material transformer bobbin. Parallel distance=10.9mm. Pin Pitch1=3.5mm. Pin Pitch2=3.5mm. Dip bobbin. Bobbin Size=17.8mmX16.3mmX29.3mm. UL REC: 94V-0
brand:
MCTitem no.:
MCT-EL1904(V4+6P)shipping port:
ShanghaiWe are professional electronic components manufacturer, our main products are high frequency transformers, inductors, EMI filters, coil formers. All products samples are supported, OEM service are also welcome.
Quick Details
|
Part Number: MCT-EL1904(V4+6P) |
Brand Name: MCT |
|
Material: Phenolic |
Color: Beige |
|
UL REC: 94V-0 |
Logo: Can be customized |
|
Lead Time: 20 days after payment |
Custom Made: Available |
|
Certification: ISO9001,ROHS,CE |
Packing: Carton, accept customize |
|
OEM: Available |
MOQ: Any quantity |
Part Information
Product Name: EL19 4+6 Pin Transformer Bobbin Vertical Type Single Slot Coil Bobbin
Product Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: switching power supply transformers, toroidal inductors, choke coils, high frequency transformers, filters.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: By air, By ship, etc.
Advantages: Professional transformer winding bobbin factory, complete specifications.
Our Factory is made up of 500 people, huge output can be finished every day.
All materials are environmental protected. We accept custom made and design service.
Any request, please contact us, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
Product Specification
EL16 Horizontal Coil Former 6+6 Pins
EL16 ferrite transformer, 6+6 pins horizontal EL16 bobbin, through hole transformer bobbin. Parallel Distance=15.6mm.Bobbin Size=28.3mmx16.8mmx15.1mm. Pin Pitch1=5.4mm. Pin Pitch2=2.4mm. Phenolic material EL16 transformer frame, we make new bobbin tooling to meet special bobbin size requirement.
EL12 Phenoilic Transformer Bobbin
1+1 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=17.7mm Size=19.4mmX9.4mmX9.4mm
EL16 Vertical Transformer Bobbin Phenolic Material With 4+6 Pins
4+6 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.5mm Parallel Distance=12mm Size=17.8mmx16mmx26.6mm
EL16 Mn-Zn Ferrite Core Transformer Bobbin
4+6 pins vertical EL16 bobbin, high frequency EL16 bobbin. Bobbin Size=18mmx16.2mmx26.2mm. Pin Pitch=3.5mm. Parallel Distance=12mm. Phenolic material EL16 former. UL REC:94V-0
Dip Bobbin EL16 Vertical Transformer Bobbin With 4+6 Pins
4+6 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.5mm Parallel Distance=12.2mm Size=18mmx16.2mmx29.9mm
