We can design rod core inductor with ferrite rod core, single layer winding with or without shrink tube, terminal tinned copper wire or LITZ wire, high resonance frequency.
brand:
MCTitem no.:
MCT Φ3×20 Rod core inductorshipping port:
Shanghai PortHefei Mycoil Technology Co., LTD produce various series rod core inductors and design as your requirements, our high frequency chokes rod core inductors are widely used in switching power supply, power amplifiers, broadband filtering, notebook computer, digital electronic products, buck converter, LCD and other electronic equipments.
Quick Details
|
|
Brand Name: MCT |
|
|
Current Rating: @50Hz and 40℃ Ambient temperature |
|
Custom Made: Available |
|
Inductance Tolerance:±20% |
|
Logo: Can be customized |
|
Normal Inductance: Measure at 25℃ |
|
Packing: Carton,can custom |
|
Testing Current: 0.1mA |
|
Certification: ISO9001,ROHS,CE |
|
Testing frequency :L≤10uH:1MHz,10uH＜L≤1000uH:100KHz,L＞1000uH:10KHz |
|
OEM: Available |
|
Climate level: 40/125/56 |
|
Lead Time: 25 days after payment |
|
Terminal Tinned Copper Wire or LITZ Wire |
|
MOQ: Any quantity |
|
Ferrite Rod Core |
|
Shipping: Air, Ship, etc |
|
Single Layer Winding |
|
With or Without Shrink Tube |
|
Dimension Tolerance: Component:±0.5mm Terminal：±2.0mm |
|
High Resonance Frequency |
Part Information
Product Name: High Frequency Chokes With Ferrite Rod Core Inductor
Applications: switching power supply, power amplifiers, broadband filtering, digital electronic products.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Product Specification
High Frequency Chokes with Ferrite Rod Cores Φ3×20
IR in A
LR in uH
RDC-mΩ
ΦC-mm
MCT PN
1.0
27
70
0.40
MCT-LB-A01
2.0
12
25
0.60
MCT-LB-A02
3.0
7
15
0.75
MCT-LB-A03
4.0
5
10
0.85
MCT-LB-A04
We can supply these dimension Ferrite Rod Core.Please make your design with the following table:
|
Type |
Diameter:A |
Length:B |
|
Type |
Diameter |
Length |
|
|
R1.65×7 |
1.65±0.20 |
7±0.40 |
|
R6×10 |
6±0.30 |
10±0.40 |
|
|
R1.65×10 |
1.65±0.20 |
10±0.40 |
|
R6×12 |
6±0.30 |
12±0.40 |
|
|
R2×7 |
2±0.20 |
7±0.40 |
|
R6×15 |
6±0.30 |
15±0.40 |
|
|
R2×10 |
2±0.20 |
10±0.40 |
|
R6×20 |
6±0.30 |
20±0.40 |
|
|
R3×10 |
3±0.20 |
10±0.40 |
|
R6×22 |
6±0.30 |
22±0.50 |
|
|
R3×12 |
3±0.20 |
12±0.40 |
|
R6×22.5 |
6±0.30 |
22.5±0.50 |
|
|
R3×14 |
3±0.20 |
14±0.40 |
|
R6×25 |
6±0.30 |
25±0.50 |
|
|
R3×15 |
3±0.20 |
15±0.50 |
|
R6×30 |
6±0.30 |
30±0.50 |
|
|
R3×16 |
3±0.20 |
16±0.50 |
|
R6×45 |
6±0.30 |
45±0.50 |
|
|
R3×20 |
3±0.20 |
|
|
R6.2×26 |
6.2±0.30 |
26±0.50 |
|
|
R4×10 |
4±0.20 |
10±0.40 |
|
R7.94×7.94 |
7.94±0.30 |
7.94±0.40 |
|
|
R4×11 |
4±0.20 |
|
|
R8×18.5 |
8±0.40 |
18.5±0.50 |
|
|
R4×12 |
4±0.20 |
12±0.40 |
|
R8×20 |
8±0.40 |
20±0.50 |
|
|
R4×15 |
4±0.20 |
15±0.50 |
|
R8×25 |
8±0.40 |
25±0.50 |
|
|
R4×16 |
4±0.20 |
16±0.50 |
|
R8×30 |
8±0.40 |
30±0.50 |
|
|
R4×18 |
4±0.20 |
18±0.50 |
|
R8×32 |
8±0.40 |
32±0.50 |
|
|
R4×19 |
4±0.20 |
19±0.50 |
|
R8×40 |
8±0.40 |
40±0.50 |
|
|
R4×20 |
4±0.20 |
20±0.50 |
|
R10×6 |
10±0.50 |
6±0.40 |
|
|
R4×25 |
4±0.20 |
25±0.50 |
|
R10×12 |
10±0.50 |
12±0.40 |
|
|
R4.5×19 |
4.5±0.20 |
19±0.50 |
|
R10×20 |
10±0.50 |
20±0.50 |
|
|
R5×4 |
5±0.20 |
4±0.40 |
|
R10×22 |
10±0.50 |
22±0.50 |
|
|
R5×10 |
5±0.20 |
10±0.40 |
|
R10×30 |
10±0.50 |
30±0.50 |
|
|
R5×12 |
5±0.20 |
12±0.40 |
|
RWW3×8 |
3±0.20 |
8±0.40 |
|
|
R5×13 |
5±0.20 |
|
|
ROO3×10 |
3±0.20 |
10±0.40 |
|
|
R5×15 |
5±0.20 |
15±0.50 |
|
ROO4×15 |
4±0.20 |
15±0.50 |
|
|
R5×18 |
5±0.20 |
18±0.50 |
|
RWW4×20 |
4±0.20 |
20±0.50 |
|
|
R5×20 |
5±0.20 |
20±0.50 |
|
ROO5×15 |
5±0.30 |
15±0.50 |
|
|
R5×21.5 |
5±0.20 |
21.5±0.50 |
|
ROO5×20 |
5±0.30 |
20±0.50 |
|
|
R5×24 |
5±0.20 |
24±0.50 |
|
|
|
|
|
|
R5×25 |
5±0.20 |
25±0.50 |
|
|
|
|
|
|
R5×30 |
5±0.20 |
30±0.50 |
|
|
|
|
|
|
R5.5×17 |
5.5±0.20 |
17±0.50 |
|
|
|
||
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Contact: Lily Yu
Skype: sales003_125
Email: sales003@mycoiltech.com
