ER28 Home Appliance Control Board Transformer BobbinER28 High-Frequency Power Supply Transformer Bobbin,The ER28 transformer bobbin is designed primarily for 60–150W high-frequency switching power supply applications. It is made from UL94V-0 flame-retardant material and offers excellent insulation and high-temperature resistance. With its uniform structure and scientifically designed pin layout, it is perfectly suited for automated winding operations. It effectively reduces equipment losses and minimizes the overall size of the unit, making it a core component for small- and medium-power high-frequency power supplies. -
Vertical ER40 Transformer Bobbin 6+6 PinsThe ER40 high frequency transformer bobbin, with its core advantages of high efficiency and high reliability, helps equipment achieve miniaturization and energy-saving upgrades. It is adaptable to complex environments such as fluctuations in industrial power grids and vibrations in vehicles, providing a solid power supply guarantee for the stable operation of equipment in multiple industries. -
ER28 Communication Base Station Transformer BobbinER28 switch-mode power supply transformer bobbins are widely used in the adapter industry. Their primary functions are to support coils, secure the magnetic core, and provide electrical insulation. Made of phenolic material, they offer excellent heat resistance and flame retardancy, high insulation strength to prevent electrical leakage, and high mechanical hardness that resists deformation and cracking. Designed for high-frequency winding applications, they feature high dimensional accuracy and comply with safety standards. These bobbins effectively secure windings, suppress interference, extend transformer lifespan, and reduce operational failures. -
SMD-ER13 Mobile Phone Charger Power Transformer Bobbin 4+4 PinsSMD-ER13 switch-mode power supply driver transformer bobbin, Due to the presence of numerous benzene rings in its molecular structure and the formation of a cross-linked three-dimensional network, phenolic material possesses excellent heat resistance. Standard phenolic materials can maintain structural stability for extended periods at temperatures below 200°C; when modified, their heat resistance can exceed 300°C, with a carbon residue rate of over 50%. They retain structural integrity even in an inert gas environment at 1000°C. Furthermore, they possess inherent flame-retardant properties: they do not burn when exposed to open flames, produce no smoke, are non-toxic and do not drip. No additional flame retardants are required, and the gases emitted during combustion are harmless to humans and the environment, meeting environmental and safety requirements. They are particularly suitable for high-temperature applications and scenarios with stringent fire safety requirements, such as high-temperature components in aerospace and thermal insulation materials for construction. -
ER35 New Energy Charging Pile Vertical Crossover Transformer Bobbin 11+11PinsER35 GaN Fast Charging Vertical Crossover Transformer Bobbin Core is optimised for LLC resonant converters, GaN fast charging modules, and PFC boost transformers. It is also extensively employed in the winding assemblies of switching power supplies and high-frequency transformers, serving as a core structural component in high-frequency power conversion equipment. -
Horizontal ER42 High Frequency Transformer Bobbin 8+8 PinsHorizontal ER42 drive power transformer bobbin, 8+8 pins ER42 single slot coil former. Bobbin size=41mmX40.mmX33.8mm, parallel distance=35.0mm, pin pitch/distance=5.0mm. Transformer applications cover eight core fields, including switching power supplies, communications, new energy, industrial control and other sectors. It can not only match server power supplies, energy storage inverters and other equipment, but also meet the safety regulations requirements of on-board OBCs and medical monitors. -
SMD ER11.5 Vertical Drive Power Supply Transformer Bobbin 6+6 PinsThe best-selling ER11.5 switching power supply transformer frame is here! The dimensions are accurate to 12.5mm×9.2mm×2.8mm, with a pin pitch of 2.0 mm. Made from carefully selected phenolic resin, it features dual advantages of high temperature resistance and corrosion resistance, making it suitable for both household appliances and consumer electronics. It also supports exclusive customization to meet your personalized needs! -
ER7.5 High Frequency Transformer Vertical BobbinBest-selling product,ER7.5 Power switch transformer bobbin, . Bobbin size=7mmX6mmX4.9mm, pin pitch/distance=1.75mm. This transformer is made of PHENOLIC material, which is heat-resistant and corrosion-resistant. It has a wide range of applications and can be used in household appliances as well as consumer electronics. We also support custom transformer bobbin. -
Photovoltaic Inverter ER28 Horizontal Transformer Bobbin 6+6 PinsTest instrument switch horizontal transformer bobbin,Applied in precision equipment such as oscilloscopes and multimeters, the ER28 transformer achieves precise voltage conversion. The PHENOLIC skeleton has high insulation accuracy and low loss, providing a stable signal source for test instruments and enhancing the accuracy and repeatability of measurement data. -
Switching power Supply ER28 Transformer Bobbin 6+6 PinsAutomotive electronic switching power supply transformer bobbin, In vehicle navigation and chargers, the ER28 transformer can withstand a wide temperature range of -40 ℃ to 125℃. The PHENOLIC frame is anti-vibration and resistant to voltage shock, suitable for vehicle 12V/24V power conversion, ensuring the stable operation of vehicle equipment in complex road conditions. -
SMD-ER 11.5 The Vital Sign Monitoring Equipment Transformer BobbinSMD-ER11.5 Mobile Phone fast charging transformer bobbin, application fields: It is applicable to smart wearables (bracelets, headphone power supply modules), portable medical devices (small vital sign monitoring devices), and industrial micro-control (mini sensor nodes, micro PLCS). The miniaturized surface mount design is adapted to the compact layout of devices, meeting the requirements of low-power high-frequency voltage conversion and improving the efficiency of circuit integration. -
SMD-ER 14.5 Three slots Security Monitoring Transformer bobbinSMD-ER14.5 servo drive transformer bobbin, -
ER42 High Frequency Transformer Bobbin 9+9 pinsPC power ER42 horizontal multi slots coil former ,9+9 pins multi grooves bobbin. ER Coil former size=25.60mmX30.50mmX44.50mm, pin distance=5.00mm.Pin row distance=35.00mm.This product utilizes Phenolic material, which boasts excellent heat resistance, enabling it to maintain structural stability in high-temperature environments and prevent deformation that could disrupt transformer operation. It also exhibits outstanding electrical insulation properties, effectively preventing current leakage and reducing the risk of electric shock, thereby ensuring equipment safety. Additionally, the material features high mechanical strength, strong resistance to impact and vibration, and the ability to withstand mechanical stress during transformer operation, ultimately extending the lifespan of the frame. -
ER28 Power Transformer Vertical Bobbin 8+8PinsER28 ferrite core bobbin, 8+8 pins ER28 single slot coil former. Bobbin size=24.8mmX31.5mmX25.2mm, parallel distance=20mm, pin pitch/distance=4.0mm. T375 material ER28 bobbin, we can custom final transformers. -
ER28 High Frequency Transformer Horizontal BobbinER28 ferrite core bobbin, 5+5 pins ER28 single slot coil former. Bobbin size=29mmX25.8mmX21.0mm, parallel distance=23.0mm, pin pitch/distance=5.8mm. T375 material ER28 bobbin, we can custom final transformers. -
ER28 High Frequency Power Transformer BobbinEC28/28 though hole bobbin, 5+5 pins ER28 vertical transformer frame, phenolic material ER28 coil former. parallel distance=17.5mm. Bobbin size=25.0mmX23.2mmX27.0mm, pin distance=5.0mm. We are China bobbin factory and custom different injection toolings to meet customer's requirement. -
ER28/28 Power Supply Transformer FrameER28 vertical bobbin 12pins, through hole ER28 coil bobbin. Phenolic material ER28 coil former. parallel distance=17.5mm. Bobbin size=31.2mmX23.2mmX28.5mm, pin distance=5mm. China bobbin factory, hot selling ER series transformer bobbins. -
ER28 High Voltage Transformer Horizontal BobbinER28 transformer bobbin 6+6 pins, multi section ER28 bobbin. Horizontal ER28 coil former, Bobbin size=37.0mmX30.0mmX25.0mm, pin distance=5.0mm, parallel distance=30.0mm. We manufacture ER28 electronic transformers for power suplies, printers, computers, welcome customzied transformers. -
ER40/30 Power Supply Transformer 8+8 PinsER40 flyback transformer bobbin, 8+8 pins through hole bobbin, 6 grooves ER40 coil former. Parallel Distance=35.2mm. Pin Pitch=5.0mm. Bobbin size=43.9mmX40.0mmX31.1mm. Phenolic ER40/30 coil bobbin. Samples can be sent for prototype testing. -
ER35 High Voltage Transformer Bobbin 6+6 PinsER35 through hole bobbin, 6+6 pins ER35 vertical coil former, phenolic material bobbin. Pin distance=5.0mm, parallel distance=22.4mm, bobbin size=28.0mmX22.60mmX31.70mm. We accept custom designed ER35 transformer and inductor, small batches order is acceptable. -
ER40/15 High Frequency Transformer FrameER40 single slot bobbin 8+8 pins, ER40 ferrite core bobbin, horizontal ER40 transformer bobbin. Parallel Distance=35.4mm. Pin Pitch=5.0mm. Bobbin size=44.0mm*40.0mm*28.4mm. Phenolic bobbin. We can make new ER40 bobbin tooling to meet PCB layout. -
ER35 Power Supply Transformer Bobbin 7+7 PinsER35 transformer phenolic material bobbin, 7+7 pins ER35 bobbin. Pin distance=5.0mm, parallel distance=22.5mm, bobbin size=35.3mmX28.10mmX39.50mm. We accept custom designed ER35 transformer, small batches order is acceptable. -
7+7 Pins ER35 High Frequency Transformer BobbinVertical ER35 ferrite bobbin, 7+7 pins single slot ER35 coil former. Pin distance=5.0mm, parallel distance=22.5mm, bobbin size=35.5mmX28.40mmX41.10mm. Phenolic material ER35 transformer bobbin. We manufacture ER35 electronic transformers. -
ER35 High Power Transformer Bobbin 7+7 PinsER35 7+7 pins DIP pin bobbin, vertical ER35 coil bobbin single slot. Pin distance=5.0mm, parallel distance=22.5mm, bobbin size=35.0mmX27.80mmX39.70mm. Phenolic material ER35 transformer bobbin. We manufacture ER35 electronic transformers. -
ER35 High Voltage Transformer Frame 22+22 Pins22+22 pins ER35 vertical bobbin, through hole ER35 coil former, pin distance=2.54mm,bobbin size=57.8mmX33.35mmX41.10mm, parallel distance=25.5mm. Phenolic material ER35 bobbin. We manufacture ER35 transformer for switching power suppliers. -
ER28 High Frequency Transformer FrameER28 vertical transformer, 6+6 pins single slot ER28 coil former. Bobbin size=34.0mmX23.0mmX34.0mm, pin distance=5mm, parallel distance=17.5mm. We manufacture ER28 transformers for UPS, power supply, SMPS, welcome small order transformers. -
ER26 Transformer Bobbin For Electronic DeviceER26 coil bobbin. ABS material ER26 coil former, we can make new tooling to meet size requirement. -
ER35 High Frequency Power Transformer FrameER35/26 vertical bobbin 15+15 pins, pin distance=2.5mm, bobbin size=40.0mmX27.7mmX27.8mm, parallel distance=22.5mm. Phenolic material ER35 electronic transformer bobbin. We manufacture final electronic transformer for power suppliers, low magnetic leakage and good performance, welcome customized transformers. -
ER28 Power Transformer Horizontal BobbinER28/34 core bobbin, horizontal ER28 6+6 pins coil former. Bobbin size=34.9mmX28.0mmX20.9mm, pin distance=5mm, parallel distance=26.0mm. We manufacture ER28 transformers for SMPS, used in DC converters, welcome small order of transformers. -
SMPS Transformer ER44 Horizontal Bobbin 16 PinsER44 8+8 pins coil bobbin, horizontal ER44 bobbin double slots. ER44 case size=46.8mmX44.0mmX26.3mm, bobbin pin distance=5.0mm, bobbin parallel distance=35.0mm. We manufacture ER44 electronic transformer for AC-DC converters, SMPS transformer has low magnetism leakage and good performance, we accept OEM service.
