PA66 EE30 Transformer Bobbin for High Frequency Transformers4+4 Pins EE30 horizontal electronic transformer bobbin.DIP bobbin PA66 transformer bobbin.Pin pitch=6mm,Parallel Distance=20.7mm Bobbin Size=28.4mmX25.5mmX24.25mm,UL REC:94V-0 -
5+5 Pins EE30 Transformer Bobbin for High Frequency Transformers5+5 Pins EE30 horizontal electronic transformer bobbin.DIP bobbin. PA66 transformer bobbin.Parallel Distance=15.4mm. Bobbin Size=26.2mmX25.6mmX20mm,UL REC:94V-0. -
5+5 Pins EE Type High Frequency Transformer Bobbin Horizontal Bobbin5+5 Pins horizontal transformer bobbin.DIP transformer bobbin. Phenolic transformer bobbin.Parallel Distance=25mm. Bobbin Size=28.6mmX24mmX18.6mm,UL REC:94V-0. -
8+8 Pins Horizontal Transformer Frame EE30 Transformer BobbinEE30 flyback trasnformer, 8+8 Pins horizontal EE30 coil bobbin for transformer. Bobbin Size=28.6mmX24mmX18.6mm. Parallel Distance=25mm. DIP transformer bobbin. PA66 material transformer bobbin. UL REC:94V-0. -
High Frequency Transformer Bobbin Horizontal Bobbin 6+6 Pins Horizontal BobbinEE transformer bobbin with 6+6 Pins. Horizontal transformer bobbin. Phenolic DIP transformer bobbin. Parallel Distance=24mm. Bobbin Size=31.1mmX24mmX21mm, UL REC:94V-0. -
EE30 High Frequency Bobbin 6+6 Pins Horizontal BobbinEE30 horizontal transformer bobbin. 6+6 Pins transformer bobbin. Phenolic DIP transformer bobbin.Parallel Distance=34.5mm. Bobbin Size=44.5mmX30mmX21mm, UL REC:94V-0. -
7+7 Pins EE30 High Frequency Bobbin for Ferrite Core7+7 Pins EE30 horizontal transformer bobbin.DIP transformer bobbin. PA66 transformer bobbin. Parallel Distance=22.4mm. Bobbin Size=33.5mmX27.3mmX23.55mm. UL REC:94V-0 -
EE30 Transformer Bobbin for Electronic Current Power TransformerEE30 high frequency transformer bobbin. FR530 transformer bobbin. UL REC:94V-0. Bobbin Size=38.6mmX30.2mmX30.2mm. -
EE30 High Frequency Horizontal Transformer Bobbin with 6+6 Pins BobbinEE30 horizontal transformer bobbin.UL REC:94V-0. 6+6 Pins phenolic transformer bobbin.Parallel Distance=39.6mm. DIP bobbin. Bobbin Size=46.6mmX30mmX26.5mm. -
Double Slots EE30 Transformer Bobbin 4+4 Pins Horizontal BobbinEE30 double slots bobbin transformer bobbin.UL REC:94V-0. 4+4 Pins horizontal transformer bobbin.Parallel Distance=20.7mm. DIP bobbin. Bobbin Size=28.4mmX25.5mmX24.25mm. -
EEI35 Electronic Transformer Bobbin No Pins High Frequency BobbinNo Pins EEI35 electronic transformer bobbin. UL REC:94V-0 Nylon material transformer bobbin, accept custom made. We can make new EEI bobbin tooling to meet different dimensions. -
Horizontal EER35 High Frequency Transformer Bobbin with 7+7 Pins7+7 Pins EER35 horizontal transformer bobbin. DIP bobbin. Parallel Distance=37mm. Pin Pitch=5.0mm. UL REC:94V-0 Bobbin Size=43.5mmX36mmX28.8mm. EER35 phenolic bobbin. -
EER35 Electronic Transformer Bobbin 6+6 Pins Horizontal Bobbin6+6 Pins EER35 horizontal bobbin. DIP transformer bobbin. Parallel Distance=35mm. Pin Pitch=5.0mm. UL REC:94V-0 Bobbin Size=42.5mmX35mmX24mm. EER35 phenolic bobbin. -
7+7 Pins EE40 Bobbin High Frequency Horizontal Transformer BobbinEE40 horizontal transformer bobbin. DIP transformer bobbin. Parallel Distance=25.8mm. Pin Pitch=5.0mm. UL REC:94V-0 Bobbin Size=38.5mmX33.5mmX27.9mm. 7+7 PinsEE40 transformer bobbin. -
4+4 Pin EE19 Electronic Transformer Bobbin Horizontal Coil Former4+4 pins horizontal coil former. Phenolic material bobbin. Pin Pitch=5mm, Parallel Distance=12.5mm. DIP bobbin. Bobbin Size=19.3mmX17mmX16.2mm. UL REC:94V-0. -
5+5 Pins EE19 Vertical High Frequency Transformer Bobbin Dip Coil FormerEE19 vertical transformer bobbin. 5+5 pins coil former. Parallel distance=13mm. Pin Pitch=3.8mm. Dip bobbin. Bobbin Size=20mmX16.2mmX22.8mm. UL REC: 94V-0 -
EE19 Coil Former 5+5 Pins Vertical Bobbin Phenolic Winding bobbin5+5 pins EE19 transformer bobbin. Vertical coil former. Parallel distance=12.7mm. Pin Pitch=3.8mm. Dip bobbin. Bobbin Size=20mmX16.5mmX15.7mm. UL REC: 94V-0 -
EE19 5+5 Pins Horizontal Transformer Bobbin for Power TransformerEE19 high frequency transformer bobbin. Horizontal coil former. Parallel distance=24.1mm.Pin Pitch1=3.5mm.Pin Pitch2=4.5mm Bobbin Size=30.1mmX20.8mmX15.5mm. UL REC: 94V-0 -
EE19 Vertical Coil Former 4+4 Pins High Frequency Transformer Bobbin4+4 pin vertical coil former. Phenolic material bobbin. Pin Pitch=5mm, Parallel Distance=15mm. DIP bobbin. Bobbin Size=18.9mmX18.9mmX15.9mm. UL REC:94V-0.
