Vertical Bobbin EE16 Transformer Bobbin With 5+2 Pins5+2 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=19.5mm Size=22.5mmX17mmX14mm -
Horizontal Bobbin EE16 Transformer Bobbin Phenolic Material5+2 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=17.5mm Size=20.6mmX16mmX14mm
-
Horizontal Bobbin EE16 Transformer Bobbin With 5+2 Pins5+2 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=17.5mm Size=20.6mmX16.1mmX15.3mm -
Vertical Bobbin EE16 Dip Transformer Bobbin With 4+6 Pins5+2 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=12.2mm Size=17.6mmX15.5mmX16.3mm -
Horizontal Bobbin EE16 Dip Transformer Bobbin With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=11mm Size=15.2mmX14.6mmX13.7mm -
Vertical Bobbin EE16 Transformer Bobbin Phenolic Material With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.2mm Parallel Distance=10.5mm Size=12.8mmX11.4mmX14.2mm -
Horizontal Bobbin EE16 Transformer Phenolic Material With 5+2 Pins5+2 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=15.5mm Size=20mmX18mmX13.27mm -
Double Slots EE16 Vertical Transformer Bobbin Phenolic Material5+5 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=10mm Size=12.7mmX11.2mmX13.8mm -
Double Slots EE16 Vertical Transformer Bobbin 5+5 Pins5+5 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=10mm Size=12.7mmX11.2mmX13.8mm -
Horizontal Bobbin EE16 Transformer Bobbin With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=11mm Size=15mmX13.9mmX13.5mm -
Five Slots EE16 Horizontal Transformer Bobbin With 2+3 Pins2+3 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=12.45mm Size=17mmX16mmX10.5mm -
Horizontal Bobbin EE16 Transformer Bobbin With 5+2 Pins5+2 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=16.5mm Size=19.52mmX16mmX13.44mm -
Horizontal Bobbin EE16 Transformer Bobbin With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.2mm Parallel Distance=15.5mm Size=18.3mmX16mmX13.1mm -
Horizontal Bobbin EE16 Transformer Bobbin With Phenolic Material5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.2mm Parallel Distance=15.5mm Size=18.6mmX16mmX13.4mm -
Horizontal Bobbin EE16 Transformer Bobbin Dip Bobbin5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.2mm Parallel Distance=15.5mm Size=18.3mmX16mmX13.6mm -
Horizontal Bobbin EE16 Transformer Bobbin With 6+6 Pins6+6 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=2.5mm Parallel Distance=12.5mm Size=15.6mmX15mmX12.6mm -
Horizontal Bobbin EE16 Transformer Bobbin With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=5.0mm Parallel Distance=15.2mm Size=19.5mmX18.4mmX16.25mm -
Horizontal Bobbin EE16 Transformer Bobbin With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=5.0mm Parallel Distance=15.2mm Size=20.5mmX18.4mmX20.5mm -
Phenolic Material EE16 Dip Transformer Bobbin With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.5mm Parallel Distance=12.8mm Size=15.5mmX16mmX12.3mm -
Horizontal Bobbin EE16 Dip Transformer Bobbin With 4+6 Pins4+6 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=15.5mm Size=18.7mmX18.4mmX13.5mm -
Horizontal Bobbin EE16 Dip Transformer Bobbin Phenolic Material4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=11mm Size=15mmX14.6mmX14mm -
Horizontal Bobbin EE16 Transformer Bobbin Dip Bobbin With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=2.5mm Parallel Distance=13.6mm Size=15.8mmX15.5mmX14mm -
Double Slots EE16 Horizontal Transformer Bobbin With 3+4 Pins3+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=4mm Parallel Distance=10mm Size=14mmX13.9mmX12.8mm -
Horizontal Bobbin EE16 Transformer Bobbin With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.8mm Parallel Distance=17.8mm Size=20.8mmX18.3mmX13.3mm -
Horizontal Bobbin EE16 Dip Transformer Bobbin Phenolic Material3+3 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.8mm Parallel Distance=12.5mm Size=16.2mmX11mmX11.7mm -
Double Slots EE16 Horizontal Transformer Bobbin Phenolic Material3+3 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.8mm Parallel Distance=12.5mm Size=16.2mmX11mmX11.8mm -
EE16 High Frequency Horizontal Transformer Bobbin2+2 pins horizontal EE16 transformer bobbin, Phenolic Material, pPin pitch=10mm, parallel distance=12.6mm. bobbin size=17.8mmX10mmX11mm. We have many bobbin toolings, for special size bobbin, we can make new tooling. -
Four Slots EE16 Vertical Transformer Bobbin With 4+4 Pins4+4 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=5mm Parallel Distance=10mm Size=17.8mmX12.5mmX17.7mm -
EE16 Horizontal Transformer Bobbin Phenolic Material With 4+4 Pins4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=2.5mm Parallel Distance=12.7mm Size=13mmX15mmX10.5mm -
EE16 Vertical Transformer Bobbin Phenolic Material With 3+3 Pins3+3 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=9mm Size=11.6mmX13.3mmX13.3mm
