EI type encapsulated transformers for power supply. Output power: 75.00 VA – 100.0 VA. Low frequency encapsulated transformer. Excellent temperature fluctuation resistance properties. High electrical safety and long service-life features. Self-extinguishing cast housing and sealing material. Per item tested quality with certificate.
brand:
MCTitem no.:
EI84 75.0 VA – 100.0 VAshipping port:
ShanghaiHefei Mycoil Technology Co.,LTD is professional electronic encapsulated transformers manufacturer. All materials we used are environmental protected and UL certified. We accept custom made and design service.
Quick Details
|
Part No: EI84 75.0 VA – 100.0 VA |
Brand name: MCT |
|
Output Power up to 100.0 VA |
Custom made: Available |
|
Temperature class ta 70 °C/B |
Logo: Can be customized |
|
High voltage resistance |
Packing: Carton, can custom |
|
Bobbin: Dual chamber windings |
MOQ: Any quantity |
|
Certification: ISO9001,ROHS,CE |
OEM: Available |
|
Lead time: 25 days after payment |
Shipping: Air, Ship, etc |
Part Information
Product Name: EI Type Encapsulated Power Transformers for Printed Circuit Boards
Product Range: Transformers, Inductors, Choke coils, Transformer bobbins, Magnetic cores.
Applications: Household appliances, printed circuit boards, low power industrial control products, meters and other industries.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Product Part Number
|
Frame size/Core height |
Output Power Ta 70°C/B |
Height(h) |
Weight |
|
BV EI 841.../29.5mm |
75.0V/A |
38.5±0.5mm |
1.600kg |
|
BV EI 842.../43.5mm |
100.0 V/A |
44.5±0.5mm |
2.100kg |
Product Specification
If you have any request, please contact us, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
TEL: +86 551 6619 6829
