EP7 High Frequency Transformer Ferrite Core Bobbin

EP7 drive transformer bobbin. Coil former EP7 pin 4+4 horizontal bobbin. Low loss power transformer. We make bobbin tooling to meet special requirement. Bobbin for power supply transformer. Low temperature rise power transformer. Welcome customized design and OEM service.

brand:
MCT
item no.:
MCT-SMD-EP0706
shipping port:
Shanghai
payment:
T/T in advance

contact now

product description

Factory price EP7 SMD coil bobbin, horizontal type pin 4+4, we supply matched ferrite cores for samples making.

Quick Details

Part No: MCT-SMD-EP706	Brand Name: MCT
Material: PM9630	Color: Black
UL REC: 94V-0	Logo: Can be customized
Lead Time: 20 days after payment	Custom Made: Available
Certification: ISO9001,ROHS,CE	Packing: Carton, accept customize
OEM: Available	MOQ: Any quantity
