EQ40 High Frequency Power Transformer Bobbin

EQ40 smps transformer bobbin, 6+6 pin vertical EQ40 bobbin. Bobbin Size=45.4mmX36.8mmX19.8mm. Pin distance=5.0mm. Parallel distance=39.0mm. We are China bobbin factory, we supply various magnetic ferrite cores with competitive price.

  • brand:

    MCT
  • item no.:

    MCT-EQ4002
  • shipping port:

    Shanghai
  • payment:

    T/T in advance; PayPal
contact now
product description

EQ40 flyback transformer frame, 6+6 pin coil former vertical shape bobbin, sampels are available.


Product Specification

EQ40 high frequency bobbin


If you are interested in our products, welcome to contact us:

Email: sales003@mycoiltech.com

Skype: live:sales003_125

Contact: Miss Lily

Request a Free Quote

If you are interested in our products or have any questions, contact us now!
