ETD34 High Voltage Transformer Double Slots Bobbin

ETD29 Switching Power Transformer Frame ,ETD29 coil former size=33.60mmX31.10mmX28.96mm.Pin row distance=25.40mm,Pin row distance 2=4.06mm，pins distance =5.08mm.This is our latest product developed for customers, which can be used for computer power supplies, adapters, etc. The ETD29 transformer can also be used to convert mains power into low-voltage DC power required by equipment, providing stable power supply for internal circuits..If you have any technical questions, please feel free to communicate with us at any time.

ETD34 coil bobbin, 15+15 pins ETD34 horizontal transformer. Parallel Distance=30.0mm. Pin pitch=2.54mm. Bobbin Size=40.0mmX39.2mmX27.0mm. ETD34 soft ferrite core transformer with high magnetic flux and low loss magnetic materials, mainly used in PCB circuits, computers, monitors, printer, scanner, duplicator, mobile adapters, other equipment and instruments.

ETD34 main transformer, 16+16 pins horizontal ETD34 bobbin. Parallel Distance=25.4mm. Pin pitch=2.54mm.Bobbin Size=41.8mmX38.6mmX30.04mm. ETD34 core transformer with high magnetic flux and low loss magnetic materials, mainly used in PCB circuits, computers, monitors, printer, scanner, duplicator, mobile adapters, other equipment and instruments.

ETD34 SMPS transformer bobbin,16+16 pins lead free bobbin. ETD34 transformer frame, Parallel Distance=32.0mm. Pin pitch=2.54mm. Bobbin Size=41.8mmX38.6mmX30.04mm. We manufacture final  ETD34 transformer for customer, with high magnetic flux and low loss magnetic materials, mainly used in PCB circuits, computers, monitors, printer, scanner, duplicator, mobile adapters, other equipment and instruments.

ETD59 flyback transformer. 13+13 pin horizontal ETD59 bobbin. Bobbin Size=66.8mmX66.2mmX48.35mm. Pin pitch=5.08mm. Parallel Distance=50.8mm. ETD59 high frequency transformer widely used in power supplies, fax machines, monitor, scanner, UPS and other equipments.
