EE13 High Voltage Switching Power Horizontal Transformer BobbinEE13 PCB transformer supply. 5+2 Pins horizontal EE13 coil former. Bobbin size=18.4mmX13.2mmX13.3mm. Parallel distance=15.8mm. Pin Pitch=2.75mm. Safety distance EE13 transformer bobbin made in China. -
ER35 FlybackTransformer Horizontal Bobbin Pin 8+8ER35 high current transformer manufacturer. Horizontal 8+8 pin ER35 coil former. Supply matched ER/EC35 ferrite cores. Parallel Distance=35mm. Pin Pitch=5.0mm. Bobbin Size=40mmX39.6mmX24.35mm. -
EE19 Horizontal Bobbin for Transformer Filter Ferrite CoreEE19 pin 4+4 transformer bobbin. Horizontal transformer bobbin. Phenolic material bobbin. Pin Pitch=3.81mm, Parallel Distance=12.7mm. DIP bobbin. Bobbin Size=19mmX17.8mmX15.8mm. UL REC:94V-0. -
EE19 High Frequency Horizontal Bobbin Single Slot Pin 5+5 BobbinEE19 horizontal type transformer bobbin. EE19 transformer bobbin 10 pin. Phenolic material bobbin. Pin Pitch=3mm, Parallel Distance=11.2mm. DIP bobbin. Bobbin Size=19.2mmX17.8mmX13.9mm. UL REC:94V-0. -
EE19 PCB Mounting Transformer Bobbin 5+2 Pins Horizontal Coil FormerEE19 5+2 pin transformer bobbin. EE19 horizontal winding bobbin. Phenolic material bobbin. Pin Pitch=3mm, Parallel Distance=18.4mm. DIP bobbin. Bobbin Size=22.55mmX19.2mmX13.7mm. UL REC:94V-0. -
High Voltage Transformer Bobbin 5+5 Pin EE19 Horizontal BobbinEE type EE19 transformer bobbin. Horizontal EE19 transformer bobbin. 5+5 pin coil former. Phenolic material bobbin. Pin Pitch=3mm, Parallel Distance=12.5mm. DIP bobbin. UL REC:94V-0. -
EE19 Horizontal High Frequency Transformer Bobbin Bakelite Bobbin 4+4 Pin4+4 pin EE19 transformer bobbin. Horizontal transformer bobbin. Phenolic material bobbin. Pin Pitch=4.7mm, Parallel Distance=13mm. DIP bobbin. Bobbin Size=18.4mmX16mmX13.1mm. UL REC:94V-0. -
EE19 Bobbin 4+4 Pin For Transformer Horizontal Winding BobbinEE19 8pins transformer bobbin. Horizontal coil former. Phenolic material bobbin. Pin Pitch=5mm, Parallel Distance=17.7mm. DIP bobbin. Bobbin Size=21.4mmX18.8mmX16.2mm. UL REC:94V-0. -
EE20 Ferrite Core Bobbin High Frequency Horizontal Coil BobbinElectronic transformer bobbin EE20. Horizontal EE20 coil former. PA66 material transformer bobbin. Pin Pitch=5mm. DIP bobbin. Parallel Distance=15mm. Bobbin Size=20.5mmX20.2mmX13.55mm. UL REC:94V-0. -
EE20 3+3 Pin Vertical High Frequency Flyback Transformer BobbinEE20 bobbin 3+3 pin. EE20 vertical type coil former. FBT material transformer bobbin. Parallel Distance=15.5mm. Pin Pitch=6.25mm. DIP bobbin. Bobbin Size=20mmX16.8mmX17.9mm. UL REC:94V-0. -
EE20 Horizontal Coil Bobbin For PCB Mounting TransformerEE20 horizontal phenolic bobbin. EE20 4+4 pins coil former. Bobbin Pin Pitch=5mm. DIP transformer bobbin. Parallel Distance=15mm. Bobbin Size=20mmX19.5mmX15.5mm. UL REC:94V-0. -
PQ32 Vertical High Frequency Transformer Bobbin For Ferrite CoreLead free PQ32 6+6 pins bobbin. Vertical transformer bobbin. Pin pitch=5.1mm. Parallel Distance=30.5mm. Phenolic material PQ32 bobbin. Size=34.01mmX31.93mmX19.7mm. Dip bobbin. We can make bobbin tooling. -
PQ32 Vertical 6+6 Pins High Power Bobbin For PCB Mount TransformerPQ32 vertical coil former. 6+6 pins transformer bobbin. Pin pitch=5mm. Parallel Distance=30mm. Phenolic material PQ32 bobbin. Size=34.5mmX33.2mmX25mm. Dip bobbin. We can make bobbin tooling. -
CQ25 Vertical High Frequency Bobbin 5+2 Pins Coil FormerCQ25 transformer bobbin 2+5 pin. Vertical type transformer bobbin. Pin pitch=3mm. Parallel Distance=22.7mm. Phenolic material CQ25 bobbin. Size=26.2mmX23mmX19.5mm. Dip bobbin. We can make bobbin tooling. -
EI25 High Frequency Vertical Transformer Bobbin Pin 5+55+5 pin EI25 transformer bobbin. EI25 vertical bobbin. Bobbin Size=25mmX20mmX18.5mm. Parallel Distance=20mm. Pin Pitch=5.0mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI25 Ferrite Core Bobbin 4+4 Pin Vertical EI Transformer BobbinLead free 4+4 pin EI25 transformer bobbin. EI25 vertical bobbin. Bobbin Size=25.5mmX17.5mmX19.8mm. Parallel Distance=12.6mm. Pin Pitch=5.0mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI25 5+8 Pin Phenolic High Frequency Transformer BobbinEI25 vertical transformer bobbin 5+8 pin. EI25 phenolic material bobbin. Bobbin Size=28.5mmX20.5mmX20.5mm. Parallel Distance=15.2mm. Pin Pitch1=3.50mm. Pin Pitch2=5.0mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI25 Vertical 4+4 Pin Bobbin for Electronic TransformerEI25 bakelite transformer 4+4 pin bobbin. EI25 vertical bobbin. Bobbin Size=25mmX17.3mmX20mm. Parallel Distance=12.4mm. Pin Pitch=5.0mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI25 High Power Transformer Bobbin 4+4 Pin Vertical BobbinEI25 ferrite core bobbin 4+4 pin. EI25 vertical type bobbin. Bobbin Size=25mmX17.3mmX20.5mm. Parallel Distance=12.4mm. Pin Pitch=5.0mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI25 4+4 Pin Coil Former Vertical EI25 Ferrite Core BobbinEI25 ferrite core bobbin 4+4 pin. EI25 vertical/horizontal type transformer bobbin. Bobbin Size=25mmX17.3mmX20.5mm. Parallel Distance=12.4mm. Pin Pitch=5.0mm. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
PQ26 Vertical Bobbin for High Frequency Isolation TransformerPQ2625 vertical ferrite core bobbin. 6+6 pins coil former. Size=29.3mmX26.4mmX25.2mm. Pin pitch=3.8mm. Parallel Distance=25.6mm. Phenolic material PQ26 bobbin. Dip bobbin. We can make bobbin tooling. -
EI28 Vertical Ferrite Core Bobbin With 5+5 Pins10 pins EI28 ferrite core bobbin. EI28 vertical type transformer bobbin. Bobbin Size=26mmX21.5mmX19.65mm. Parallel Distance=17.5mm. Pin Pitch=5.0mm. DIP transformer bobbin. We can make new bobbin tooling to meet different requirements. UL REC:94V-0. -
EI28 Vertical Single Slot Transformer Bobbin With 5+5 PinsEI28 vertical transformer bobbin. 5+5 pins EI28 bobbin. Bobbin Size=26mmX21.5mmX18.85mm. Parallel Distance=17.5mm. Pin Pitch=5.0mm. DIP transformer bobbin. We can make new bobbin tooling to meet different requirements. UL REC:94V-0. -
EI28 6+6 Pins Vertical Bobbin Made of Phenolic6+6 pins EI28 coil bobbin. EI28 vertical bobbin. Bobbin Size=29.6mmX24mmX19.9mm. Parallel Distance=17.6mm. Pin Pitch=5.0mm. DIP transformer bobbin. We can make new bobbin tooling to meet different requirements. UL REC:94V-0. -
Vertical EI28 High Frequency Transformer Bobbin 5+5 PinsEI28 5+5 pins coil former. EI28 vertical bobbin. Bobbin Size=26mmX22mmX19.7mm. Parallel Distance=17.5mm. Pin Pitch=5.0mm. DIP transformer bobbin. We can make new bobbin tooling to meet different requirements. UL REC:94V-0. -
EI28 Vertical Ferrite Core Transformer Bobbin 6+6 PinsEI28 coil former 6+6 pins. Vertical EI28 bobbin. Parallel Distance=17.5mm. Bobbin Size=29mmX24mmX19.6mm. Pin Pitch=5.0mm. DIP transformer bobbin. We can make new bobbin tooling to meet different requirements. UL REC:94V-0. -
ER29 Vertical High Frequency Transformer 5+4 Pins BobbinER29 5+4 pins transformer bobbin. Vertical ER29 bobbin. Parallel Distance=17.5mm. Pin Pitch=5.0mm. Bobbin Size=24.8mmX22.8mmX16.65mm. DIP transformer bobbin. We can make new bobbin tooling to meet different requirements. UL REC:94V-0. -
EF25 Vertical High Frequency Transformer BobbinEF25 vertical transformer bobbin. 4+4 pins EF25 transformer bobbin. Bobbin Size=25.4mmX23mmX28.2mm. Parallel Distance=17mm. Pin pitch=5mm. Nylon and PET material bobbin. DIP transformer bobbin. -
EF25 Ferrite Core Vertical Bobbin For TransformerEF25 transformer bobbin 4+4 pins. EF25 vertical transformer bobbin. Bobbin Size=37mmX20.1mmX20.4mm. Parallel Distance=32mm. Pin pitch=4.5mm. Nylon and PET material bobbin. DIP transformer bobbin. -
EF25 PC40 Ferrite Core Horizontal Bobbin 4+4 PinsEF25 4+4 pin horizontal bobbin. Single slot EF25 coil former. Bobbin Size=25.4mmX25.4mmX21mm. Parallel Distance=19.9mm. Pin pitch=5mm. PET material bobbin. DIP transformer bobbin.
