EE13 High Voltage Switching Power Horizontal Transformer BobbinEE13 PCB transformer supply. 5+2 Pins horizontal EE13 coil former. Bobbin size=18.4mmX13.2mmX13.3mm. Parallel distance=15.8mm. Pin Pitch=2.75mm. Safety distance EE13 transformer bobbin made in China. -
EFD25 High Frequency Power Transformer BobbinEFD25 pcb mounting transformer. 6+6 pin single slot SDM bobbin. Bobbin Size=31.5mmX25.0mmX12.6mm. Pin pitch=4.0mm. We have bobbin tooling now, samples are available. -
EFD25 Flyback Transformer SMD BobbinEFD soft ferrite core bobbin. Mainly for pcb mounting transformer. Bobbin pin 6+6 horizontal shape. Bobbin Size=31.5mmX25.0mmX12.6mm. Pin pitch=3.75mm. We have bobbin tooling now, samples are available. -
ETD29 Transformer Ferrite Core Horizontal BobbinETD29 power transformer bobbin. Ferrite core ETD29 bobbin 13+13 pins. Bobbin Size=34.7mmX34.6mmX24.3mm. Parallel Distance=25.4mm. Pin pitch=2.54mm. We manufacture various types of electronic transformers. Most of products are accept custom design and OEM service according to the requirements of the customers. -
EP10 Flyback Power Transformer SMD BobbinEP10 transformer bobbin factory. EP10 coil bobbin for transformer. SMD EP10 4+4 pin horizontal bobbin. Size=14.6mmX11.4mmX10.5mm. Pin pitch=2.5mm. Parallel distance=7.0mm. EP10 small electronic transformer mainly used for communications control equipment, switching power supply, chargers, alarm system and inverters. Custom designs available. -
ETD39 High Voltage Transformer Frame 8+8 Pins8+8 pins ETD39 horizontal bobbin, ETD39 DIP transformer frame. Parallel Distance=30.0mm. Pin pitch=5.0mm, Bobbin Size=42.0mmX41.5mmX32.68mm. ETD39 power transformer has high magnetic flux and low loss magnetic materials, mainly used in PCB circuits, computers, monitors, printer, scanner, duplicator, mobile adapters, other equipment and instruments. -
EF16 PCB Mounting Transformer Horizontal Bobbin4+4 pins EF16 coil former. EF16 ferrite core bobbin, parallel distance=15.05mm. Pin pitch=3.80mm. Bobbin size=21.85mmX18.7mmX16.85mm. EF16 electronic transformers are widely used in electrical equipment, household applications, medical equipment, computers, switching power supplies, communication equipment, power component, vehicle electronic equipment. -
EE22 High Frequency Switching Power Supply BobbinEE22 through hole bobbin, 5+5 pins EE22 vertical bobbin. Vertical EE22 DIP bobbin. Phenolic material EE22 coil bobbin. Parallel Distance=10.0mm. Pin pitch=4.0mm. Bobbin Size=22.0mmX15.7mmX17.3mm. We are transformer bobbin factory and delove bobbin toolings, for special size bobbin, we can custom bobbin tooling and we also manufacture various high frequency transformers for SMPS. -
EFD40 Horizontal Double Slot Coil Former 8+8 PinsEFD40 high frequency transformer multi slot bobbin is a very popular product in our factory, 8+8 pins EFD40 horizontal bobbin,bobbin former size=42.60mmX41.00X17.40mm.We accept customized transformer frame sizes. If your industry belongs to laboratory research and development, medical equipment, military industry, or manufacturing, you can contact us at any time and we can provide transformer samples. -
GU07/POT07 Mobile Phone Fast Charging Transformer Bobbin.GU07/POT07 PLC power module transformer bobbin ,High frequency and low consumption, superior energy efficiency: PA66 features excellent high-frequency dielectric performance, effectively reducing the coupling loss between the transformer core and windings. In high-frequency scenarios ranging from tens of kHz to MHz, it significantly enhances the efficiency of electrical energy conversion, helping customers reduce energy consumption costs and meet energy-saving requirements. -
GU59/POT59 Small Medical Equipment Transformer BobbinGU59/POT59 Automated transformer bobbin ,Chemical-resistant self-extinguishing, wide application: It can withstand various chemical media such as oil and flux that may come into contact with transformers during operation, and has self-extinguishing properties. In the event of an unexpected fire, it can delay the combustion and is suitable for multiple fields such as industry, home appliances, and new energy, expanding the application range of customers' products. -
Air Conditioning switch power supply transformer BobbinThe commercial air conditioning transformer bobbin, EE42 is used for the external power supply of commercial air conditioners and supports high power output. EE42 has strong resistance to electromagnetic interference. The PHENOLIC material can withstand a high temperature of 120℃, has excellent insulation properties, and is suitable for frequent start-stop scenarios, reducing the energy consumption of commercial air conditioners. -
EF16 Notebook Peripheral Horizontal Transformer Frame 4+5 PinsThe EF16 is a vehicle-mounted USB small module transformer bobbin, which converts 12V to 5V for mobile phone charging. Its advantages include fast high-frequency response and shock resistance.PM-9820 is oil-resistant and dimensionally stable, making it suitable for complex automotive working conditions and preventing unstable power supply to modules due to oil stains or vibrations. -
Household Appliance Horizontal Transformer Bobbin 7+3 PinsMedical equipment power switch transformer bobbin,It is compatible with the power supply of monitors and ultrasonic equipment. The ETD transformer has strong insulation and isolation performance and complies with medical electrical standards. bobbin flame-retardant UL94 V-0 grade, resistant to alcohol disinfection, free of volatile substances, ensuring the safety and sterility of power supply for medical equipment. -
GU25/POT25 Encapsulated Transformer BobbinGU/POT25 Power Supply Driven Transformer Bobbin,High-temperature phenolic resin construction: 150–200°C continuous operation; 300°C+ short-term resistance (far exceeding PA66's 130°C limit) Matches ferrite core thermal expansion → prevents deformation from temperature fluctuations Ideal for high-load heat dissipation requirements of GU/POT25 transformers.
