6+8 Pins PQ20 Flyback Transformer FramePQ20/16 vertical coil former. 6+8 pins transformer PQ20 bobbin. Pin pitch=5mm. Parallel Distance=20.5mm. Bobbin Size=23.0cmX23.0cmX18.2cm. PQ bobbin series: PQ20/16 PQ20/20 PQ26/25 PQ32/30, welcome customized PQ20 transformer, we can make bobbin tooling. -
PQ20 High Frequency Vertical BobbinPQ20/14 core bobbin, 5+5 pins PQ20 vertical transformer. Pin pitch=3.7mm. Parallel Distance=17.5mm. Bobbin Size=20.0cmX20.0cmX13.9cm. PQ bobbin series: PQ20/14 PQ20/20 PQ26/25 PQ32/30 PQ50/50 PQ65, welcome customized PQ20 transformer, we can make bobbin tooling. -
PQ20 Switching Power Transformer Frame 6+8 Pins6+8 pins PQ20/20 coil former, vertical PQ20 though hole bobbin. Parallel Distance=20.5mm. PQ20 ferrite core bobbin. Bobbin Size=23.0cmX23.0cmX23.30cm. Pin pitch=2.54mm. Pin pitch=3.80mm. PQ20 series bobbin for high power PQ20 transformer, welcome customized PQ20 electronic transformer. -
High Power PQ20 Transformer Vertical BobbinPQ20 vertical bobbin 6+8 pins, PCB mounting PQ20 transformer bobbin. Parallel Distance=15.0mm. PQ20/16 ferrite core frame. Bobbin Size=23.8cmX22.9cmX16.5cm. Pin pitch=2.5mm. Pin pitch=3.80mm. PQ20 series bobbin for electronic transformers, welcome customized PQ20 power transformer.
