SMD EFD15 High Frequency Power Transformer

SMD EFD15 driver transformer. 5+5 pins horizontal EFD15 horizontal bobbin. Pin Pitch=2.5mm. Parallel distance=15.0mm. Bobbin Size=21.55mmX14.9mmX7.25mm. EFD15 transformer bobbin made of PM9630 material.

brand:
MCT
item no.:
MCT-SMD-EFD1523
shipping port:
Shanghai
payment:
T/T in advance
price range:
3000-5000/0.035$

contact now

product description

Popular transformer bobbin EFD15, SMT ferrite core bobbin, we accept small purchase order, customized transformer also acceptable.

Quick Details

Part No: MCT-SMD-EF1523	Brand Name: MCT
Material: PM9630	Color: Black
UL REC: 94V-0	Logo: Can be customized
Lead Time: 20 days after payment	Custom Made: Available
Certification: ISO9001,ROHS,CE	Packing: Carton, accept customize
OEM: Available	MOQ: Any quantity
