SMD EFD20 Switching Power Transformer Bobbin

EFD20 PCB transformer wholesale, 2+7 pins horizontal EFD20 SMD winding bobbin, eight slots EFD20 coil former from China bobbin factory. LCP-4008 material transformer bobbin. Customized design and OEM service are accepted.

brand:
MCT
item no.:
MCT-SMD-EFD2009
shipping port:
Shanghai
payment:
T/T in advance

contact now

product description

2+7 pins EFD20 SMD bobbin, eight slots EFD20 bobbin with L pins, factory price and good quality, welcome custom made transformer and inductor.

Quick Details

Part No: MCT-SMD-EFD2009	Brand Name: MCT
Material: LCP-4008	Color: Black
UL REC: 94V-0	Logo: Can be customized
Lead Time: 20 days after payment	Custom Made: Available
Certification: ISO9001,ROHS,CE	Packing: Carton, accept customize
OEM: Available	MOQ: Any quantity
