MCT20S with shielding Series Common Mode Choke Standard Winding. Compact and light weight. Testing frequency:1KHz/0.25V. Operating temperature:-40°C~+85°C. Rated current rang 1A~5A. SMD toroidal type. Inductance range 1000uH~10000uH
brand:
MCTitem no.:
MCT20S Common Mode Choke 1~5Ashipping port:
ShanghaiHefei Mycoil Technology Co., LTD (MCT) offers different series common mode choke, toroidal inductors, power choke coils. Our common mode chokes mainly used in coupled inductors, isolation transformers, switching power supply, EMI filters, etc.
The materials we use are RoHS and REACH compliant. We have our own quality control department, our engineering and technical personnel can quickly respond to make drawings and samples.
Quick Details
|
|
Brand name: MCT |
|
|
Testing frequency: 1KHz/0.25V |
|
Custom made: Available |
|
Operating temperature:-40°C~+85°C |
|
Logo: Can be customized |
|
Rated current rang1A~5A |
|
Certification: ISO9001,ROHS,CE |
|
Inductance range 1000uH~10000uH |
|
OEM: Available |
|
SMD toroidal type |
|
Shipping: Air, Ship, etc |
|
Lead time: 25 days after payment |
|
MOQ: Any quantity |
Part Information
Product Name: SMD Toroidal Common Mode Choke Inductor Shielding Series Inductor 1-5A
Applications: Switching power supply, Lighting equipment, Data transmission, Wind generators, Frequency Converter.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Advantages:Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Typical electrical parameter
|
MCT Part No. |
Inductance(mH) ±35% |
DC Resistance(Ω)max |
Rated Current(A) |
|
MCTS20-530LF |
0.53 |
0.015 |
7.5 |
|
MCTS20-590LF |
0.59 |
0.012 |
7.0 |
Welcome customized.
Please contact us for more information, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Lily Yu
High Frequency Choke Coil Inductor With Base
Choke mode coil base. 3+3 pins common mode choke base. Base size=10.3mmX6.2mmX7.3mm. Pin pitch=3.5mm. Parallel distance=4.0mm. We manufacture electronic components for customers, special specifications available upon request.
ETD49 Power Transformer Horizontal Coil Former
ETD/ER/EC49 transformer bobbin. 10+10 pin horizontal ETD49 bobbin factory. Bobbin Size=56.0mmX54.4mmX35.35mm. Pin pitch=5.08mm. Parallel Distance=40.64mm. ETD49 high frequency transformer widely used in PCB circuits, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments.
Horizontal High Frequency Transformer EF20 Bobbin
PCB mount transformer design. 4+4 pins coil former. Bobbin Size=20.6mmX20.6mmX13.95mm. Pin pitch=5.0mm. Parallel Distance=15.0mm. EF20 transformer DIP bobbin. We can make new tooling to meet customer's design.
4+4 Pins Power Inductor Base
Power inductor base, 4+4 pins phenolic base. Base Size=12.0mmX11.9mmX5.6mm. Pin distance=2.50mm. Parallel distance=7.7mm. China transformer bobbin factory, PET material electronic inductor base, we manufacture final inductor and transformers.
5A/2.5mA Micro Precision Current Transformer for Energy Meter
High current transformer has small size, high accuracy and good consistency, mainlt used for current and power measurementit. We can provide a typical accuracy of ±0.5%. Isolated withstand voltage:3000V. Insulation Rating Class F. Materials UL94-V0.
EE16 Horizontal Transformer Bobbin With 7+7 Pins Dip Bobbin
7+7 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=2.54mm Parallel Distance=15.24mm Size=19.6mmX16.9mmX13.9mm
EEL10 Electronic Transformer Bobbin, 2+2 Pin and Six Slots Bobbin
2+2 Pins Horizontal EEL10 Bobbin,Phenolic Material Parallel Distance=17.45mm,UL REC:94V-0 Size=19.25mmX9.9mmX7.25mm
Encapsulated Electronic Transformer Case Black Phenolic Transformer Case
Phenolic electronic transformer case. EFD40 transformer case. Case Size=51.6mmX48mmX12.3mm. We can make case tooling. Used in EFD40 high frequency transformer. UL REC:94V-0
EF20 Transformer Two Slots Horizontal Bobbin
Ferrite core transformer bobbin. EF20 horizontal bobbin with two slots. Bobbin Size=20.8mmX20.7mmX14.6mm. Pin pitch=5.0mm. Parallel Distance=15.0mm. EF20 transformer DIP bobbin. We can make new tooling to meet customer's design.
POT23 Power Supply High Frequency Transformer Frame
Current transformer manufacturer. 5+5 pins vertical POT transformer bobbin. Bobbin Size=23.7mmX19.2mmX7.0mm. Parallel Distance=20.2mm. Pin pitch=3.8mm. We are professional transformer bobbin factory, our bobbins are widely used in high frequency line filters, smoothing choke coil, drive transformer, switching power transformers and chokes
ER28 Power Transformer Horizontal Bobbin
ER28/34 core bobbin, horizontal ER28 6+6 pins coil former. Bobbin size=34.9mmX28.0mmX20.9mm, pin distance=5mm, parallel distance=26.0mm. We manufacture ER28 transformers for SMPS, used in DC converters, welcome small order of transformers.
Vertical EE65/32/27 Bobbin For Power Transformer
EE65 electronic transformer bobbin. Single phase EE65/32/27 bobbin. Coil former Size=55.0mmX53.5mmX59.1mm. Parallel Distance=48.0mm.Pin pitch=5.0mm. We supply matched EE65 ferrite cores and transformers. EE65 transformer widely used in UPS, switching mode power supply, telecom communication systems, welding machines and other industries.
