Vertical EQ40 Electronic Transformer Bobbin with 6+0 Pins Bobbin

6+0 pins EQ40 electronic transformer bobbin. DIP bobbin

Vertical type bobbin. We can make bobbin tooling.

Bobbin Size=45.15mmX36.85mmX19.6mm. UL REC:94V-0

  • brand:

    MCT
  • item no.:

    MCT-EQ4001(V6+0P)
  • shipping port:

    Shanghai
contact now
product description

We are professional transformer bobbin manufacturer. Best price 6 pins vertical ER bobbin, good performance and high quality, if you need customized bobbin products, we also can design for you.


Quick Details

Part Number: MCT-EQ4001(V6+0P)

Brand Name: MCT

Material: Phenolic

Color: Black

UL REC: 94V-0

Logo: Can be customized

Lead Time: 20 days after payment

Custom Made: Available

Certification: ISO9001,ROHS,CE

Packing: Carton, accept customize

OEM: Available

MOQ: Any quantity



Part Information

Product Name: Vertical EQ40 Electronic Transformer Bobbin with 6+0 Pins Bobbin

Product Range: Transformers, Inductors, coils, bobbins, ferrite cores.

Applications: switching power supply transformers, toroidal inductors, choke coils, high frequency transformers, filters.

Samples time: 7-10 days for customized parts, 3-5 days for standard parts.

Shipping Details: By air, By ship, etc.

Advantages: Professional transformer winding bobbin factory, complete specifications.

Our Factory is made up of 500 people, huge output can be finished every day.

All materials are environmental protected. We accept custom made and design service.



Any request, please contact us, we will give you fast reply.

Email: sales003@mycoiltech.com

Skype: sales003_125

Contact: Miss Lily Yu



Product Specification

EQ40 transformer bobbin 6 pins vertical bobbin

Request a Free Quote

If you are interested in our products or have any questions, contact us now!
