2+2 Pins UU10.5 Four Slots Filter Inductor Bobbin2+2 Pins Horizontal UU10.5 Bobbin, Phenolic Material UU10.5 Inductor bobbin. Bobbin Size=17.5mmX14.5mmX14mm. Pin Pitch=13mm. Parallel Distance=10mm. We manufacture UU10.5 series inducotrs for customer. UL REC:94V-0 -
Horizontal Bobbin For EE13 Transformer Pin 4+5EE13 high frequency PCB transformer. 5+4 pin horizontal bobbin. Bobbin Size=19.5mmX13mmX9.4mm. Pin Pitch=2.73mm. Parallel distance=15.35mm. DIP transformer phenolic bobbin. -
EF(5+5pin) Horizontal Transformer Ferrite Core BobbinEF20 5+5 pin horizontal bobbin. Customized final transformer. Bobbin Size=22.3mmX22.3mmX18.0mm. Pin pitch=3.8mm. Parallel Distance=15.0mm. PA66-70G33L material transformer bobbin wholesale. -
EF25 High Frequency Power Transformer BobbinSwitching power transformer design. Horizontal bobbin EF25. Bobbin Size=26.0mmX25.6mmX25.1mm. Pin pitch=5.0mm. Parallel Distance=20.0mm. PA66 material transformer bobbin. DIP bobbin. -
High Voltage EE19 Transformer Horizontal BobbinEE19 power transformer bobbin. 4+4 pin horizontal coil former. Parallel distance=12.9mm. Pin Pitch=3.8mm. Bobbin Size=19.0mmX17.0mmX15.6mm. Nylon material transformer bobbin. -
PCB Mounting Encapsulated Transformer BobbinCustom transformer EE19. Horizontal 5+5 pin bobbin. Bobbin Size=19.0mmX17.0mmX14.8mm. Parallel distance=12.6mm. Pin Pitch=5.0mm. Nylon material transformer bobbin. -
EE42 Power High Frequency Horizontal BobbinEE42 switching transformer. 6+6 pins horizontal EE42 coil bobbin. Bobbin Size=46.20mmX41.50mmX42.20mm. Parallel distance=37.55mm. Pin pitch1=7.62mm. Pin pitch2=5.08mm. We can make bobbin tooling. Phenolic material EE42 transformer bobbin. -
ETD39 Switching Transformer Horizontal Coil FormerETD39 high frequency power transformer. 8+8 pins horizontal ETD39 transformer frame. Parallel Distance=38.1mm. Pin distance=5.0mm. Bobbin Size=44.6mmX43.4mmX17.7mm. ETD39 ferrite core transformer has high magnetic flux and low loss magnetic materials, mainly used in PCB circuits, computers, monitors, printer, scanner, duplicator, mobile adapters, other equipment and instruments. -
EVD25 5+5 Pin High Voltage Transformer BobbinEVD25 switching power transformer manufacture. 5+5 pins EVD25 high frequency bobbin. Bobbin Pin Pitch=5.0mm. Parallel Distance=22.5mm. Bobbin Size=25.5mmX25.0mmX18.0mm. EVD25 transformer factoy. Supply matched ferrite cores. -
ETD54 High Voltage Power Transformer 11+11 Pin BobbinPCB mountign ETD54 transformer. 11+11 pin ETD54 horizontal bobbin. Bobbin Size=61.5mmX61.2mmX44.8mm. Pin pitch=5.08mm. Parallel Distance=45.9mm. ETD54 high frequency transformer widely used in fax machines, monitor, scanner, UPS and other equipments. -
EF16 Switching Mode Power Supply Transformer FrameEF16 power transformer bobbin. SMD EF16 horizontal wire slot bobbin. Bobbin size=25.7mmX16.5mmX13.55mm. Pin Pitch=2.54mm. Parallel distance=20.7mm. PM-9630 material EF16 bobbin for transformer. -
ETD29 Switching Power Transformer Horizontal BobbinETD29 transformer ferrite bobbin 6+6 pin. Horizontal type ETD29 single slot coil former. Parallel Distance=22.4mm.Pin pitch=5.08mm. Bobbin Size=33.4mmX29.0mmX26.25mm. We manufacture transformers, mainly used in PCB circuits, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments. -
Flyback Transformer ETD29 Horizontal Coil FormerHigh voltage ETD29 transformer. Ferrite core ETD29 bobbin 6+6 pins single slot bobbin. Parallel Distance=25.6mm.Pin pitch=5.08mm. Bobbin Size=35.2mmX33.5mmX24.9mm. We manufacture transformers, mainly used in PCB circuits, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments. -
ETD54 High Voltage Power Transformer 11+11 Pin BobbinFlyback transformer ETD54. 11+11 pins vertical ETD54 single slot bobbin. Bobbin Size=67.7mmX36.6mmX61.9mm. Pin pitch=5.08mm. Parallel Distance=33.02mm. ETD54 bobbin PBT material, high frequency transformer widely used in charger, power supply, fax machines, monitor, scanner, UPS and other electronic equipments. -
EP10 Network Transformer Horizontal BobbinEP10 power supply transformer bobbin, 4+4 pins EP10 DIP bobbin, horizontal EP10 single slot coil former. Bobbin Size=11.0mmX11.0mmX10.05mm. Pin pitch=2.5mm. Parallel distance=7.5mm. EP10 electronic transformer mainly used for communications and control equipment, switching power supplies, UPS chargers, alarm system and inverters. Custom designed transformers are available. -
EEL25 Power Supply High Frequency Transformer BobbinEEL25 horizontal bobbin 4+6 pins. Seven slots EEL25 transformer frame. Bobbin Size=30.8mmX20.3mmX16.85mm. Parallel distance=28.0mm. Pin pitch=4mm. Accept custom EEL25 injection tooling. EEL25 transformers mainly use for LED driving, power supplies, UPS chargers, mechanical equipment and other industries.
