EF20 Horizontal Flyback Transformer Bobbin 4+4 PinEF20 LED Driver Transformer Bobbin 4+4 pins,Withstands high temperatures during solder dipping and wave soldering without deforming. Offers reliable dielectric properties, moisture and chemical resistance, and minimal dimensional fluctuation during long-term operation. Features precise pin positioning, easy core assembly, and organized winding space. Ideal for LED drivers, smart home power supplies, and compact DC-DC converters, ensuring long-term stable operation. -
EF20 Security Surveillance Horizontal Transformer Bobbins 7+7 PinsCharger and Industrial Control Instrument Transformer Bobbin. PHENOLIC offers excellent temperature resistance, capable of withstanding temperature fluctuations in industrial environments, with high mechanical strength, vibration resistance and creep resistance, ensuring no deformation even after long-term use. Its stable insulation properties effectively isolate circuit interference, enhancing measurement accuracy and operational safety. -
Ariable Frequency Air Conditioner Switching Power Supply Transformer BobbinServo motor drive transformer bobbin,Made of PHENOLIC material, it can withstand a high temperature of 370℃ and resist the temperature rise of EF32 transformers during high-frequency operation. It has low dielectric loss, stable insulation performance in high-frequency circuits, and a dielectric strength of up to 10KV/mm, which can avoid the risk of winding breakdown. The fire resistance rating reaches 94V-0, making it suitable for the harsh industrial scenarios of high temperature and high load. -
Drone EF32 Drive Transformer Bobbin 7+7 PinsThe smart home power switch transformer bobbin is made of nylon and is renowned for its high toughness, capable of withstanding mechanical shocks during the assembly and transportation of EF32 frames. Its surface is smooth, facilitating automatic winding. It has a high injection molding efficiency and can meet the mass production requirements of smart home devices. Withstand voltage up to 27 -
5G Micro Communication Module Vertical Transformer Bobbin 5+5 pinsThe small security detector transformer bobbin is designed for wireless detectors. The EF16 has the advantages of low power consumption (long battery life) and high-frequency adaptive transmission. Youdaoplaceholder0 dust-resistant, high and low temperature resistant, suitable for outdoor environments, ensuring 24-hour stable monitoring of the detector. -
EF20 Motorcycle Power Drive Module Horizontal Coil Former 4+4 pinsThe portable water quality testing pen collar transformer bobbin powers the testing pen. The E20 has the advantages of miniaturization (integrated pen body) and efficient conversion. The T375HF has a high dielectric strength and is resistant to water splashes, preventing water splashes from causing circuit leakage during detection and ensuring detection safety. -
EF16 Automotive Electronic Sensor Horizontal Transformer Frame 4+4 PinsSmart home central control module transformer bobbin , to power the mini central control, the EF16 has the advantages of wide voltage input (100-240V) and low noise. Youdaoplaceholder0 has excellent insulation resistance, which can reduce the interference of central control signals and make the control of lights and curtains smoother -
EF16 Notebook Peripheral Horizontal Transformer Frame 4+5 PinsThe EF16 is a vehicle-mounted USB small module transformer bobbin, which converts 12V to 5V for mobile phone charging. Its advantages include fast high-frequency response and shock resistance.PM-9820 is oil-resistant and dimensionally stable, making it suitable for complex automotive working conditions and preventing unstable power supply to modules due to oil stains or vibrations. -
Small Switching Power Supply Horizontal Transformer Bobbin 4+4 PinsThe smart wearable charger transformer bobbin EF16 is compatible with 4-12W fast charging for wristbands and headphones. Its advantages include miniaturization and easy integration, as well as high frequency (20kHz-500kHz) and low power consumption (efficiency ≥93%). PHENOLIC is resistant to tin immersion at 400℃, has a dielectric strength of 11kV/mm, and is capable of preventing high-temperature leakage during charging, ensuring safe use. -
Sensor EF25 Horizontal Transformer Bobbin 4+4 pinsAudio multi slots transformer EF25 horizontal bobbin ,4+4 pins multi grooves bobbin. EF25 Coil former size=25.40mmX24.30mmX20.85mm, pin distance=5.00mm.Pin row distance=20.00mm, We have a professional design team capable of providing tailored customization services, covering current transformers, common mode inductors, high frequency transformers, potted transformers, and more. -
Switch High Frequency Vertical Transformer Bobbin EF25 5+5 PinsHot sale product EF25 Remote control transformer bobbin 5+5 pins, with a bobbin size of 17.00mm × 25.80mm × 26.00mm,Pin distance=5.00mm,Pin row distance=12.60mm,We have a professional design team capable of providing tailored customization services, covering current transformers, common mode inductors, high-frequency transformers, potted transformers, and more. -
Vertical Bobbin for Fower Switch Transformer EF20 3+3 PinsHot sale product EF20 switch power supply transformer bobbin 3+3 pins, with a bobbin size of 20.10mm × 14.00mm × 13.20mm,Our EF series transformers are mainly used in the instrumentation industry, industrial automation industry, home appliance industry, monitoring equipment industry, lighting equipment industry, power supply industry, etc. -
EF20 Bobbin 3+3 Pins Vertical for Electronic TransformerThe latest mold product EF20 Vertical Transformer bobbin 3+3 pins, with a bobbin size of 18.9mm × 14.0mm × 13.2mm, is made of Hfenolc and has good insulation, high temperature resistance, flame retardancy, high bonding strength, low curing shrinkage rate, excellent insulation performance, and chemical corrosion resistance.In addition, we support small batch orders. If you have any questions, please feel free to contact us at any time. We have professional engineers to answer your questions -
EF20 Horizontal Multi Slot Transformer Bobbin 4+4 PinsEF20 multi slot power transformer bobbin is a very popular product in our factory, 5+5 pins EF20 Vertical bobbin,bobbin former size=18.2mmX19.9X20.8mm.We accept custom orders for high frequency transformers, inductors, current transformers, etc. -
EF20 5+5 Pins Vertical Bobbin for Electronic TransformerEF20 household appliance transformer bobbin is a very popular product in our factory, 5+5 pins EF20 vertical coil former. Bobbin size=22mmX13.8X23.4mm. We accept custom orders for high frequency transformers, inductors, current transformers, etc. -
EF20 Switching Power Supply Transformer Frame 5+7 PinsEF20 high frequency bobbin, 5+7 pins EF20 horizontal bobbin. Coil former size=27.5mmX24.8mmX18.0mm, parallel distance=20.32mm, pin pitch/distance 1 =2.5mm. Pin pitch/distance 2=5.08mm. This is our latest best selling product that supports small batch customization. We can also custom transformer related products. -
EF16 PCB Mounting Transformer Horizontal Bobbin4+4 pins EF16 coil former. EF16 ferrite core bobbin, parallel distance=15.05mm. Pin pitch=3.80mm. Bobbin size=21.85mmX18.7mmX16.85mm. EF16 electronic transformers are widely used in electrical equipment, household applications, medical equipment, computers, switching power supplies, communication equipment, power component, vehicle electronic equipment. -
EF16 High Power Transformer Bobbin 4+4 PinsPower transformer frame, 4+4 pins EF16 horizontal bobbin. Row distance=17.78mm. Pin pitch=5.0mm. Bobbin size=21.1mmX18.3mmX15.0mm. Phenolic material EF16 transformer bobbin, electronic transformers are widely used in electrical equipment, household applications, medical equipment, computers, switching power supplies, communication equipment, power component, vehicle electronic equipment. -
EF20 High Voltage Transformer Bobbin 4+4PinsEF20 SMPS transformer bobbin, 4+4 pins horizontal EF20 transformer frame, phenolic material EF20 bobbin. Pin pitch=5.0mm, Bobbin Size=20.55mmX20.0mmX15.65mm. Parallel distance=15.0mm. We manufacture final inductors and transformers, custom design and OEM transformers also acceptable. -
EF20 High Frequency Transformer Horizontal BobbinEF20 power transformer bobbin, 4+4 pins horizontal EF20 transformer bobbin, phenolic material EF20 bobbin. Pin pitch=5.0mm, Bobbin Size=20.0mmX19.8mmX15.50mm. Parallel distance=15.0mm. We manufacture final transformers, custom design and OEM transformers also acceptable. -
EF20 Main Power Supply Transformer Vertical BobbinEF20 DIP coil former, 5+5 pins vertical EF20 transformer frame, phenolic material EF20 bobbin. Pin pitch=3.8mm, Bobbin Size=22.0mmX13.5mmX21.10mm. Parallel distance=10.10mm. We manufacture final transformers, custom design and OEM transformers also acceptable. -
High Frequency Transformer EF12.6 Horizontal BobbinEF12.6 horizontal coil bobbin, 5+5 pins EF12.6 ferrite core bobbin. Row distance=15.4mm. Bobbin Size=19.5mmX16.3mmX9.4mm. Pin pitch=3.5mm. EF12.6 power transformer widely used for power supply, computers, ultrasonic level sensors, electrical equipment, medical equipment, communication equipment, power supplies, vehicle electronic equipment. -
EF20 Switching Power Supply Transformer Horizontal BobbinEF20 horizontal coil former, DIP pin EF20 bobbin 5+5 pins. Bobbin Size=24.0mmX21.0mmX16.6mm. Pin pitch=3.75mm, Parallel distance=20.0mm. Phenolic material EF20 transformer frame. -
EF20 Power Supply Transformer Horizontal BobbinEF20 horizontal coil former, 5+5 pins though hole EF20 bobbin. Bobbin Size=20.25mmX20.0mmX17.8mm. Pin pitch=3.8mm, Parallel distance=15.0mm. We are bobbin EF20 bobbin factory, supply EF20 soft cores PC40 PC44 PC95 material. -
EF20 High Frequency Vertical Transformer BobbinThrough hole EF20 bobbin, 5+5 pins vertical EF20 coil bobbin. Pin pitch=3.81mm, Bobbin Size=22.0mmX13.9mmX19.8mm. Parallel distance=10.16mm. PA66/PET material EF20 coil former, we manufacture final transformers, custom design and OEM also acceptable. -
Power Transformer EF20 Vertical BobbinVertical EF20 DIP bobbin, 5+5 pins single slot EF20 coil former. Pin pitch=3.80mm, Bobbin Size=22.0mmX13.7mmX20.1mm. Parallel distance=10.0mm. We are transformer bobbin factory. We make new bobbin tooling. -
EF20 High Voltage Transformer Horizontal FrameEF20 PCB mounting transformer, single slot EF20 dip bobbin 5+5 pins. Bobbin Size=21.8mmX21.2mmX16.5mm. Pin pitch=3.8mm, Parallel distance=15.4mm. Phenolic material EF20 coil former. We make new bobbin tooling to meet size requirement, OEM/ODM transformer also acceptable. -
EF25 High Voltage Transformer Bobbin 5+5 PinsEF25 through hole bobbin. EF25 transformer 5+5 pins bobbin. Parallel Distance=20.50mm. Pin distance=5.0mm. Bobbin Size=27.0mmX25.2mmX21.7mm. We accept custom designed EF25 electronic transformer, samples can be sent for prototype testing. -
EF25 Horizontal Flyback Transformer Frame7+7 pins EF25 coil former, horizontal EF25 transformer bobbin. Parallel Distance=25.40mm. Pin distance=3.80mm. Bobbin Size=30.6mmX26.0mmX19.3mm. For special size bobbin, we can make new tooling to meet customer's requirement.
