EE28 Transformer bobbin for the power supply module of the switching motor

EE28 automated PLC transformer bobbin . Our product is made of PM9823 material, featuring a low dielectric constant and tangent of dielectric loss Angle. At a high frequency of 1MHz, the dielectric constant of PM9823 is approximately 2.6-2.8, and the dielectric loss tangent (tanδ) is ≤0.002, which is much lower than that of traditional phenolic resin (dielectric constant 3.5-4.5) or common nylon (dielectric constant 3.0-3.5). This means that the material has a "small hindrance effect" on the electric field, which can reduce signal loss and heat generation during the operation of the transformer, especially suitable for high-frequency transformers (such as switching power supply transformers). High arc resistance and dielectric strength: The arc resistance time of PM9823 can reach over 120 seconds (UL94 standard), and its dielectric strength is ≥18kV/mm. It can withstand the instantaneous high-voltage impact during the operation of the transformer and avoid short-circuit faults caused by "insulation breakdown". Meanwhile, the material is less likely to form a carbonized layer under the action of an electric arc (carbonization will reduce insulation), and its insulation performance deteriorates slowly after long-term use.

product origin:
China
brand:
MCT
item no.:
MCT-2882

contact now

product description

EE28 Smart Home Transformer bobbin Vertical 5+5 pins，This product features a variety of material selection characteristics. The modified polyphenylene ether itself has an extremely low water absorption rate (≤0.05%, 24-hour soaking), which is far superior to nylon 66 (water absorption rate 1.5%). Low hygroscopicity means that the material will not "get damp and conduct electricity" due to changes in environmental humidity, and can maintain stable insulation performance, making it particularly suitable for humid environments (such as transformers in industrial control cabinets).

Production Specification

EE28 Iot sensor transformer bobbin

Email: sales008@mycoiltech.com

Whats app ID: +86 18788862885

Name：Alex~Mycoiltech
