Power Supply Transformer Bobbin EF25 Horizontal 4+4 PinEF25 horizontal transformer bobbin. 4+4 pins EF25 coil former. Bobbin Size=24.4mmX17.5mmX18.8mm. Parallel Distance=21.7mm. Pin pitch=4.7mm. PA66 material bobbin. DIP transformer bobbin. -
High Voltage Transformer EF25 Bobbin 5+5 Pins Horizontal BobbinEF25 5+5 pins horizontal bobbin. EF25 single slot bobbin. Bobbin Size=25.1mmX21.6mmX21.7mm. Parallel Distance=22.86mm. Pin pitch1=5.08mm. Pin pitch2=4mm. Phenolic material bobbin. DIP transformer bobbin. -
EF25 Power Charge Transformer 4+4 Pin Horizontal BobbinEF25 ferrite core transformer bobbin. 4+4 pins horizontal EF25 coil former. Bobbin Size=24.3mmX17.5mmX21.8mm. Parallel Distance=21.5mm. Pin pitch=4.7mm. PA66 material bobbin. DIP transformer bobbin.
-
EF25 Horizontal 5+5 Pin Transformer Bobbin With Three SlotsMulti section transformer bobbin EF25. 5+5 pins horizontal EF25 coil former. Bobbin Size=25.1mmX21.6mmX17.35mm. Parallel Distance=22.86mm. Pin pitch1=3.81mm. Pin pitch2=5.08mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 Transformer Ferrite Core Horizontal Bobbin Pin 4+4EF25 PC40 ferrite core bobbin. 4+4 pins horizontal EF25 coil former. Bobbin Size=28.2mmX17.5mmX22.58mm. Parallel Distance=21.7mm. Pin pitch=4.7mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 5+5 Pin Horizontal Bobbin For High Frequency TransformerManufacture EF25 horizontal bobbin. EF25 5+5 pins transformer bobbin. Bobbin Size=25.9mmX25mmX22.2mm. Parallel Distance=20mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 Soft Ferrite Core Bobbin Horizontal 5+5 PinEF25 5+5 pin horizontal bobbin. EF25 ferrite core transformer bobbin. Bobbin Size=25.9mmX25mmX21.7mm. Parallel Distance=20mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 Horizontal Bobbin 5+5 Pin With Three SlotsMulti section EF25 bobbin. Horizontal EF25 transformer bobbin. Bobbin Size=25.8mmX25.1mmX21.7mm. Parallel Distance=20mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
Double Slots EF25 Bobbin 3+3 Pin Horizontal BobbinEF25 3+3pin horizontal bobbin. Double slots EF25 transformer bobbin. Bobbin Size=21mmX18.2mmX21mm. Parallel Distance=15.5mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 4+4 Pin Horizontal Transformer Bobbin Double SlotsEF25 horizontal two slots bobbin. 4+4 pins EF25 transformer bobbin. Bobbin Size=25.7mmX25.6mmX20.5mm. Parallel Distance=20mm. Pin pitch=5mm. Phenolic material bobbin. DIP transformer bobbin. -
EF25 Horizontal 9+9 Pin Coil Former For TransformerEF25 transformer horizontal bobbin. EF25 9+9 pin transformer bobbin. Bobbin Size=26mmX26mmX19.5mm. Parallel Distance=20.32mm. Pin pitch=2.54mm. Phenolic material bobbin. DIP transformer bobbin. -
EF25 High Frequency Transformer Vertical Bobbin Pin 4+4EF25 high frequency transformer. EF25 vertical bobbin 4+4 pins. Size=24.1mmX22.5mmX26.5mm. Pin pitch=5.0mm. Parallel Distance=17.5mm. PA66 material transformer bobbin. DIP transformer bobbin. -
Transformer Bobbin EF25 Pin 5+5 With Two SlotsLead free EF25 high frequency bobbin. Pin pitch=5.08mm. EF25 two slots vertical bobbin. Parallel Distance=12.75mm. Size=27.0mmX19.0mmX26.0mm. PA66 material transformer bobbin. DIP transformer bobbin. -
EF25 Horizontal 9+9 Pin Coil Former For TransformerPower transformer EF25 bobbin. EF25 horizontal bobbin 9+9 pin. Bobbin Size=26.0mmX26.0mmX19.5mm. Parallel Distance=20.32mm. Pin pitch=2.54mm. Phenolic material bobbin. DIP transformer bobbin. -
EF25 4+4 Pin Horizontal Transformer Ferrite Core Bobbin4+4 pin EF25 horizontal bobbin. EF25 high frequency transformer. Bobbin Size=25.7mmX22.5mmX20.5mm. Parallel Distance=20mm. Pin pitch=5.0mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 Soft Ferrite Core Horizontal Bobbin Pin 5+5EF25 high voltage bobbin. EF25 horizontal winding bobbin. Bobbin Size=26.0mmX25.1mmX20.0mm. Parallel Distance=20mm. Pin pitch=4.0mm. Phenolic material bobbin. DIP transformer bobbin. -
EF25 High Frequency Coil Bobbin Horizontal 5+5 PinCustom made electronic transformer EF25. High frequency bobbin. Bobbin Size=27.8mmX27.2mmX20.5mm. Parallel Distance=20.5mm. Pin pitch=5.0mm. EF25 horizontal coil bobbin. Phenolic material bobbin. DIP transformer bobbin. -
Transformer Bobbin EF25 Pin 6+7 HorizontalEF25 ferrite core bobbin. L pin coil former. Bobbin Size=33.4mmX26.8mmX19.0mm. Pin pitch=4.5mm. Parallel Distance=22.0mm. PA66 material transformer bobbin. DIP type winding bobbin. -
EF25 Horizontal Wire Bobbin 4+4 Pin For Transformer4+4 pin EF25 coil former. PC40 ferrite core. Bobbin Size=22.8mmX17.6mmX20.0mm. Pin pitch=4.7mm. Parallel Distance=20.0mm. PA66 material transformer bobbin. L pin winding bobbin. -
Transformer EF25 Ferrite Core Four Slots BobbinEF(4+4pin) horizontal bobbin. Multi section coil former. Bobbin Size=26.2mmX25.4mmX21.0mm. Pin pitch=5.0mm. Parallel Distance=19.9mm. PA66 material transformer bobbin. DIP bobbin. -
EF25 DIP Horizontal High Frequency TransformerEF25 PC40 material core. Horizontal EF25 bobbin. Bobbin Size=26.2mmX25.4mmX21.5mm. Pin pitch=5.0mm. Parallel Distance=19.9mm. PET transformer bobbin. DIP bobbin. -
SMPS Power Transformer EF25 Bobbin VerticalTransformer bobbin for surface mounting. Horizontal and vertical shape. Bobbin Size=42.0mmX27.0mmX16.8mm. Pin pitch=4.5mm. Parallel Distance=37.0mm. Phenolic material transformer bobbin. L pin bobbin. -
EF25 Vertical Bobbin For Step Down TransformerPower transformer in horizontal and vertical type. EF25 coil former 5+5 pin. Bobbin Size=24.0mmX17.0mmX24.4mm. Pin pitch=5.0mm. Parallel Distance=12.5mm. Phenolic material transformer bobbin. DIP transformer bobbin. -
EF25 High Voltage Transformer Bobbin 5+5 PinsEF25 through hole bobbin. EF25 transformer 5+5 pins bobbin. Parallel Distance=20.50mm. Pin distance=5.0mm. Bobbin Size=27.0mmX25.2mmX21.7mm. We accept custom designed EF25 electronic transformer, samples can be sent for prototype testing.
