EF20 ferrite core bobbin. Transformer bobbin with 3+3 pin. Bobbin Size=14.7mmX13.2mmX17.9mm. Pin pitch=5.0mm. Parallel Distance=12.0mm. DIP transformer bobbin. We can make new tooling to meet customer's design.
product origin:
Chinabrand:
MCTitem no.:
MCT-EF2093shipping port:
Shanghaipayment:
T/T in advanceprice range:
1000-5000/0.064$China transformer vertical bobbin EF20, mainly used in high frequency transformers, power supply transformers, and other small electronic transformers.
Quick Details
|
Part No: MCT-EF2093 |
Brand Name: MCT |
|
Material: PBT |
Color: Black |
|
UL REC: 94V-0 |
Logo: Can be customized |
|
Lead Time: 20 days after payment |
Custom Made: Available |
|
Certification: ISO9001,ROHS,CE |
Packing: Carton, accept customize |
|
OEM: Available |
MOQ: Any quantity |
Part Information
Product Name: High Power Transformer EF20 Vertical Bobbin
Main Parts: Transformers, Inductors, coils, bobbins, ferrite cores.
Lead Time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: We use TNT/UPS/DHL/FedEx, etc air shipping ways. Also by ship, and other ways.
Product Specification
Any request, welcome here, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: live:sales003_125
Contact: Miss Lily Yu
