brand:
MCTitem no.:
UU,UF Series Ferrite Coreshipping port:
ShanghaiQuick Details
|
Part Number: UF Series Ferrite Core |
Brand Name: MCT |
|
Material: Mn-Zn/Ni-Zn ferrite core |
Logo: Can be customized |
|
Type: Power core/High permeability core |
OEM: Available |
|
Applications: Split core current transformers,output transformers,choke coils |
MOQ: Any quantity |
|
Packing: Carton,can be customized |
Custom Made: Available |
|
Lead Time: 25 days after payment |
Certification: ISO9001,ROHS,CE |
Part Information
Product Name: M10P/M7P/M5P/MP4 Material UF Electronic Transformer Ferrite Core
Products Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: Filter common mode transformers. Line transformers, liner filters. Color TV sets. Inverter welding machine. Plating Power Supply. Computers, monitors and other electronic equipment.
Advantages: Our Factory is made up of 500 people, huge output can be finished every day.
We have a technical team consist of 5 experienced engineers.
All materials are environmental protected. We accept custom made and design service.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Shipping Details: By air, By ship, etc.
Product Details
|
TYPE |
Dimension:mm |
Weight:g |
|||||
|
A |
B |
C |
D |
E |
F |
||
|
UF9.8 |
9.8±0.2 |
14.2±0.2 |
2.7±0.2 |
4.2±0.2 |
2.8±0.1 |
8.4±0.3 |
1.3 |
|
UF10.3 |
10.35max |
15.0±0.3 |
2.93±0.12 |
4.05min |
2.95±0.1 |
8.6+0.7 |
1.5 |
|
UF10.5 |
10.5±0.3 |
15.6±0.4 |
5.3±0.15 |
5.5±0.3 |
2.5±0.1 |
10.6±0.3 |
2.5 |
|
UF15 |
15.2±0.7 |
23.4-0.2 |
6.7-0.5 |
5.2±0.35 |
5.2±0.2 |
11.4+1.4 |
8.0 |
|
UF15.7 |
15.7±0.2 |
19.6±0.3 |
5.9±0.15 |
6.7±0.2 |
4.5±0.2 |
12.0±0.2 |
6.7 |
|
UF16 |
16.0±0.2 |
20.0±0.4 |
6.0±0.15 |
7.0-0.3 |
4.5±0.2 |
12.0±0.2 |
6.9 |
|
UF18 |
18.4+0.5 |
26.1±0.4 |
6.2±0.15 |
6.0+0.4 |
6.2+0.4 |
13.5+0.6 |
11.8 |
|
UF19 |
19.0±0.7 |
26.0±1.0 |
6.0±0.15 |
8.5±0.5 |
4.5±0.2 |
19.4±0.7 |
8.5 |
|
UF21 |
20.7±0.8 |
31.2±0.6 |
7.45±0.2 |
6.3±0.3 |
7.25±0.2 |
16.6±0.4 |
18.0 |
|
TYPE |
Effective parameter |
AL（nH/N2）（AL±25%） |
||||||
|
C1 (mm-1) |
Ae (mm2) |
Le (mm) |
Ve (mm3) |
MP4 |
M5P |
M7P |
M10P |
|
|
UF9.8 |
4.46 |
7.66 |
34.2 |
261.5 |
450 |
980 |
1200 |
2500 |
|
UF10.3 |
4.13 |
8.63 |
35.7 |
308 |
|
|
920 |
|
|
UF10.5 |
3.02 |
13.3 |
40.0 |
530.7 |
640 |
1400 |
1700 |
2500 |
|
UF15 |
1.55 |
32.6 |
50.5 |
1647 |
|
|
3000 |
|
|
UF15.7 |
2.05 |
24.5 |
50.3 |
1232 |
|
2000 |
3000 |
3300 |
|
UF16 |
1.97 |
25.9 |
51.0 |
1321 |
|
|
3300 |
|
|
UF18 |
1.55 |
38.4 |
59.4 |
2284 |
|
|
4400 |
|
|
UF19 |
2.64 |
25.0 |
66.0 |
1652 |
|
|
1870 |
|
|
UF21 |
1.27 |
54.0 |
68.6 |
3700 |
|
4380 |
|
|
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily
