4+2 Pins EE19 Horizontal Coil Former for High Frequency TransformerEE19 single slot transformer bobbin. Phenolic bobbin. Pin Pitch=5mm. 4+2 pins EE19 coil former. Bobbin Size=21.3mmX14mmX16mm. UL REC: 94V-0 -
EPC19 Coil Former for High Frequency Transformer 5+6 Pin Horizontal BobbinHorizontal EPC19 ferrite core bobbin. EPC19 5+6 pin electronic transformer bobbin. Parallel Distance=16mm. Pin Pitch=2.5mm. Bobbin Size=18.5mmX15mmX11.1mm. Phenolic material transformer Bobbin. DIP transformer bobbin. UL REC:94V-0. -
EL19 Vertical High Frequency Transformer Bobbin 4+6 Pin Coil Former4+6 pin EL19 transformer bobbin. Vertical type bobbin. Parallel distance=12mm. Pin Pitch1=2.7mm. Pin Pitch2=3.5mm. Dip bobbin. Bobbin Size=17.7mmX15.9mmX29.2mm. UL REC: 94V-0 -
5+5 Pin Single Slot EL19 High Frequency Bobbin Vertical Winding BobbinEL19 5+5 pin transformer bobbin. Vertical type transformer bobbin. Parallel distance=12mm. Pin Pitch=4mm. Phenolic bobbin. Dip bobbin. Bobbin Size=22.5mmX15.8mmX29.2mm. UL REC: 94V-0 -
EL19 4+6 Pin Transformer Bobbin Vertical Type Single Slot Coil BobbinEL19 vertical coil former. 4+6 pin transformer bobbin. Phenolic material transformer bobbin. Parallel distance=10.9mm. Pin Pitch1=3.5mm. Pin Pitch2=3.5mm. Dip bobbin. Bobbin Size=17.8mmX16.3mmX29.3mm. UL REC: 94V-0 -
EE19 Vertical High Frequency 4+3 Pin Bobbin For Transformer Ferrite Core3+4 pin EE19 coil former. Vertical type coil former. 70G33L material bobbin. Pin Pitch=4mm, Parallel Distance=15mm. DIP bobbin. Bobbin Size=14.5mmX14.2mmX16.4mm. UL REC:94V-0. -
EE19 PCB Mounting Transformer Bobbin 5+2 Pins Horizontal Coil FormerEE19 5+2 pin transformer bobbin. EE19 horizontal winding bobbin. Phenolic material bobbin. Pin Pitch=3mm, Parallel Distance=18.4mm. DIP bobbin. Bobbin Size=22.55mmX19.2mmX13.7mm. UL REC:94V-0. -
EE19 Vertical Transformer Bobbin Pin 4+6 High Frequency Coil Bobbin4+6 pin EE19 transformer bobbin. Vertical type coil former. Phenolic material bobbin. Pin Pitch1=2.8mm. Pin Pitch2=3.5mm. Parallel Distance=12mm. DIP bobbin. Bobbin Size=16.2mmX13.8mmX30.65mm. UL REC:94V-0. -
EE19 Vertical Flyback Transformer Bobbin 3+4 Pin Coil FormerEE19 coil former 3+4 pin. Vertical type winding bobbin. Phenolic material bobbin. Pin Pitch=4mm, Parallel Distance=11mm. DIP bobbin. Bobbin Size=14.7mmX14.2mmX15.3mm. UL REC:94V-0. -
EE19 Vertical Bobbin For Switching Power Transformer Pin 4+6EE19 flyback transformer bobbin. 4+6 pin vertical coil bobbin. Phenolic material bobbin. Pin Pitch1=2.7mm. Pin Pitch2=3.5mm. Parallel Distance=12mm. DIP bobbin. Size=17.7mmX15.6mmX20.8mm. UL REC:94V-0. -
Single Phase EE19 Bobbin 2+2 Pin Power Transformer BobbinEE19 vertical bobbin with 2+2 pin. Single slot transformer bobbin. Phenolic material coil bobbin. Parallel distance=10.5mm. Pin Pitch=9.5mm. Bobbin Size=13.8mmX13.3mmX12.03mm. Dip bobbin. UL REC: 94V-0 -
EE19 Vertical Toroidal Transformer Bobbin with 2+2 PinHigh power EE19 transformer bobbin. 2+2 pin single slot transformer bobbin. Vertical type winding bobbin. Phenolic material coil bobbin. Parallel distance=12.1mm. Pin Pitch=10.1mm. Size=15.35mmX13.5mmX13.75mm. -
EPC25 Horizontal High Frequency Transformer Bobbin Pin 5+6EPC25 5+6 pin coil former. Horizontal EPC25 transformer bobbin. Parallel Distance=20mm. Pin Pitch1=3.7mm. Pin Pitch2=5mm. Bobbin Size=25.5mmX25.15mmX15.6mm. Phenolic material transformer Bobbin. DIP transformer bobbin. UL REC:94V-0. -
EEL25 Horizontal High Frequency Transformer Bakelite Bobbin 7+7 PinEEL25 horizontal bakelite bobbin. High frequency EEL25 coil former. Phenolic bobbin. Parallel distance=27.2mm. Pin pitch=4mm. Bobbin Size=32.8mmX30.9mmX19.9mm. Dip bobbin. We can make bobbin tooling. -
EEL25 Power Transformer Bobbin 7+7 Pin High Frequency Horizontal BobbinEEL25 7+7 pins horizontal bobbin. Phenolic material EEL25 bobbin. Bobbin Size=32.9mmX30.9mmX19.9mm. Parallel distance=27.2mm. Pin pitch=4mm. Dip bobbin. We can make bobbin tooling.
-
EC25 Vertical 5+5 Pin Bobbin For High Frequency TransformerEC25 ferrite core bobbin 5+5 pin. Parallel Distance=14.5mm. Bobbin Size=17.5mmX12.4mmX3.9mm.Vertical type EC25 transformer bobbin. Phenolic material transformer Bobbin. DIP transformer bobbin. UL REC:94V-0. -
ER25 Vertical Single Slot Transformer Bakelite Bobbin 5+3 Pin5+3 pins ER25 transformer bobbin. Phenolic material ER25 coil bobbin. Pin Pitch=3.5mm. Bobbin Size=17.8mmX17mmX8.9mm. Parallel distance=14.5mm. We can make tooling. UL REC:94V-0 -
High Frequency Transformer Bobbin 5+5 Pin Vertical ER25 Coil FormerER25 5+5 pins transformer bobbin. Phenolic material ER25 bobbin. Pin Pitch=5mm. Bobbin Size=24.7mmX22.8mmX16.2mm. Parallel distance=17.5mm. We can make tooling. UL REC:94V-0 -
ER25 Bakelite Transformer Bobbin Vertical Bobbin 3+4 Pin3+4 pin(L pin) ER25 bobbin. ER25 vertical bobbinmade of phenolic material. Bobbin Size=30mmX21.3mmX8.3mm. Pin Pitch1=3.5mm. Pin Pitch2=3.75mm. Parallel distance=24.8mm. We can make tooling. UL REC:94V-0 -
ER25 High Frequency Ferrite Bobbin 5+5 Pin For Power Transformer10 pins ER25 vertical bobbin. ER25 phenolic material bobbin. Bobbin Size=26mmX19.6mmX23.7mm. Parallel distance=15mm. Pin Pitch=5mm. DIP bobbin. We can make tooling. UL REC:94V-0 -
Horizontal EVD25 4+4 Pin Transformer Bobbin Made by Nylon4+4 pin EVD25 ferrite core bobbin. Horizontal type EVD25 transformer bobbin. Bobbin Size=25.8mmX24mmX20mm. Nylon material EVD25 transformer bobbin. Parallel Distance=20mm. Pin pitch=5.0mm. UL REC:94V-0. -
EVD25 Horizontal 10+10 Pin Flyback Power Transformer Bobbin10+10 pin EVD25 bobbin for ferrite core. Basf material EVD25 transformer bobbin. Bobbin Size=37.5mmX27.18mmX11mm. Parallel Distance1=31mm. Parallel Distance2=21mm. Pin pitch=5.0mm. UL REC:94V-0. -
High Frequency Transformer EVD25 Bobbin 10 Pin 5+5 PinsLead free 5+5 pin EVD25 bobbins. Horizontal type EVD25 transformer bobbin. Bobbin Size=33mmX26mmX18.9mm. Phenolic material EVD25 transformer bobbin. Parallel Distance=27mm. Pin pitch=5.0mm. UL REC:94V-0.
-
Common Mode Choke Inductor Bobbin 5+5 Pin EVD25 BobbinEVD25 ferrite fore horizontal bobbin. 5+5 pins EVD25 transformer bobbin. Bobbin Size=26.1mmX25.8mmX19.9mm. Parallel Distance=20mm. Pin pitch=4.0mm. PA66 material EVD25 transformer bobbin. UL REC:94V-0. -
EVD25 Power Supply Transformer Bobbin 4+4 Pin Horizontal BobbinHorizontal EVD25 transformer bobbin pin 4+4. Nylon material EVD25 transformer bobbin. Bobbin Size=25.8mmX24mmX20mm. Parallel Distance=17.4mm. Pin pitch=5.0mm. UL REC:94V-0. -
EE25 Vertical Transformer Bobbin 6+6 Pin Single Slot6+6 pin EE25 vertical coil bobbin. Pin Pitch=4.5mm. Parallel Distance=20.7mm. Bobbin Size=27.3mmX27mmX18.8mm. EE25 PA66 material beige transformer bobbin. DIP transformer bobbin. UL REC:94V-0. -
EFD25 Horizontal High Frequency Transformer Bobbin L PinEFD25 L pin transformer bobbin. EFD25 horizontal transformer bobbin. Pin pitch1=5mm. Pin pitch2=3.5mm. Parallel distance=35mm. Bobbin Size=52mmX25.5mmX15.5mm. Phenolic material transformer bobbin. UL REC:94V-0. -
EFD25 Transformer Bobbin Spacer Made of PA66EFD25 electronic transformer bobbin spacer. Mainly for EFD25 transformer bobbin. Spacer Size=36.5mmX27mmX0.8mm. PA66 material bobbin spacer. UL REC:94V-0. -
EFD25 Horizontal 5+5 Pin Bobbin For High Frequency TransformerEFD25 transformer bobbin 5+5 pin. EFD25 horizontal transformer bobbin. Pin pitch=5mm. Parallel distance=22.5mm. DIP bobbin. Bobbin Size=25.8mmX25mmX15.5mm. Phenolic material transformer bobbin. UL REC:94V-0. -
EFD25 Inductor Bobbin For Power Supply TransformerEFD25 4+4 pin transformer bobbin. EFD25 horizontal transformer bobbin. Pin pitch=5mm. Parallel distance=20mm. DIP bobbin. Bobbin Size=25mmX24.7mmX14.2mm. Phenolic material transformer bobbin. UL REC:94V-0.
