EE22 Switching Power Transformer Vertical BobbinEE22 soft ferrite core bobbin. 5+5 pin vertical version EE22 coil former. Bobbin Size=21.9mmX16.0mmX17.0mm. Parallel Distance=10.4mm. Pin pitch=4.0mm. We have over 10 years in producing and selling bobbins, we have many type bobbin toolings. We also manufacture final high frequency transformers for power supply. -
ER40 High Voltage Frequency Transformer FramePower supply transformer ER40, horizontal transformer coil former. Bobbin size=41.2mmX40.1mmX31.7mm, Parallel Distance=34.8mm. Pin Pitch=5.0mm. Bobbin Size=41.2mmX40.1mmX37.0mm. ER40 phenolic bobbin. Custom made transformer, UL REC:94V-0 -
EL19 High Voltage Transformer 4+6 PinsEEL19 ferrite cores. 4+6 pins vertical bobbin for EL19 transformer. Parallel distance=12.0mm. Pin Pitch1=2.8mm. Pin Pitch2=3.45mm. Dip bobbin. Bobbin Size=17.8mmX16.3mmX20.9mm. Manufacture final EL19 electronic transformer. -
EFD30 High Voltage Transformer FrameEFD30 ferrite cores, 5+7 pins L pin EFD30 horizontal transformer. Parallel Distance=43.8mm. Pin distance=5.0mm. Bobbin Size=55.0mmX30.3mmX13.5mm. EFD30 LED drive transformer accept customzied. We make EFD30 tooling to meet special size. -
Power Transformer EE30 Ferrite BobbinHigh voltage transformer, EE30 7+7 pins horizontal coil bobbin. Parallel Distance=23.0mm. Pin distance=5.0mm. Bobbin Size=35.4mmX33.9mmX22.5mm. EE30 low frequency transformer, we can make samples for prototype testing. -
EPC17 High Frequency Transformer 4+6 pins BobbinHorizontal EPC17 single slot bobbin, 4+6 pins EPC17 coil forme, pin pitch1=2.5mm, pin pitch2=3.7mm, Parallel Distance=15.0mm. Bobbin Size=17.5mmX17.0mmX11.0mm, phenolic material EPC17 transformer bobbin. -
EPC17 SMD Horizontal Transformer BobbinHorizontal SMD EPC17 coil former, 4+5 pins EPC17 single slot transformer, pin pitch1=5.0mm,pin pitch2=3.5mm, Parallel Distance=15.0mm. Bobbin Size=18.5mmX17.3mmX9.5mm, phenolic material EPC17 transformer bobbin. -
PQ32 Flyback Transformer Vertical Bobbin6+6 pins PQ32/30 coil bobbin, PQ32 high frequency transformer. Bobbin Size=34.5mmX33.0mmX30.7mm. Pin pitch=5.0mm, parallel distance=30.0mm, Phenolic PQ32 bobbin for high frequency transformer, accept custom made and OEM service. -
EF25 Horizontal Flyback Transformer Frame7+7 pins EF25 coil former, horizontal EF25 transformer bobbin. Parallel Distance=25.40mm. Pin distance=3.80mm. Bobbin Size=30.6mmX26.0mmX19.3mm. For special size bobbin, we can make new tooling to meet customer's requirement. -
Two Slots Transformer EE35 Bobbin 12 PinsEE35 encapsulated transformer, 6+6 pins EE35 horizontal coil former. Parallel distance=26.5mm. Pin pitch1=5.1mm.Pin pitch2=3.7mm. EE35 transformer bobbin DIP pins, supply EE35/EC35 soft ferrite cores. -
EFD20 High Frequency Coil SMT BobbinEFD20 main power transformer bobbin, SMD EFD20 horizontal coil former. Bobbin size=21.5X20.1mmX20.5mm. Single slot EFD20 bobbin, phenolic material EFD20 bobbin for transformer mainly used for UPS, power supplies, and other equipment, welcome customized EFD20 bobbin tooling. -
EF16 High Power Transformer Bobbin 4+4 PinsPower transformer frame, 4+4 pins EF16 horizontal bobbin. Row distance=17.78mm. Pin pitch=5.0mm. Bobbin size=21.1mmX18.3mmX15.0mm. Phenolic material EF16 transformer bobbin, electronic transformers are widely used in electrical equipment, household applications, medical equipment, computers, switching power supplies, communication equipment, power component, vehicle electronic equipment. -
EF16 PCB Mounting Transformer Horizontal Bobbin4+4 pins EF16 coil former. EF16 ferrite core bobbin, parallel distance=15.05mm. Pin pitch=3.80mm. Bobbin size=21.85mmX18.7mmX16.85mm. EF16 electronic transformers are widely used in electrical equipment, household applications, medical equipment, computers, switching power supplies, communication equipment, power component, vehicle electronic equipment.
