Sendust core/ferrite core toroidal inductor. "RoHS Compliance" product, label outside package. Vertical and horizontal orientations optimize EMI/RFI. Compatible with low cost through-hole assembly.
brand:
MCTitem no.:
MCT-Power Inductor Seriesshipping port:
ShanghaiWe are a factory, specialized in manufacturing coil type product and filters as well(kinds of transformers, chokes, inductors, other accessories) for 10 years in china. If you are looking for high quality toroidal power inductors supplier, welcome to contact us.
Quick Details
Part No: MCT-Power Inductor Series |
Brand name: MCT |
Inductance test: 20KHz/0.1V |
Custom made: Available |
Mounted type: Horizontal, vertical, base |
Logo: Can be customized |
Lead time: 25 days after payment |
Pay terms: T/T |
Packing: Carton, can custom |
MOQ: Any quantity |
Lead time: 25 days after payment |
OEM: Available |
Certification: ISO9001,ROHS,CE |
Shipping: Air, Ship, etc |
|
|
Part Information
Product Name: Toroidal Inductor Ferrite Core Power Inductor
Products Range: Transformers, Inductors, coils, bobbins, ferrite cores.
Applications: High power switch-mode power supplies. Power line filters. High power audio filters. Solar inverter. White goods. Motor drivers.
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Product Specification
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
TEL: +86 551 6619 6829
Powder core toroidal inductor. With high efficiency powder iron core. Vertical and horizontal orientations optimize EMI/RFI. Custom design available. Compatible with low cost through-hole assembly.
6+6 Pins Dip Bobbin,Phenolic Material,UL REC:94V-0 Size=38.5mmX24.3mmX17.8mm
EE25 ferrite core bobbin 4+4 pin. EE25 phenolic material transformer bobbin. Bobbin Size=24.8mmX17.5mmX19.9mm. Pin Pitch=5mm. Parallel Distance=12.5mm. DIP transformer bobbin. UL REC:94V-0.
4+4 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin pitch=2.5mm, Parallel Distance=8mm Size=10.5mmX10.4mmX10mm
4+4 pins horizontal bobbin, EP10 SMT bobbin, double slots coil bobbin, LCP-E4008 Material, Pin Pitch=2.5mm Parallel Distance=10.5mm. UL REC:94V-0. Size=14.6mmX11.5mmX8.9mm.Customized designs are accepted.
EE5.0 transformer iron clips. High frequency transformer for power supply. Filter bobbin EE5.0 clamps for transformer. Clip Size=5.2mmX4.8mmX2.0mm. We accept make bobbin tooling to meet special requirement.
7+7 pins EFD25 coil bobbin. EFD25 horizontal bobbin. Bobbin Size=26.0mmX25.2mmX16.5mm. Pin pitch=5mm. Parallel distance=22.5mm. Phenolic material transformer bobbin. We can make bobbin tooling. UL REC:94V-0.
DR1419 series 10-1000uH DIP type drum core inductor. Drum core inductor mainly used for noise filter,motor controller and switching power supply. It has high power, high saturation current and low impedance. Small mounting space required. Operating temperature range: -25 to +120°C.
7+7 pins horizontal bobbin. Pin Pitch=5.08mm. Bobbin Size=37mmX34.8mmX28mm. Phenolic material transformer bobbins. Parallel Distance=25.4mm. Accept make bobbin tooling. DIP bobbin. UL REC:94V-0.
3+3 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.25mm Parallel Distance=13mm Size=16.5mmX13mmX12mm
Customized EF20 transformer 4+4 pin. Horizontal EF20 coil bobbin. Bobbin Size=20mmX19.5mmX17.5mm. Parallel Distance=15mm. Pin pitch=5mm. Phenolic material transformer bobbin. DIP transformer bobbin.
Horizontal encapsulated common mode choke has excellent frequency characteristics and attenuation characteristics. The selection meets safety specifications. Low leakage flux (magnetic loss). The series inductance range: 10uH-1mH above (differential mode)
