5+5 Pins EE19 Horizontal Transformer Bobbin Phenolic Material5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=11mm Size=19mmX16.5mmX11.7mm -
Vertical Bobbin EE19 Transformer Bobbin Dip Bobbin With 5+5 Pins5+5 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=4mm Parallel Distance=13mm Size=20mmX16.1mmX15.8mm -
EE19 Horizontal Transformer Bobbin Phenolic Material With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3mm Parallel Distance=11mm Size=19mmX16.5mmX11.7mm -
Four Slots EE19 Horizontal Transformer Bobbin Dip Bobbin With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.05mm Parallel Distance=12.6mm Size=19.2mmX17.6mmX12.6mm -
EE19 Horizontal Bobbin Dip Bobbin Phenolic Material With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.05mm Parallel Distance=12.6mm Size=19.2mmX17.6mmX12.6mm -
EE19 Horizontal Transformer Bobbin Dip Bobbin For PCB Mounting Transformer4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.7mm Parallel Distance=12.6mm Size=20.4mmX17mmX16.6mm -
EE19 Horizontal Transformer Bobbin Dip Bobbin Phenolic Material4+4 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=3.7mm Parallel Distance=12.6mm Size=20.4mmX17mmX16.6mm -
EE19 Horizontal Bobbin 5+2 Pins With Five SlotsCustomized EE19 transformer. 5+2 Pins horizontal EE19 bobbin. Multi section bobbin. Bobbin Size=18.0mmX17.4mmX16.0mm. Pin pitch=3.5mm. Bobbin Material: Nylong. We can make bobbin tooling to meet different requirements. ,UL REC:94V-0 -
Horizontal Bobbin EE19 Transformer Bobbin Five Slots5+2 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=13mm Size=19.8mmX18.2mmX16.8mm -
Vertical Bobbin EE19 Transformer Bobbin Phenolic Material4+3 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Parallel Distance=11mm Size=14.5mmX14.18mmX16.5mm -
Vertical Bobbin EE19 Transformer Bobbin With 3+3 Pins4+3 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=4.7mm Parallel Distance=11.3mm Size=14.5mmX14.18mmX15.8mm -
Vertical Bobbin EE19 Transformer Bobbin Phenolic Material3+3 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=5mm Parallel Distance=12.5mm Size=16mmX13mmX10.9mm -
4+4 Pin EE19 Electronic Transformer Bobbin Horizontal Coil Former4+4 pins horizontal coil former. Phenolic material bobbin. Pin Pitch=5mm, Parallel Distance=12.5mm. DIP bobbin. Bobbin Size=19.3mmX17mmX16.2mm. UL REC:94V-0. -
4+6 Pins EE19 Coil Former Double Slots High Frequency Transformer BobbinEE19 flyback transformer bobbin. Parallel Distance=12mm. Pin Pitch1=2.7mm. Pin Pitch2=3.5mm. Bobbin Size=19.2mmX15.4mmX17.7mm. 10 Pins EE19 coil former. DIP transformer bobbin. We have many bobbin toolings, for special size bobbin, we can make new tooling. -
4+2 Pins EE19 Horizontal Coil Former for High Frequency TransformerEE19 single slot transformer bobbin. Phenolic bobbin. Pin Pitch=5mm. 4+2 pins EE19 coil former. Bobbin Size=21.3mmX14mmX16mm. UL REC: 94V-0 -
5+5 Pins EE19 Vertical High Frequency Transformer Bobbin Dip Coil FormerEE19 vertical transformer bobbin. 5+5 pins coil former. Parallel distance=13mm. Pin Pitch=3.8mm. Dip bobbin. Bobbin Size=20mmX16.2mmX22.8mm. UL REC: 94V-0 -
EE19 Coil Former 5+5 Pins Vertical Bobbin Phenolic Winding bobbin5+5 pins EE19 transformer bobbin. Vertical coil former. Parallel distance=12.7mm. Pin Pitch=3.8mm. Dip bobbin. Bobbin Size=20mmX16.5mmX15.7mm. UL REC: 94V-0 -
EE19 5+5 Pins Horizontal Transformer Bobbin for Power TransformerEE19 high frequency transformer bobbin. Horizontal coil former. Parallel distance=24.1mm.Pin Pitch1=3.5mm.Pin Pitch2=4.5mm Bobbin Size=30.1mmX20.8mmX15.5mm. UL REC: 94V-0 -
EE19 Vertical High Power Transformer Bobbin 3+3 Pins Winding BobbinEE19 vertical transformer bobbin. 3+3 pins coil former. Parallel distance=10.5mm.Pin Pitch=4.75mm. Dip bobbin. Bobbin Size=15.5mmX15mmX19.3mm. UL REC: 94V-0 -
EE19 Vertical Type 3+3 Pins High Frequency Transformer Bobbin for Ferrite Core3+3 pin EE19 transformer bobbin. Vertical type bobbin. Parallel distance=12.5mm.Pin Pitch=6.4mm. Dip bobbin. Bobbin Size=18.9mmX18.3mmX18.3mm. UL REC: 94V-0 -
EE19 Multi Section Transformer Bobbin 4+4 Pin Horizontal Winding Bobbin4+4 pin EE19 transformer bobbin. Horizontal type bobbin. Parallel distance=32mm. Pin Pitch=6.4mm. Dip bobbin. Bobbin Size=30.7mmX13.8mmX17.65mm. UL REC: 94V-0 -
SMD EE19 Bobbin Four Slots Transformer Bobbin 4+6 Pin Horizontal Coil FormerFour slots EE19 transformer bobbin. SMD coil bobbin. 4+6 pin horizontal bobbin. Bobbin material: LCP-E4008. Pin Pitch=2.5mm. Parallel Distance=19mm. Bobbin Size=20.5mmX19mmX11.2mm. Customized designs are accepted. -
EE19 Vertical Coil Former 4+4 Pins High Frequency Transformer Bobbin4+4 pin vertical coil former. Phenolic material bobbin. Pin Pitch=5mm, Parallel Distance=15mm. DIP bobbin. Bobbin Size=18.9mmX18.9mmX15.9mm. UL REC:94V-0. -
5+5 Pin EE19 Transformer Bobbin Vertical Coil Former5+5 pin EE19 vertical transformer bobbin. Pet material coil former. Parallel distance=15mm. Pin Pitch=4mm. Bobbin Size=19mmX19mmX15mm. Dip bobbin. UL REC: 94V-0 -
Double Slots EE19 Horizontal Bobbin for High Voltage TransformerEE19 pin 4+4 transformer bobbin. Horizontal type bobbin. Multi section bobbin made of phenolic material. Parallel distance=13mm. Pin Pitch=5mm. Dip bobbin. Bobbin Size=19mmX16mmX15mm. UL REC: 94V-0 -
EE19 Transformer Bakelite Bobbin 5+5 Pin Vertical Coil Bobbin5+5 pin EE19 transformer bobbin. Vertical EE19 bobbin made of FR530 material. Parallel distance=15mm. Pin Pitch=4mm. Bobbin Size=19mmX19mmX15mm. Dip bobbin. UL REC: 94V-0 -
Three Slots EE19 Bobbin High Frequency Horizontal Bobbin 4+4 PinEE19 bakelite transformer bobbin. Multi section transformer bobbin. 4+4 pin orizontal bobbin. Pin Pitch=3.25mm. Dip bobbin. Bobbin Size=38.5mmX20mmX17.6mm. UL REC: 94V-0 -
EE19 Vertical High Frequency 4+3 Pin Bobbin For Transformer Ferrite Core3+4 pin EE19 coil former. Vertical type coil former. 70G33L material bobbin. Pin Pitch=4mm, Parallel Distance=15mm. DIP bobbin. Bobbin Size=14.5mmX14.2mmX16.4mm. UL REC:94V-0. -
High Frequency Horizontal EE19 3+3 Pin Coil FormerDouble slots EE19 transformer bobbin. Horizontal 3+3 pin bobbin made of PBT material. Parallel distance=13mm. Dip bobbin. Bobbin Size=18.8mmX15mmX16.2mm. We can make bobbin tooling. UL REC: 94V-0 -
EE19 Transformer Bobbin for Power Transformer 3+3 Pin Double Slots Coil Former3+3 pin EE19 transformer bobbin. Horizontal winding bobbin. Double slots nylon material bobbin. Parallel distance=12.5mm. Dip bobbin. Bobbin Size=1mmX14.3mmX16.2mm. We can make bobbin tooling. UL REC: 94V-0
