EI19 Vertical High Frequency Bobbin 3+4 Pin For TransformerTransformer vertical bobbin EI19. 3+4 pins coil bobbin. Bobbin Size=38mmX18.1mmX14.2mm. Parallel Distance=33.9mm. Pin pitch1=4.1mm. Pin pitch2=4.6mm. Nylon material transformer bobbin. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI19 High Voltage Transformer Vertical Bobbin 3+3 PinsHigh frequency core bobbin. Vertical EI19 bobbin 3+3 pins. Bobbin Size=15.4mmX13.8mmX14.1mm. Parallel Distance=10.5mm. Transformer phenolic bobbin. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
High Performance Transformer Bobbin EI19 Vertical Bobbin Pin 3+3Lead free transformer bobbin. 3+3 Pins EI19 vertical bobbin. Bobbin Size=15mmX13.8mmX16mm. Parallel Distance=11.3mm. Pin pitch=4.6mm. Transformer phenolic bobbin. DIP transformer bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EF25 Soft Ferrite Core Bobbin Horizontal 5+5 PinEF25 5+5 pin horizontal bobbin. EF25 ferrite core transformer bobbin. Bobbin Size=25.9mmX25mmX21.7mm. Parallel Distance=20mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 Horizontal Bobbin 5+5 Pin With Three SlotsMulti section EF25 bobbin. Horizontal EF25 transformer bobbin. Bobbin Size=25.8mmX25.1mmX21.7mm. Parallel Distance=20mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
Double Slots EF25 Bobbin 3+3 Pin Horizontal BobbinEF25 3+3pin horizontal bobbin. Double slots EF25 transformer bobbin. Bobbin Size=21mmX18.2mmX21mm. Parallel Distance=15.5mm. Pin pitch=5mm. PA66 material bobbin. DIP transformer bobbin. -
EF25 4+4 Pin Horizontal Transformer Bobbin Double SlotsEF25 horizontal two slots bobbin. 4+4 pins EF25 transformer bobbin. Bobbin Size=25.7mmX25.6mmX20.5mm. Parallel Distance=20mm. Pin pitch=5mm. Phenolic material bobbin. DIP transformer bobbin. -
EF25 Horizontal 9+9 Pin Coil Former For TransformerEF25 transformer horizontal bobbin. EF25 9+9 pin transformer bobbin. Bobbin Size=26mmX26mmX19.5mm. Parallel Distance=20.32mm. Pin pitch=2.54mm. Phenolic material bobbin. DIP transformer bobbin. -
Vertical Bobbin EC28 For Electronic Isolation TransformerEC28 ferrite core transformer bobbin. 5+5 pin vertical EC/ER28 coil former. Bobbin Size=25.0mmX22.0mmX19.3mm. Parallel Distance=16.5mm. Pin pitch=5mm. Phenolic material transformer Bobbin. DIP transformer bobbin. UL REC:94V-0. -
EI28 Ferrite Core Bobbin 6+6 Pins Vertical Bobbin6+6 pins EI28 transformer bobbin. Vertical EI28 winding bobbin. Bobbin Size=29.2mmX24.2mmX19.4mm. Pin pitch=5.0mm. Parallel Distance=17.5mm. Transformer phenolic bobbin. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
EI28 Power Transformer Vertical Bobbin Pin 13+13EI28 coil former 26 pins. EI28 vertical transformer bobbin. Bobbin Size=34.1mmX22.1mmX21.5mm. DIP transformer bobbin.Parallel Distance=17.5mm. UL REC:94V-0. We can make new bobbin tooling to meet different requirements. -
High Efficiency Power Transformer ER49 BobbinVertical ER49 bobbin for transformer. 9+9 pins coil former. Bobbin Size=49.00mmX37.00mmX33.8mm. Pin Pitch=5.0mm. Parallel Distance=28.0mm. For final ER49 high frequency transformer, has low magnetism leakage and good operating performance, we can start from samples. -
EI35 Vertical Power Transformer Bobbin Pin 5+5EI35 vertical bobbin for transformer. 5+5 pins horizontal EI35 bobbin. Parallel Distance=20.0mm. Pin Pitch=5.0mm. Bobbin Size=32.0mmX25.6mmX26.0mm. EI35 transformer has small size, high precision and excellent uniformity. We use PCB welding installation method to meet special requirements. -
2+2 Pins Encapsulated Transformer Bobbin CasePower transformer phenolic case. Factory wholesale bobbin plastic case for electronic transformer. Pin pitch=6.1mm. Case Size=8.5mmX8.5mmX6.2mm. Parallel distance=6.7mm. When transformer assembled by bobbin and magnet cores, we use case to cover the transformer. -
Shielded Case For SMD Power Filter InductorPCB mount encapsulated transformer case. Factory customized transformers. Case Size=12.8mmX9.1mmX12.3mm. Pin pitch=10.0mm. Parallel distance=7.6mm. When transformer assembled by bobbin and magnet cores, we use case to cover the transformer. -
PCB Mounting Transformer PBT Material CaseCase for high frequency transformer. Power transformer and inductor manufacture. Phenolic material case for bobbin. Case Size=30.1mmX24.4mmX17.2mm. When transformer assembled by bobbin and magnet cores, we use case to cover the transformer. -
High Voltage Vertical EE33 Transformer Coil FormerEE33 ferrite core bobbin. 6+6 pin EE33 vertical bobbin. Parallel Distance=22.6mm. Pin pitch=5.0mm. Bobbin size=29.0mmX28.2mmX28.2mm. EE series ferrite cores widely used in power transformers and low signal applications, welcome customized transformer and inductors. -
ER28 High Frequency Flyback Transformer BobbinER28 vertical coil former. 5+5 pins without VDE ER28 transformer frame. Supply EC2828 ER28/28 EC28/28 transformer cores. Mainly used for high frequency transformer, with low magnetism leakage and good performance, welcome customized final transformers. -
Switching Power Supply ER28 Vertical Transformer BobbinHigh voltage ER28 transformer. 5+5 pins ER28 transformer bobbin with VDE. Supply EC2828 ER28/28 EC28/28 transformer cores. Mainly used for high frequency transformer, with low magnetism leakage and good performance, welcome customized final transformers. -
ER35 High Voltage Transformer Horizontal BobbinER35/42 7+7 pin horizontal bobbin, single slot ER35 bobbin for high frequency transformer, pin distance=5.0mm, bobbin size=43.5mmX36.0mmX28.8mm, parallel distance=37.0mm. Phenolic material ER35 transformer coil former. We manufacture final electronic transformer for power suppliers, low magnetic leakage and good performance, welcome customized transformers. -
EFD25 Power Supply Transformer 5+7 Pins BobbinCustomized EFD25 transformer, 5+7 pins EFD25 bobbin single slot coil former. Row distance=35.0mm. Pin pitch=5.0mm. Pin pitch2=3.5mm, Bobbin Size=42.0mmX25.5mmX13.5mm. EFD25 high frequency transformers widely used in electrical equipments, DC converters, medical equipments, communication equipments, power supplies, vehicle electronic equipments. -
RM6 Power Transformer Vertical Bobbin 3+3 PinsDouble grooves RM6 coil former, vertical RM6 main power transformer frame. PM9630 material RM6 transformer bobbin. We produce various RM series bobbins, RM6/RM8/RM14, etc bobbins. We make new tooling for special size bobbins. -
High Frequency Transformer LP32 BobbinLP32 horizontal bobbin 4+4 pins, ferrite core for LP32 bobbins. Size=40.4mmX25.0mmX17.6m. Pin pitch=6.35mm, parallel distance=27.94mm, PPS material transformer bobbin for LP32 electronic transformer, we accept custom made bobbins and OEM service. -
ETD29 High Voltage Transformer Vertical BobbinETD29 transformer 14 pins bobbin, vertical ETD29 bobbin for EC29 cores. Bobbin Size=33.6mmX23.8mmX39.1mm. Pin pitch=5.0mm, Parallel distance=20.0mm. We design various ETD29 ETD39 ETD49 series transformers, provide samples for prototype testing. -
ETD29 High Frequency Flyback Transformer FrameETD29 ferrite transformer bobbin, 6+6 pins vertical ETD29 coil former. Bobbin Size=35.2mmX23.6mmX39.6mm. Pin pitch=5.0mm, Parallel distance=20.0mm. PET material ETD29 bobbins. We produce ETD29 ETD39 ETD49 series transformers, provide samples for prototype testing. -
ER35 High Frequency Power Transformer FrameER35/26 vertical bobbin 15+15 pins, pin distance=2.5mm, bobbin size=40.0mmX27.7mmX27.8mm, parallel distance=22.5mm. Phenolic material ER35 electronic transformer bobbin. We manufacture final electronic transformer for power suppliers, low magnetic leakage and good performance, welcome customized transformers. -
PQ32 Flyback Transformer Vertical Bobbin6+6 pins PQ32/30 coil bobbin, PQ32 high frequency transformer. Bobbin Size=34.5mmX33.0mmX30.7mm. Pin pitch=5.0mm, parallel distance=30.0mm, Phenolic PQ32 bobbin for high frequency transformer, accept custom made and OEM service. -
EL16 Multi Section Horizontal Transformer FrameEL16 horizontal coil former, 3+3+2pins six slots EL16 bobbin. Bobbin Size=23.3mmx16.0mmx12.3mm. Pin Pitch1=6.8mm.Pin Pitch2=13.6mm. Parallel Distance=15.6mm. Phenolic material EL16 horizontal transformer bobbin, accept new bobbin tooling. -
High Frequency Transformer EE65 BobbinEE65 horizontal coil former, 8+8 pins ferrite bobbin EE65. Bobbin Size=49.0mmX43.0mmX52.9mm. Parallel Distance=45.0mm. Pin pitch=3.0mm.Pin pitch=5.0mm. We manufacture EE65 power transformers mainly used in power supplies, we can design EE65 transformer to meet customers requirement. -
EE65 Main Power Transformer Horizontal BobbinEE65 electronic transformer bobbin, horizontal coil former 8+8 pins. Bobbin Size=56.0mmX44.0mmX53.2mm. Parallel Distance=45.0mm. Pin pitch=5.0mm. We manufacture and design EE65 high voltage transformers for customers.
