Flexible Switching Mode Power Supply Transformer ER9.5 SMD Transformer

Customized ER9.5 switching mode power supply transformer. SMD ER9.5 coil former with ferrite cores. High permeability and high saturation magnetic flux density. Different circuit will use many possibilities for quick prototyping. We can design to meet different applications.

  • brand:

    MCT
  • item no.:

    Flexible SMPS-Transformer ER9.5
  • shipping port:

    Shanghai
contact now
product description

2018 new design switching mode power supply transformersSMD ER9.5 high frequency transformers, we can design and send samples in 5 days, if you are looking for high quality electronic transformers, welcome to contact us for more information.


Quick Details

Part No: Flexible SMPS-Transformer ER9.5

Brand name: MCT

Insulation test voltage: 1500V

Custom made: Available

Low leakage inductance

Logo: Can be customized

Transformer with multi-winding

Packing: Carton, can custom

Operating temperature -40°C~+125°C

MOQ: Any quantity

Certification: ISO9001,ROHS,CE

OEM: Available

Lead time: 25 days after payment

Shipping: Air, Ship, etc


Part Information

Product Name: Flexible Switching Mode Power Supply Transformer ER9.5

Product Range: Transformers, Inductors, coils, bobbins, ferrite cores.

Applications: Flyback converters. Forward converters. Push-pull converters. Step-Up/Step-down converters. Sepic converters(single ended primary inductor converter)

Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray

Samples time: 7-10 days for customized parts, 3-5 days for standard parts.


Product Specifications

ER9.5 SMD high frequency transformer design

Electrical Data and Part Number(PN)

Lin uH

Lin mA

Lsat in mA

RDC/Ω

PN

1000

25

35

4.7

MCT-ER103


If you have any request, please contact us, we will give you fast reply.

Email: sales003@mycoiltech.com

Skype: sales003_125

Contact: Miss Lily Yu

TEL: +86 551 6619 6829

Request a Free Quote
