Horizontal Bobbin EFD15 Transformer Bobbin With 5+5 Pins5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin pitch=2.5mm, Parallel Distance=17mm Size=14.8mmX14.8mmX7.4mm -
Vetical EE16 4+6 Pin High Frequency TransformerFerrite core EE16 bobbin. 4+6 Pins vertical EE16 bobbin made by phenolic material. Parallel Distance=12.2mm, pin pitch=2.7mm. Bobbin size=17.8mmX16.0mmX30.4mm. We manufacture EE16 electronic transformers for LED light, SMPS, UPS, medical equipments. -
ETD29 Ferrite Core Bobbin For Power Supply Transformer7+7 pins ETD29 vertical bobbin(coil former). Pin Pitch=5mm. Bobbin Size=35mmX23.8mmX39mm. Parallel Distance=20.3mm. Accept make bobbin tooling. DIP bobbin. UL REC:94V-0. -
ETD29 Vertical High Frequency Transformer Bobbin 7+7 PinsETD29 7+7 pins vertical bobbin. Phenolic material ETD series transformer bobbin. Bobbin Size=38.3mmX27mmX42mm. Pin Pitch=5mm. Parallel Distance=22.9mm. We accept make new bobbin tooling. DIP bobbin. UL REC:94V-0. -
ETD29 Power Bobbin For High Frequency TransformerHigh performance ETD29 horizontal bobbin. Pin Pitch=5mm. Bobbin Size=35mmX29.2mmX24.6mm. Phenolic material transformer bobbins. Parallel Distance=25.8mm. Accept make bobbin tooling. DIP bobbin. UL REC:94V-0. -
ETD29 Horizontal Bobbin For PCB Mounting Transformers7+7 pins horizontal bobbin. Pin Pitch=5.08mm. Bobbin Size=37mmX34.8mmX28mm. Phenolic material transformer bobbins. Parallel Distance=25.4mm. Accept make bobbin tooling. DIP bobbin. UL REC:94V-0. -
EF25 Bobbin 5+5 Pin Horizontal Double SlotsHorizontal coil bobbin EF25. Double slots coil former. Bobbin Size=25.8mmX25.2mmX19.2mm. Pin pitch=5.0mm. Parallel Distance=20.0mm. Transformer bobbin with PA66 material. DIP transformer bobbin. -
EF25 Bobbin For Switching Power Supply TransformerFerrite core high frequency transformer bobbin. EF25 single slot coil former. Bobbin Size=26.2mmX26.0mmX19.8mm. Pin pitch=5.0mm. Parallel Distance=20.0mm. PM9820 material transformer bobbin. DIP type winding bobbin. -
Double Slots Ferrite Core Bobbin EF25 Pin 5+5Power supply transformer. EF25 horizontal bobbin. Double slots 5+5 pins. Bobbin Size=26.2mmX26.1mmX19.85mm. Parallel Distance=20.0mm. Pin pitch=5.0mm. Transformer phenolic material bobbin. DIP transformer bobbin. -
EE42 Ferrite Core Switch Power Transformer Vertical BobbinEE42 high frequency transformer. Vertical type EE42 8pin bobbin. Bobbin Size=55.95mmX46.2mmX4.95mm. Pin pitch=5.5mm. We can make bobbin tooling. EE42 electronic transformer can used for electrical equipment, medical equipment, communication equipment, UPS. AC/DC Converter, LED drive and vehicle electronic equipment industry. -
Vertical EE13 High Frequency Power Transformer BobbinEE13 mini electronic drive transformer. EE13 5+5 pin vertical frame. Coil former Size=13.3mmX12.3mmX19.85mm. Parallel Distance=8.5mm.Pin pitch=2.5mm. We supply EE13 PC40 material ferrite cores. Welcome customized EE13 transformer. Used in UPS, switching mode power supply, telecom communication systems, welding machines and other industries. -
EP10 Ferrite Core Transformer ClampsPCB mount transformer EP10 clip, magnetic transformer cores supply. We are China bobbin factory, we produce various bobbins, we can make new tooling to meet special size requirements. RM6 electronnic transformers widely used for PCB circuits, UPS, computers, switching power supplies,TVs, monitor, scanner and other electronics. -
EF16 Switching Mode Power Supply Transformer FrameEF16 power transformer bobbin. SMD EF16 horizontal wire slot bobbin. Bobbin size=25.7mmX16.5mmX13.55mm. Pin Pitch=2.54mm. Parallel distance=20.7mm. PM-9630 material EF16 bobbin for transformer. -
EE80 High Voltage Flyback Transformer BobbinSupply flyback transformer bobbin, EE80 bobbin for electrical transformer. Bobbin Size=81.4mmX56.3mmX62.0mm. We are experienced bobbin factory, we have many bobbin toolings, for special size bobbin, we can make new bobbin tooling. -
EE130 High Power Transformer No Pin BobbinMagnetic core EE130/40 bobbin. Supply matched ferrite cores. Bobbin Size=79.5mmX79.5mmX95.0mm. We are China transformer bobbin factory, we make bobbin tooling to meet special size bobbin requirememnts. -
EE110 Switched Mode Power Supply Transformer FrameFerrit core transformer EE110 coil former. Bobbin Size=84.0mmX73.0mmX81.6mm. PBT material EE110 coil bobbin for transformers, we are ISO9001/2015 certificated transformer bobbin factory, we make bobbin tooling to meet special size bobbin requirememnts. -
PQ26/25 High Frequency Flyback Transformer BobbinFerrite transformer PQ26 bobbin. No pin PQ2625 transformer frame. Bobbin Size=21.2mmX21.2mmX24.4mm. Phenolic PQ26 coil bobbin for high frequency transformer, used in PCB circuits, printers, filters, computers, LED lighting, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments. -
Horizontal ER35/42 Magnetic Core Transformer BobbinEER35 6+6 pin bobbin, high frequency horizontal bobbin. Bobbin size=43.7mmX35.6mmX28.8mm, pin distance=5.33mm, parallel distance=37.0mm. PET material EER35 coil former. We manufacture final electronic transformer for power suppliers, low magnetic leakage and good performance, welcome customized transformers. -
EF16 High Frequency Transformer SMD Coil BobbinHorizontal EF16 core bobbin. SMD EF16 5+5 pins bobbin. Bobbin size=23.5mmX16.0mmX12.7mm. Pin Pitch=3.25mm. Parallel distance=18.3mm. EF16 phenolic material bobbin for transformer. -
EE41 PCB Mounting Transformer Horizontal BobbinEE41 power transformer bobbin. 7+7 pin horizontal EE41 transformer frame. Bobbin Size=33.4mmX27.88mmX28.7mm. Parallel Distance=23.5mm. Pin pitch=5.0mm. China bobbin factory with over 12 years tooling produce, manufacture and OEM electronic transformer and coils. -
EE42 Switching Power Transformer Vertical FrameEE42 coil transformer ferrite. 9+9 pin vertical transformer double slots coil former. Parallel Distance=25.5mm. Bobbin Size=43.5mmX36.8mmX42.4mm. Pin pitch=5.0mm. EE42 electronic transformer, which has high transmission power and low temperature rise,welcome customzied wound components. -
Flyback Transformer ER35 Ferrite Bobbin 8+8 PinsER35 8+8 pin bobbin, high frequency coil former. Bobbin size=42.8mmX40.0mmX29.0mm, pin distance=5.0mm, parallel distance=35.0mm. Phenolic material ER35 transformer coil former. We manufacture final electronic transformer for power suppliers, low magnetic leakage and good performance, welcome customized transformers. -
Vertical PQ35 Flyback Transformer FramePQ35 ferrite transformer, 6+6 pin vertical PQ35/35 coil former. Bobbin Size=39.3mmX34.9mmX36.6mm. Row distance=35.5mm. Pin pitch=5.0mm. Phenolic PQ35 bobbin for high frequency transformer, used in power supplies, printers, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments. -
EF20 Ferrite Transformer Horizontal BobbinEF20 high frequency bobbin, SMPS transformer EF20 coil former 7+8 pins frame. Bobbin Size=24.8mmX20.0mmX20.5mm. Pin pitch=2.5mm, Parallel distance=20.0mm. China EF20 bobbin factory. We made special size bobbin tooling and manufacture final transformer for customer. -
EE16 High Frequency Transformer Horizontal FrameEE16 ferrite core bobbin, 4+4 pin horizontal coil former. Bobbin Size=18.3mmX16.0mmX13.10mm. Pin pitch=3.2mm. Parallel Distance=15.5mm. We produce fianl EE16 power transformers, used in AC/DC inverter or DC/AC converter, power supplies, lighting, UPS, computer equipment, telecom communication systems, welding machines and other industries. -
EE25 High Voltage Transformer Vertical FrameHigh frequency EE25 bobbin, 5+5 pins vertical transformer frame, Bobbin Pin Pitch=5.0mm. Parallel Distance=15.0mm. Bobbin Size=25.0mmX20.0mmX19.4mm. We manufacture EE25 electronic transformer, welcome customized coils. -
SMPS Transformer PQ35/20 Vertical BobbinPQ35 ferrite core bobbin, 6+6 pin vertical PQ35/20 transformer. Bobbin Size=39.1mmX35.2mmX18.4mm. Row distance=35.6mm. Phenolic material PQ35 bobbin for high frequency transformer, used in power supplies, printers, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments. -
EF20 High Power Transformer Horizontal BobbinSwitch mode transformer EF20 bobbin, SMPS transformer EF20 5+5 pins bobbin. PM-9820 material EF20 coil former. Bobbin Size=20.0mmX20.0mmX20.5mm. Pin pitch=3.81mm, Parallel distance=15.24mm. China EF20 bobbin factory. We made special size bobbin tooling and manufacture final transformer for customer. -
EF20 High Power Transformer Horizontal BobbinSwitch mode transformer EF20 bobbin, SMPS transformer EF20 5+5 pins bobbin. PM-9820 material EF20 coil former. Bobbin Size=20.0mmX20.0mmX20.5mm. Pin pitch=3.81mm, Parallel distance=15.24mm. China EF20 bobbin factory. We made special size bobbin tooling and manufacture final transformer for customer. -
EE13 Bobbin For LED Light Power TransformerEE13 switch transformer bobbin. EE13 transformer with low leakage inductance and good performance. Vertical EE13 DIP bobbin. Parallel Distance=8.5mm. Pin pitch=2.5mm. Coil former Size=12.3mmX12.3mmX15.0mm. R&D EE13 electronic transformers, mainly used for power supplies, lighting, UPS, computer equipment, telecom communication systems, welding machines and other industries.
