RM8 Vertical 6+6Pin Electronic Transformer Bobbin6+6 Pins Vertical Bobbin, Phenolic Material,UL REC:94V-0 DIP Bobbin Pin Dia=0.6mm Size=21.6mmX16.3mmX12.3mm -
EE13 Vertical Bobbin For High Frequency Transformer 5+2 Pins5+2 Pins Vertical Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch1=3.6mm Pin Pitch2=2.5mm Parallel Distance=13mm -
High Current Flyback Transformer EF20 BobbinEF20 SMPS transformer wholesale. Horizontal type EF20 multi section transformer bobbin. Row distance=15.1mm. Pin pitch=3.8mm. Bobbin Size=22.0mmX22.0mmX13.0mm. EF20 transformer widely used in light system, industrial power supplies, and audio-visual equipment. We accept custom design and OEM service. -
EPC40 Power Transformer Frame 8+8 Pin Horizontal Bobbin8+8 pin horizontal EPC40 ferrite core bobbin, windly used in auxiliary powr transformer and main power transformer. Bobbin Size=41.5mmX26.0mmX21.45mm. Pin distance=5.0mm. We are bobbin factory, we supply various gigh quality ferrite cores for customers. -
ER42/20 Switching Transformer Bobbin CoverER42 transformer bobbin cover made by PBT material. Cover Size=39.0mmX21.6mmX26.0mm. ER42 PBT material bobbin cover, high temperature resistance and low cost, we produce various transformers and supply magnetic cores. -
EF12.6 Switching Power Transformer 4+5 Pin BobbinEF12.6 high frequency coil former. 4+5 pins horizontal EF12.6 single slot bobbin. Row distance=15.3mm. Bobbin Size=19.2mmX13.0mmX7.45mm. Pin pitch=3.5mm, pin pitch2=2.7mm. EF12.6 SMPS transformer widely used for UPS, computers, ultrasonic level sensors, electrical equipments, medical equipments, communication equipments, power supplies, vehicle electronic equipments. -
EEL22 Vertical Bobbin For Inverter TransformerEEL22 switcing transformer. Vertical 5+5 pin EEL22 bobbin. Bobbin size=22.1mmX16.0mmX30.0mm. Pin pitch=4.0mm. Parallel Distance=15.0mm. EEL22 transformer mainly used in communication power supply,SMPS, UPS power supply and other electronic equipment. -
EEL22 Switching Power Transformer Vertical BobbinEEL22 vertical coil former, 5+5 pin EEL22 transformer bobbin. Bobbin size=21.5mmX16.9mmX27.8mm. Pin pitch=5.0mm. Parallel Distance=12.5mm. EEL22 transformer mainly used in communication power supply,SMPS, UPS power supply and other electronic equipment., welcome customized EEL22 electronic transformer. -
EFD20 Flyback Transformer Horizontal Frame4+4 pins EFD20 coil former, manufacture final transformer. Pin pitch=5.0mm. Bobbin Size=20.1mmX20.0mmX10.4mm. Row distance=17.4mm. EFD20 power supply transformers widely used in electrical equipments, medical equipments, communication equipments, power supplies, vehicle electronic equipments. -
EEL22 Switching Power Transformer Vertical BobbinEEL22 vertical coil former, 5+5 pin EEL22 transformer bobbin. Bobbin size=21.5mmX16.9mmX27.8mm. Pin pitch=5.0mm. Parallel Distance=12.5mm. EEL22 transformer mainly used in communication power supply,SMPS, UPS power supply and other electronic equipment., welcome customized EEL22 electronic transformer. -
EFD20 High Frequency SMD Coil Former 5+5 Pins5+5 pins SMD bobbin, EFD20 horizontal coil former, manufacture final transformer. Pin pitch=3.7mm. Bobbin Size=26.4mmX21.4mmX10.7mm. Row distance=19.8mm. EFD20 electronic transformer mainly used in power supply unit, medical equipments, communication equipments, power supplies, vehicle electronic equipments. -
DVD Player Switch Horizontal Transformer Bobbin 8+8 PinsThe industrial frequency converter transformer bobbin and EE42 provide isolated power supply for the frequency converter and withstand high voltage.EE42 features high frequency and low loss, with a tensile strength of 130MPa after reinforcement with PA66 glass fiber. It prevents magnetic core loosening, ADAPTS to workshop vibrations, and enhances the reliability of the frequency converter. -
New Energy Photovoltaic PQ32 Transformer Bobbin 6+6PinsPQ32 Transformer Bobbins for PV Microinverters,The PQ32 transformer bobbin is suitable for PV microinverters and isolation transformers in PV optimizers, and is designed to withstand the harsh outdoor environments of photovoltaic power generation. The phenolic bobbin is UV-resistant, moisture-proof, and weather-resistant, making it resistant to deformation and cracking during long-term outdoor use. It features high core alignment and low magnetic circuit losses, thereby improving photovoltaic energy conversion efficiency. The winding zone design reduces coupling interference, and with ample safety margin, it is well-suited for high-frequency design solutions in the photovoltaic industry, supporting pin layout modifications and custom pin lengths based on drawings. -
Medical Device Power Supply Driver Transformer BobbinsEQ22 Photovoltaic Microinverter Bobbins , The EQ22 bobbin is suitable for photovoltaic microinverters, thin magnetic components, and energy storage auxiliary power supplies. It is also compatible with built-in driver transformers in microinverters. The bobbin features low distributed capacitance and effective magnetic shielding, making it suitable for high-frequency inverter circuits. With a temperature resistance of 130°C, it is suitable for high-temperature outdoor operating conditions. -
EQ25 PLC Auxiliary Power Supply Transformer Bobbin 5+5 PinsThe EQ25 LED driver transformer bobbin meets power supply requirements for commercial lighting, outdoor LED strips, and industrial/warehouse spotlights. It features ample winding space and excellent leakage inductance control, ensuring low temperature rise during high-frequency operation. Its flat structure fits compact circuit boards, complies with environmental standards, and ensures stable, durable performance during continuous, long-term operation.
