Military electronic installation filters. Excellent performance at high and low frequency. Type: DC. Rated current from 1A to 10A. Test Voltage ( 1min ): Line to Ground: 700VAC. Line to Line:400VDC.
brand:
MCTitem no.:
MCT8MF9 Military Filtersshipping port:
Shanghai
MCT8MF filters designs specially for the CE102 conduction launch request in the military equipment through electromagnetic compatibility military symbol GJB 151A/152A. Our military EMC filter has excellent interference suppression performance for CM and DM.
Quick Details
Part No: MCT8MF9 Military Filters |
Brand name: MCT |
Rated Voltage: 80VDC |
Custom made: Available |
Rated Current: 1A~10A |
Logo: Can be customized |
Operating Frequency: DC |
Packing: Carton, can custom |
Temperature range : HPF 25/085/21 |
Shipping: Air, Ship, etc |
Lead time: 25 days after payment |
MOQ: Any quantity |
Certification: ISO9001,ROHS,CE |
OEM: Available |
Part Information
Product Name: Military Single Phase DC EMI Filters
Applications: Single phase power supplies, switch-mode power supplies. Small to medium-sized machines and household equipment. Portable electrical and electronic equipment. Test and measurement equipment. Medical equipment.
Packing details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Product Details
If you have any questions, please contact us or leaving your comments, we will give you fast reply.
Email: sales003@mycoiltech.com
Skype: sales003_125
QQ: 2783136957
Contact: Miss Lily Yu
