PCB Board Transformer EF25 Bobbin HorizontalLead wire EF25 bobbin. Horizontal coil former 10 pins. Bobbin Size=25.5mmX25.1mmX19.3mm. Pin pitch=5.0mm. Parallel Distance=20.0mm. Phenolic bobbin for transformer. DIP bobbin. -
EF25 Bobbin For Customized Design TransformerEF low power transformer. Horizontal 5+5 pin bobbin. Bobbin Size=25.5mmX25.1mmX20.7mm. Pin pitch=5.0mm. Parallel Distance=20.0mm. Phenolic bobbin for transformer. DIP bobbin. -
High Frequency Power Transformer EF25 BobbinHorizontal type bobbin EF25. 7pin electronic transformer. Bobbin Size=26.0mmX24.5mmX21.0mm. Pin pitch=5.0mm. Parallel Distance=21.0mm. Phenolic bobbin for transformer. DIP bobbin. -
Switching Transformer EF25 Horizontal Coil FormerHigh efficiency transformer bobbin, EF25 10 pins bobbin. Bobbin Size=26.1mmX25.0mmX18.7mm. Transformer bobbin made of phenolic material. Pin pitch=4.0mm. Parallel Distance=20.0mm. DIP transformer bobbin. -
High Frequency SMPS Transformer EF25 BobbinEF25 power transformer design. 5+5 pin coil former EF25. Bobbin Size=25.9mmX25.0mmX18.8mm. Transformer bobbin made of T375HF material. Pin pitch=4.0mm. Parallel Distance=20.0mm. DIP transformer bobbin. -
Horizontal EE35 High Frequency Bobbin 6+6 PinEE35 ferrite coil for transformer. 6+6 pin horizontal bobbin EE35. Pin pitch=5.0mm. Parallel distance=21.4mm. L pin transformer bobbin. Bobbin Size=37.5mmX27.2mmX25.5mm. EE35 PET material bobbin. -
Two Slots Transformer EE35 Bobbin 12 PinsHigh frequency EE35 bobbin. Supply customized electronic transformer. 6+6 pin two slots bobbin. Parallel distance=21.4mm. Pin pitch=5.0mm. EE35 Bobbin Size=37.5mmX27.2mmX25.5mm. L pin transformer bobbin. EE35 PET material bobbin. -
EE42 Power High Frequency Horizontal BobbinEE42 switching transformer. 6+6 pins horizontal EE42 coil bobbin. Bobbin Size=46.20mmX41.50mmX42.20mm. Parallel distance=37.55mm. Pin pitch1=7.62mm. Pin pitch2=5.08mm. We can make bobbin tooling. Phenolic material EE42 transformer bobbin. -
EE42 SMPS Transformer Horizontal Bobbin 10 PinsEE42 high frequency bobbin. Horizontal EE42 bobbin pin 5+5. Bobbin Size=46.50mmX29.40mmX34.30mm. Parallel distance=34.70mm. Pin pitch=5.0mm. We can make bobbin tooling. PBT material bobbin. -
ER42 Power Supply Vertical Coil BobbinSwitch power transformer ER42. 9+9 pins ER42 vertical bobbin. Bobbin Size=45.50mmX32.00mmX29.7mm. Pin Pitch=5.0mm. Parallel Distance=27.4mm. ER42 high frequency transformer, with low magnetism leakage and good performance, we can start from samples. -
ETD44 Flyback Transformer Horizontal Bobbin 9+9 PinsETD44 high frequency bobbin. Horizontal ETD44 transformer. Bobbin Size=50.6mmX49.5mmX39.3mm. Pin distance=5.0mm. Parallel Distance=35.7mm. Lead free transformer bobbin. DIP bobbin. -
EF30 Power Transformer Vertical Bobbin 6+6 PinEF30 rectifier transformer. 6+6 pins vertical EF30 coil former. Bobbin Size=35.3mmX19.0mmX34.8mm. Pin pitch=5.08mm. Parallel Distance=15.24mm. SMPS transformer has small size, high power and low cost, we design and manufacture high frequency transformer. -
EF25 Power Charger Transformer Horizontal BobbinEF25 SMPS transformer. 5+5 pin horizontal bobbin EF25. Bobbin Size=24.0mmX23.8mmX21.5mm. Pin pitch=2.5mm. Parallel Distance=20.5mm. PC40 material EF25 ferrite core. DIP type transformer bobbin. -
SMPS Transformer EP7 SMD Coil Bobbin4+4 pin EP7 SMD bobbin. Horizontal EP7 coil former made of PM9630 material. We use bobbin in power transformer, LED drieve transformer, current transformer ,distribution transformer and other electronic transformers. We make bobbin tooling to meet special requirement. Low temperature rise power transformer. Welcome customized design and OEM service. -
ER49 High Frequency Transformer Horizontal Bobbin Double SlotsSupply ER49 transformer bobbin. 10+10 pins coil former. Horizontal ER49 two grooves bobbin. We only presented a standard ER49 transformer bobbin in our website. We manufacture final ER49 high power transformer, If you need support, please tell us the parameters you wanted, and we will advise suitable ones for you. If your size is special, we can also make new tooling. For final ER49 high frequency transformer, has low magnetism leakage and good operating performance, we can start from samples. -
POT 23/18 Flyback Transformer Vertical BobbinLED driver transformer wholesale. POT23 5+5 pins vertical bobbin. Bobbin Size=23.5mmX22.0mmX16.5mm. Parallel Distance=20.5mm. Pin pitch=3.8mm. DIP transformer bobbin. We are professional transformer bobbin factory, our bobbins are widely used in high frequency line filters, smoothing choke coil, drive transformer, switching power transformers and chokes -
High Frequency EE40 Switching Transformer 6+6 Pins BobbinEE40 power supply transformer. Vertical chape EE40 6+6 pin bobbin. Bobbin Size=32.2mmX28.0mmX30.3mm. Pin pitch=5.0mm. Parallel distance=22.5mm. We have bobbin tooling. EE40 electronic transformer used for electrical equipment, medical equipment, communication equipment, UPS and other electronic equipment industry. -
EFD25 High Frequency Power Transformer BobbinEFD25 pcb mounting transformer. 6+6 pin single slot SDM bobbin. Bobbin Size=31.5mmX25.0mmX12.6mm. Pin pitch=4.0mm. We have bobbin tooling now, samples are available. -
EFD25 Flyback Transformer SMD BobbinEFD soft ferrite core bobbin. Mainly for pcb mounting transformer. Bobbin pin 6+6 horizontal shape. Bobbin Size=31.5mmX25.0mmX12.6mm. Pin pitch=3.75mm. We have bobbin tooling now, samples are available.
-
High Frequency ER42 Transformer 7+7 Pins BobbinSoft ferrite core ER42 bobbin. Vertical ER42 7+7 pins bobbin. Bobbin Size=40.3mmX30.0mmX44.3mm. Parallel Distance=25.0mm. Pin Pitch=5.0mm. ER42 high frequency transformer, with low magnetism leakage and good performance, we can start from samples. -
ER42 Power Transformer Horizontal BobbinER42 horizontal transformer frame, 8+8 pin ER42 coil bobbin. Bobbin Size=44.0mmX40.0mmX33.8mm. Pin Pitch=5.0mm. Parallel Distance=35.0mm. ER42 high frequency transformer, with low magnetism leakage and good performance, we can start from samples. -
EE65 High Power Transformer Horizontal FrameEE65 single phase transformer. Horizontal EE65 bobbin 8+8 pins. Bobbin Size=51.5mmX43.7mmX54.8mm. Parallel Distance=44.5mm. Pin pitch=5.0mm. Good quality EE65 encapsulated transformer, singled packed with carton. -
SMPS PQ32 Vertical Transformer 2+2 Pin BobbinPQ32 power charger transformer. Vertical PQ32 2+2 pin bobbin. Bobbin size=33.0mmX32.7mmX30.6mm. Pin pitch=9.2mm. Row distance=27.2mm. We are experienced IS09001 certificated factory, our main products are transformer bobbins, magnetic cores and coil products. We accept custom design and OEM service. -
High Frequency EE65 SMPS Transformer FrameHigh power transformer. EE65 8+8 pin horizontal coil former. Bobbin Size=58.4mmX49.3mmX59.0mm. Parallel Distance=45.8mm. Pin pitch=5.0mm. Good quality EE65 power transformer, singled packed with carton, accept custom made transformer. -
PQM35 High Frequency Transformer Vertical BobbinHigh frequency bobbin PQM35. 3+5 pin vertical shape coil former. Bobbin Size=29.0mmX25.8mmX15.3mm. Parallel Distance=25.0mm. Pin pitch=5.0mm. Good quality PQM35 power transformer, singled packed with carton, accept custom made transformer. -
Switching Transformer EE19 Horizontal BobbinFlyback transformer bobbin. EE19 horizontal bobbin 7+7 pins coil former. Bobbin Size=20.7mmX20.1mmX15.95mm. Parallel Distance=17.7mm. Pin pitch=2.5mm. China transformer bobbin factory, we produce and make different bobbin toolings, we also manufacture final high frequency transformers for power supply. -
EE65 Switching Power Supply Transformer FrameHigh frequency EE65 transformer. No pin EE65 coil former. Bobbin Size=53.1mmX44.0mmX43.2mm. We have diferent size bobbin toolings, welcome custom made transformer and inductor. -
ER42 Vertical Transformer 4+1 Pin Bobbin Double SlotsVertical ER42 coil former, 4+1 pin ER42 transformer bobbin. Bobbin Size=37.6mmX33.0mmX52.7mm. Parallel Distance=28.0mm. ER42 high frequency vertical transformer, with low magnetism leakage and good performance, we can start from samples. -
EE19 LED Light Transformer Frame 4+6 PinEE19 high frequency bobbin. 6+4 pin EE19 horizontal bobbin two slots. Bobbin Size=18.5mmX15.0mmX17.8mm. Parallel Distance=12.5mm. Pin pitch1=3.5mm.Pin pitch2=2.7mm. We are transformer bobbin factory, we produce and make different bobbin toolings, we also manufacture final high frequency transformers for power supply. -
EE19 Power Supply Transformer Vertical BobbinEE19 ferrite core bobbin. 3+3 pin EE19 single slot bobbin two slots. Bobbin Size=14.0mmX13.0mmX10.8mm. Parallel Distance=11.0mm. We are transformer bobbin factory, we produce and make different bobbin toolings, we also manufacture final high frequency transformers for power supply.
