EE42 SMPS Transformer Horizontal Bobbin 10 PinsEE42 high frequency bobbin. Horizontal EE42 bobbin pin 5+5. Bobbin Size=46.50mmX29.40mmX34.30mm. Parallel distance=34.70mm. Pin pitch=5.0mm. We can make bobbin tooling. PBT material bobbin. -
SMPS EE42 Flyback Transformer Vertical BobbinEE42 high frequency transformer. EE42 vertical winding bobbin 18pins. Bobbin Size=45.0mmX32.0mmX29.4mm. Parallel distance=27.5mm. Pin pitch=5.0mm. We can make bobbin tooling. Phenolic material bobbin. -
EE42 Ferrite Core Switch Power Transformer Vertical BobbinEE42 high frequency transformer. Vertical type EE42 8pin bobbin. Bobbin Size=55.95mmX46.2mmX4.95mm. Pin pitch=5.5mm. We can make bobbin tooling. EE42 electronic transformer can used for electrical equipment, medical equipment, communication equipment, UPS. AC/DC Converter, LED drive and vehicle electronic equipment industry. -
EE42 High Frequency Power Supply Transformer FrameEE42 power high frequency transformer. Single section EE42 bobbin with pin 6+6. Bobbin Size=38.1mmX29.0mmX34.2mm. Pin pitch=5.0mm. Parallel Distance=35.0mm. We have bobbin tooling. We supply matched EE42 ferrite cores and transformers. -
EE42 Switching Power Transformer Horizontal BobbinEE42/20 soft ferrite core. 8+8 pin horizontal single slot EE42 coil former. Bobbin Size=44.5mmX42.3mmX41.1mm. Parallel Distance=37.8mm. Pin pitch=5.0mm. China transformer bobbin factory, we produce and make different bobbin toolings, we manufacture various power supply transformers and chokes. -
EE42 High Frequency Transformer Horizontal BobbinEE42 flyback transformer, 8+8pin EE42/21 transformer bobbin. Bobbin Size=47.6mmX40.0mmX35.8mm. Parallel Distance=36.0mm. Pin pitch=5.0mm. EE42 electronic transformer, with high transmission power and low temperature rise,welcome customzied wound components. FR50 material EE42 coil bobbin. -
EE42 Switching Transformer Horizontal BobbinEE42/15 ferrite core, 8+8pin horizontal EE42 transformer bobbin. Bobbin Size=40.7mmX39.6mmX32.1mm. Parallel Distance=36.0mm.Pin pitch=5.0mm. EE42 electronic transformer factory, with high transmission power and low temperature rise,welcome customzied wound components. PBT material EE42 coil former. -
EE42 High Voltage Transformer Vertical BobbinEE42/20 ferrite core bobbin, 9+9 pin EE42 through hole transformer. Bobbin Size=45.8mmX39.6mmX45.0mm. Parallel Distance=27.50mm.Pin pitch=5.0mm. EE42 electronic transformer factory, with high transmission power and low temperature rise,welcome customzied wound components. PBT material EE42 coil former. -
EE42/15 Power Transformer Horizontal Bobbin8+8 pins horizontal EE42 bobbin, DIP EE42/15 coil former. Bobbin Size=43.2mmX40.5mmX36.80mm. Parallel Distance=35.0mm. Pin pitch=5.0mm. We are EE42 electronic transformer factory, all transformers and inductors accept custom made. -
8+0 Pin EE42 Vertical Transformer BobbinEE42 high frequency bobbin, 8+0 pin EE42 vertical transformer frame. Half bobbin Pin pitch=6.0mm. PM9820 material EE42 coil former. We have different size EE42 bobbin toolings, for special size bobbin, we can make new tooling to meet size requirement. -
EE42 High Frequency Horizontal Coil FormerHorizontal EE42 8+8 pins bobbin, EE42/20 single slot coil former. Bobbin Size=49.0mmX44.5mmX44.0mm. Parallel Distance=37.70mm. Pin pitch=5.0mm. EE42 electronic transformer factory, we produce various transformers and inductors for power supplies. -
EE42 High Voltage Transformer FrameHorizontal EE42/15 bobbin, 8+8 pins EE42 coil former. Bobbin Size=41.8mmX39.5mmX35.80mm. Parallel Distance=35.0mm. Pin pitch=5.0mm. We manufacture various EE42 electronic transformers for power supplies, industrial equipments.
