ETD49 High Voltage Transformer Ferrite BobbinETD49 PCB mounting transformer, 10+10 pins ETD49 vertical coil former. Bobbin Size=61.4mmX33.9mmX56.0mm. Pin pitch=5.08mm. Parallel Distance=30.48mm. PET material ETD49 HF transformer frame.Manufacture transformers, mainly used in PCB circuits, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipments. -
ETD49 High Voltage Horizontal Transformer BobbinETD49 flyback transformer horizontal coil bobbin, 10+10 pins ETD49 bobbin two slots. Bobbin Size=48.5mmX47.0mmX33.5mm. Pin pitch=5.0mm. Parallel Distance=42.5mm. Phenolic material ETD49 electronic transformer frame. We manufacture transformers, mainly used in PCB circuits, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipment. -
ETD49 Power Transformer Bobbin Phenolic CoverETD49 transformer cover for bobbin, produce 10+10 pins ETD49 bobbin two slots. Cover Size=51.8mmX50.3mmX33.5mm. Phenolic material ETD49 electronic transformer cover. We manufacture transformers, mainly used in PCB circuits, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipment. -
High Frequency PM87 Transformer BobbinPM87 bobbin for transformer, PET material PM62 coil former without pins. We supply Mn-Zn ferrite cores and manufacture final PM62 transformer and accept OEM service. -
6+6 Pins EE35 Encapsulated Transformer BobbinEE35 double slots bobbin. Horizontal EE35 6+6 pins coil former. Parallel distance=22.0mm. Pin pitch1=4.0mm. Pin pitch2=5.0mm. EE35 Bobbin Size=37.5mmX27.0mmX25.5mm. DIP pin transformer bobbin. EE35 PBT material transformer bobbin. -
EE35 High Frequency Transformer Bobbin 6+6 PinsEE35 ferrite bobbin. 6+6 pins EE35 horizontal transformer frame. Parallel distance=21.4mm. Pin pitch1=3.8mm. Pin pitch2=5.0mm. EE35 Bobbin Size=37.0mmX26.3mmX26.4mm. L pins transformer bobbin. We manufacture EE35 transformers. -
Two Slots Transformer EE35 Bobbin 12 PinsEE35 encapsulated transformer, 6+6 pins EE35 horizontal coil former. Parallel distance=22.1mm. Pin pitch1=5.1mm. Pin pitch2=3.8mm. Bobbin size=37.20mmX26.4mmX25.4mm. EE35 transformer bobbin DIP pins, supply EE35/EC35 soft ferrite cores. -
EFD40 Horizontal Double Slot Coil Former 8+8 PinsEFD40 high frequency transformer multi slot bobbin is a very popular product in our factory, 8+8 pins EFD40 horizontal bobbin，bobbin former size=42.60mmX41.00X17.40mm.We accept customized transformer frame sizes. If your industry belongs to laboratory research and development, medical equipment, military industry, or manufacturing, you can contact us at any time and we can provide transformer samples. -
EPC30 Horizontal Step Up Circuit Transformer 6+6 PinsNew energy vehicle power switch EPC30 horizontal transformer bobbin 6+6 pins. Best selling EPC30 transformer bobbin. Size=35.1 mmX30.00mmX29.9mmX16.00mm，Pin row distance 30.00mm.Pin distance 5.00mm，If you cannot find a suitable product size, please feel free to contact us at any time. We have professional design engineers and provide customized services, including ferrite cores for voltage transformers, transformer bobbins, transformer covers, etc. -
GU22/POT22 High Frequency Transformer BobbinGU22 transformer for avionics bobbin size=17.6mmX4.6X17.6mm.This product is made of PA66 material, featuring strong support to prevent winding deformation, high insulation to prevent short circuits, and high-temperature resistance suitable for working conditions ranging from 80 to 180℃. Flame-retardant up to UL94 V-0 grade, resistant to moisture, heat and corrosion, long-lasting and stable. Compatible with high-frequency, vehicle-mounted and industrial transformers, it ensures performance and safety, and is the preferred component for enhancing the reliability of transformers! -
GU26 PLC module transformer bobbinGU26 is used for the isolation power transformer bobbin，Each product of the GU series transformer frames has been jointly inspected by multiple departments to ensure that every product is qualified. At the same time, to meet the diverse needs of different customers, we offer customized services. If you haven't found the right size, you can contact me immediately and I will recommend the most suitable solution for you. -
GU26 PLC Module Transformer Double Slots BobbinGU26 New Energy Charging Pile Transformer bobbin，The multi-slot system separates the primary, secondary and shielded windings through physical slot walls, significantly increasing the creepage distance and electrical clearance between windings. It can typically meet the withstand voltage requirement of ≥5kV, and the leakage current is controlled within < 50µA, easily passing UL 60601 (medical) and IEC 61558 (industrial) safety certifications. Moreover, the tank walls are mostly made of flame-retardant UL94 V-0 grade materials, which are not easy to burn at high temperatures. This can effectively prevent safety risks caused by winding insulation failure in medical equipment (such as ultrasound machines) and industrial high-voltage equipment, ensuring the safety of personnel and equipment. -
Three Slot GU26/POT26 Transformer BobbinGU26/POT26 New Energy Charging pile transformer bobbin,Multi-slot support can wind different windings in independent slots, flexibly achieving a "single input + multiple output" design. For example, it can precisely provide multiple sets of voltages such as ±12V (driving relays), 5V (power supply chips), and 24V (driving sensors) for industrial PLC modules, and the windings of each group do not interfere with each other. Avoid the problem of uneven current distribution caused by the single-slot tap design. It is simultaneously compatible with multi-purpose power supply scenarios such as in-vehicle electronics (main power supply + auxiliary control power supply) and precision instruments (main power supply + signal power supply), reducing the complexity of circuit design. -
GU36/POT36 Motor Drive Power Transformer BobbinGU36 PLC module transformer bobbin ，The GU series transformer bobbin is heat-resistant and prevents deformation. It has high mechanical strength, can firmly support the winding, and is resistant to impact and not easily damaged. It has excellent insulation performance, effectively isolating current and ensuring safe use. It also features excellent weather resistance and dimensional stability, making it suitable for the long-term stable operation of transformers, enhancing the durability and reliability of the product, and laying a solid foundation for the safe and efficient operation of the equipment.
