PQ50 High Frequency Transformer Babbin 8+8 PinsPQ50 horizontal coil bobbin, PQ50 8+8 Pins Frequency converter drive double slots transformer bobbin. Coil former size=50.00mmX49.50mmX38.90mm, parallel distance=38.00mm, pin distance =5.0mm.We have a professional design team capable of providing tailored customization services, covering current transformers, common mode inductors, high-frequency transformers, potted transformers, and more. -
PQ26 Horizontal Coil Former for Household to Circuit Power Supply 5+5 PinsPower switch transformer bobbin,5+5 pins PQ26 bobbin. Coil former size=25.00mmX25.00mmX29.20mm, parallel distance=20.50mm, pin distance=5.00mm.Our product has excellent edge property, high dielectric strength and low loss, and can adapt to high frequency isolation requirements; Secondly, it has strong heat resistance and wide temperature resistance (- 40 ℃ to 150 ℃), vibration resistance and high mechanical strength, and can adapt to complex working conditions; In addition, good dimensional stability and low shrinkage can match the compact structure of PQ26; Moreover, it is water-resistant, oil-resistant and moisture-proof, with durable insulation; Moreover, the flame retardancy reaches UL94 V0 and the safety is guaranteed, so as to perfectly adapt to the application requirements of PQ26 in high frequency, compact and multi-scene (vehicle-mounted, industrial, etc.). -
PQ32 Vertical Flyback Coil Former 6+6 PinsPQ32 servo motor driver transformer Vertical bobbin, 6+6 pins PQ32 bobbin. Coil former size=34.2mmX31.80mmX19.40mm, parallel distance=30.00mm, pin distance 1=5.00mm. pin distance 2=7.50mm. The PQ32 series is just one of the best selling products, and we also offer transformers covers, transformers bases, transformers cases, and more. We also support customized sizes, including related dimensions and product molds. If you have any product issues, please feel free to contact us at any time. -
PQ26/25 High Voltage Transfomer Frame 6+4 PinsPQ26 horizontal coil bobbin, 6+4 pins PQ26 through hole bobbin. Coil former size=29.8mmX26.4mmX27.5mm, parallel distance=26.3mm, pin distance =5.0mm, pin distance 2 =4.5mm. PQ26 electronic transformers are used for industrial automation, communication equipment, military equipment,etc. We can custom final transformers with specific parameters. -
PQ26 High Frequency Transformer Bobbin 2+2 PinsPQ26 ferrite core bobbin, 2+2 pins PQ26 vertical bobbin. Coil former size=22.0mmX14.0mmX22.0mm, parallel distance=18.0mm, pin distance=6.0mm. We can custom final transformers with specific parameters for different applications, such us UPS, charges, printers, etc. -
PQ32 High Frequency Transformer Bobbin 6+6 PinsPQ32 ferrite core bobbin, 6+6 pins PQ32 SMD bobbin. Coil former size=43.5mmX32.2mmX18.95mm, parallel distance=35.5mm, pin distance 1=7.5mm. pin distance 2=5.0mm. Our products are suitable for industrial automation, communication equipment, military equipment,etc. We can custom final transformers with specific parameters. -
PQ35 High Frequency Transformer BobbinPQ35 power transformer bobbin, 6+6 pins PQ32/30 vertical bobbin, single slot PQ35 coil former. Row distance=35.8mm. Bobbin Size=39.3mmX34.96mmX32.0mm. Pin pitch=5.0mm. PQ35 bobbin for high frequency transformer, used in power suppliers, printers, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipment. -
PQ32 LLC Resonant Transformer BobbinVertical PQ32 coil bobbin. Single slot PQ32 bobbin 6+6pins. Bobbin Size=33.8mmX31.8mmX32.7mm. Pin pitch=5.0mm, parallel distance=22.8mm, we custom special bobbin tooling to meet size requirements, samples can be sent for testing. -
High Power PQ20 Transformer Vertical BobbinPQ20 vertical bobbin 6+8 pins, PCB mounting PQ20 transformer bobbin. Parallel Distance=15.0mm. PQ20/16 ferrite core frame. Bobbin Size=23.8cmX22.9cmX16.5cm. Pin pitch=2.5mm. Pin pitch=3.80mm. PQ20 series bobbin for electronic transformers, welcome customized PQ20 power transformer. -
Low loss Power Transformer ATQ15.5 BobbinATQ15.5 vertical bobbin, power transformer frame, 5+0/4+0 pins vertical ATQ15.5/14.3 coil former. Bobbin Size=15.4mmX15.0mmX14.9mm. Pin distance=3.0mm. Phenolic material ATQ series bobbins. China bobbin factory, custom made injection tooling, plant pin tooling, we also manufacture final transformers. -
PQ20 Switching Power Transformer Frame 6+8 Pins6+8 pins PQ20/20 coil former, vertical PQ20 though hole bobbin. Parallel Distance=20.5mm. PQ20 ferrite core bobbin. Bobbin Size=23.0cmX23.0cmX23.30cm. Pin pitch=2.54mm. Pin pitch=3.80mm. PQ20 series bobbin for high power PQ20 transformer, welcome customized PQ20 electronic transformer. -
LP23 Power Supply Transformer BobbinLP23/8 horizontal bobbin, 6+4 pins single slot LP23 transformer frame. Bobbin size=24.0mmX20.55mmX21.2mm. Pin pitch=3.5mm, parallel distance=16.2mm, phenolic material transformer bobbin for LP23 electronic POWER transformer, accept custom made transformer. -
PQ35 Flyback Transformer Horizontal Bobbin Double SlotsPQ35 power supply transformer, double sections PQ35/35 bobbin. Horizontal PQ35 bobbin 7+7 pins. Bobbin Size=36.3mmX35.0mmX35.2mm. Row distance=32.0mm. Pin pitch=5.0mm. Phenolic material PQ35 bobbin for high frequency transformer, used in power suppliers, printers, filters, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipment. -
PQ40/30 High Voltage Transformer Vertical BobbinPQ40 vertical bobbin 6+6 pins, PQ40/30 ferrite core transformer frame. Bobbin Size=43.8mmX39.5mmX35.1mm. Pin pitch=5.0mm, row distance=38.0mm. Phenolic material PQ40/30 bobbin for electrical machinery, bobbin factory directly selling PQ40 series bobbins, wholesale PQ40/30 cores. -
ATQ21/16.8 Soft Ferrite Core BobbinATQ21 power transformer frame, 5+0 pins vertical ATQ21/16.8 coil former single slot ATQ21 bobbin 5+0pins. Bobbin Size=17.32mmX14.00mmX14.10mm. Pin distance=3.50mm. phenolic material ATQ21 bobbin. We are bobbin factory, we have various Injection tooling, plant pin tooling, we can manufacture final transformers. -
ATQ21 High Frequency Transformer Vertical BobbinVertical ATQ21 transformer bobbin, single slot ATQ21 bobbin 5+0pins. Bobbin Size=19.40mmX18.0mmX15.9mm. Pin distance=3.50mm. PM9630 material ATQ21 bobbin. We are bobbin factory, we have various Injection tooling, plant pin tooling, we can manufacture final transformers. -
PQ50 Power Supply Transformer Frame No PinsPQ50 no pins bobbin. PBT material PQ50/50 coil former. Bobbin size=33.0*29.6*46.5mm. We are professional IS09001 certificated factory, we produce various plastic bobbins and manufacture electronic transformers and inductors. Welcome custom made transformers ans small batches production. -
PQ50/50 Main Power Transformer Double Slots BobbinTwo slots PQ50 coil former, vertical PQ50 transformer bobbin 7+7pins, split core bobbin. Bobbin size=51.0mm*51.3mm*51.0mm. Pin pitch=7.60mm, parallel distance=45.70mm. We are bobbin factory and produce various size bobbins, provide custom bobbin tooling service, we also manufacture transformers and filter inductors. -
PQ50 Power Transformer Bobbin 7+7 Pins7+7 pins vertical PQ50 transformer frame, single slot PQ50/50 coil former. Bobbin size=51.0mm*51.3mm*51.0mm. Pin pitch=7.60mm, parallel distance=45.70mm. We are professional IS09001 certificated factory, we produce various size bobbins, provide custom bobbin tooling service, we also manufacture transformers and filter inductors. -
PQ32/30 Horizontal Transformer Double Slots BobbinTwo sections PQ32 bobbin. Horizontal PQ32 coil former 4+4 pins. Bobbin Size=32.0mmX29.7mmX31.0mm. Pin pitch=6.0mm, parallel distance=26.0mm, we make special bobbin tooling to meet size requirements, samples can be sent for testing. -
PQ32 High Frequency Transformer BobbinPQ32 ferrite core bobbin, 6+6 pins vertical PQ32 coil former. Bobbin Size=33.85mmX31.9mmX30.2mm. Pin pitch=5.08mm, parallel distance=22.52mm, Phenolic PQ32 transformer bobbin for high frequency transformer, we accept custom made bobbin toolings. -
PQ26/30 High Frequency Transformer FrameVertical PQ26 coil former, 6+6 pins PQ26/30 transformer frame, bobbin size=29.5mmX26.5mmX29.9mm. Parallel distance=25.4mm, pin pitch1=3.8mm, pin pitch2=7.6mm. Phenolic material PQ26 transformer bobbin. We manufacture various high frequency transformers, mainly used in PCB circuits, printers, filters, computers, LED lighting, UPS, monitor, scanners, mobile adapters and other equipment. -
PQ40 High Frequency Power Transformer FramePQ40/40 no pin bobbin, ferrite core transformer PQ40. Bobbin Size=36.0mmX27.0mmX40.2mm. Phenolic material PQ40 bobbin forelectrical machinery, bobbin factory directly selling PQ40 series bobbins, wholesale PQ40/40 cores. -
PQ40 Power Supply Transformer Vertical BobbinPQ40 ferrite core bobbin. No pin PQ40 transformer frame. Bobbin Size=36.0mmX34.0mmX30.5mm. Phenolic material PQ40 coil bobbin for transformer, used in PCB circuits, electrical machinery and power supplies. -
4+2+2 Pins High Frequency Transformer PQ16 BobbinPQ16 power transformer bobbin, DIP type 4+2+2 pins PQ16 coil former, bobbin size=17.5mmX17.0mmX15.0mm. Parallel distance=14.0mm, pin pitch1=4.0mm, pin pitch2=6.0mm. Phenolic material PQ16 bobbin for high frequency transformer, we can use it PCB circuits, power supply, computers, LED lighting, etc. Welcome for customized PQ16 transformer. -
PQ26 High Frequency Transformer Horizontal Bobbin4+4 pins horizontal PQ26 coil former, single slot PQ26/25 transformer frame. Bobbin size=26.0mmX24.7mmX23.2mm. Parallel distance=21.5mm, pin pitch1=6.5mm, pin pitch2=10.0mm. PQ2625 bobbin for high frequency transformer, mainly used in PCB circuits, printers, filters, computers, LED lighting, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipment. -
PQ26/25 Flyback Transformer Vertical BobbinVertical PQ26/25 single slot transformer, bobbin size=33.2mmX26.9mmX25.6mm. Parallel distance=26.3mm, pin pitch1=3.8mm, pin pitch2=7.6mm. Phenolic PQ26 bobbin for high frequency transformer, mainly used in PCB circuits, printers, filters, computers, LED lighting, fax machines, computers, UPS, monitor, scanners, mobile adapters and other equipment.
-
PQ32 Flyback Transformer Vertical Bobbin6+6 pins PQ32/30 coil bobbin, PQ32 high frequency transformer. Bobbin Size=34.5mmX33.0mmX30.7mm. Pin pitch=5.0mm, parallel distance=30.0mm, Phenolic PQ32 bobbin for high frequency transformer, accept custom made and OEM service. -
High Frequency Transformer LP32 BobbinLP32 horizontal bobbin 4+4 pins, ferrite core for LP32 bobbins. Size=40.4mmX25.0mmX17.6m. Pin pitch=6.35mm, parallel distance=27.94mm, PPS material transformer bobbin for LP32 electronic transformer, we accept custom made bobbins and OEM service. -
PQ50/50 High Frequency Transformer BobbinPQ50 SMPS transformer, PFC choke PQ50/50 horizontal coil former. Bobbin size=50.0mmX49.7mmX44.0mm, Parallel distance=38.0mm, Pin pitch=5.0mm. We are professional IS09001 certificated factory, we produce bobbins, suply magnetic cores, manufacture electronic transformers and filter inductors.
