Common mode inductor with base has high efficiency, high power, high current, low power loss, low temperature rise,high temperature grades also available. As excellent EMI suppressor, SMT and low profile also available.
brand:
MCTitem no.:
MCT B36V with Base Series Common Mode Chokeshipping port:
ShanghaiProfessional magnetic components factory, we supply transformer bobbins, ferrite cores, coil products. Mainly for high frequency electronic transformers, coil inductors, DC converters. Custom made available!
Quick Details
|
Part Number: MCT B36V with Base Series Common Mode Choke |
|
Brand name: MCT |
|
Type: Choke Inductor, High requency |
|
Custom made: Available |
|
Testing frequency: 1KHz/0.25V |
|
Logo: Can be customized |
|
Operating temperature:-40°C~+105°C. |
|
Shipping: Air, Ship, etc |
|
Certification: ISO9001,ROHS,CE |
|
MOQ: Any quantity |
|
Lead time: 25 days after payment |
|
OEM: Available |
Part Information
Product Name: B36V Toroidal Inductor Common Mode Choke with Base
Applications: Power supply. Power line in and output filter, for filtering of devices without a stable ground connection. Large current choke coils. Radio interference suppression in motor. Power over Ethernet Transformer. Power Conditioning System.
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Product Specification
Typical electrical parameter
|
MCT Part No. |
Inductance(mH) min |
DC Resistance(Ω)max |
Rated Current(A) |
|
MCTB36V333A40 |
33.0 |
0.20 |
4.0 |
|
MCTB36V223A50 |
22.0 |
0.10 |
5.0 |
|
MCTB36V153A60 |
15.0 |
0.07 |
6.0 |
|
MCTB36V103A70 |
10.0 |
0.05 |
7.0 |
|
MCTB36V682A80 |
6.80 |
0.04 |
8.0 |
|
MCTB36V472AA0 |
4.70 |
0.025 |
10.0 |
|
MCTB36V332AF0 |
3.30 |
0.015 |
15.0 |
|
MCTB36V222A12 |
2.20 |
0.012 |
18.0 |
|
MCTB36V222A19 |
1.50 |
0.008 |
25.0 |
|
MCTB36V222A1E |
1.00 |
0.006 |
30.0 |
We can decign.If you have any requests, please contact us, we will give you fast reply
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
B31V Magnetic Core Common Mode Inductor with Base
Magnetic core inductor storage inductor manufacturer. Our inductor has high efficiency, high power, high current, low power loss, low temperature rise, high temperature grades also available.
B42V PCB Board Common Mode Choke Filter with Base
Common mode choke coils with base has low frequency ranges, very compact design, Operating temperature: –40 ºC to +105 ºC. Mainly for AC/DC and DC/DC EMI line noise suppression. Communication system EMI line noise suppression. Automotive system EMI line noise suppression. Computer peripheral equipment EMI line noise suppression
B22V Common Mode Choke Inductors with Phenolic Base
Common mode choke with base mainly for power supply. Power line in and output filter, for filtering of devices without a stable ground connection. Large current choke coils. Radio interference suppression in motor. Power over Ethernet Transformer.
B25V Common Mode Inductor Choke Coils with Base
T25 ferrite core choke with base can achieve high suppression at low frequency ranges, it has very compact design, highest possible current with small sizes. Operating temperature: –40 ºC to +105 ºC ,accept custom designs.
Multi Section EFD15 Horizontal Transformer Bobbin
EFD15 power transformer multi section bobbin, 5+5 pins horizontal EFD15 coil former. Bobbin size=24.0mmX15.0mmX7.45mm. Pin pitch=2.5mm. LCP-E4008 material EFD15 bobbin, mainly used in power supplies.We accept customized EFD15 flyback transformer.
Common Mode Inductor Choke Base
Filter inductor toroidal base. We are professional coil products manufacturer, we supply various high frequency transformers, LAN transformers, SMT transformers for customers. We also provide matched magnetic cores. Samples are available. Plastic inductor PBT material base.
EQ30 Vertical Transformer Frame 5+5 Pins
EQ30 vertical bobbin 5+5 pins. EQ30/EIQ30 ferrite core supply. Bobbin size=31.1mm*29.0mm*17.2mm. Parallel Distance=26.8mm. Pin Pitch=5.0mm. Phenolic material EQ30 bobbin. We can make new bobbin tooling to meet size requirement.
EPO12.6 Transformer Bobbin Horizontal Bobbin With 3+3 Pins
3+3 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=4.5mm Parallel Distance=6.4mm Size=13mmX8.4mmX8.1mm
EF25 4+4 Pin Horizontal Transformer Ferrite Core Bobbin
4+4 pin EF25 horizontal bobbin. EF25 high frequency transformer. Bobbin Size=25.7mmX22.5mmX20.5mm. Parallel Distance=20mm. Pin pitch=5.0mm. PA66 material bobbin. DIP transformer bobbin.
PQ20 Power Supply Transformer Vertical Bobbin 6+8 Pins
PQ20 vertical transformer bobbin. PQ20 coil former made of phenolic material. Pin pitch1=2.5mm. Pin pitch2=3.8mm. Parallel Distance=20.3mm. Size=23.3mmX23.2mmX22.3mm. We can make bobbin tooling.
ER20 Vertical Transformer Bobbin 4 Pin For Ferrite Core
ER20 electronic transformer bobbin 4pin. Vertical type transformer bobbin. ER20 T375HF coil bobbin. Pin Pitch=4mm. Bobbin Size=20.3mmX15.7mmX14.8mm. We can make tooling. UL REC:94V-0
ER42 Power Transformer Horizontal Bobbin
ER42 horizontal transformer frame, 8+8 pin ER42 coil bobbin. Bobbin Size=44.0mmX40.0mmX33.8mm. Pin Pitch=5.0mm. Parallel Distance=35.0mm. ER42 high frequency transformer, with low magnetism leakage and good performance, we can start from samples.
