PCB Mounting RM6 Transformer BobbinRM6 led drive transformer bobbin, 4+4 pins vertical coil bobbin, coil former size=20.9mmX12.3mmX8.9mm,Pin Dia=0.5mm, Phenolic Material,UL REC:94V-0, DIP Bobbin, accept customized RM6 small electronic transformer. -
RM8 Bobbin For Power Transformers No PinNo Pin RM8 Transformer Bobbin, supply RM8 soft ferrite cores.Bobbin Size=16.9mmX9.8mmX9.1mm. Phenolic Material,UL REC:94V-0 -
RM8 Vertical Transformer 6+6 Pins Bobbin6+6 pins vertical bobbin, single slot RM8 coil former, RM8 MP4 material ferrite core, parallel distance=14.4mm. Pin Dia=0.6mm. Size=24.5mmX16.7mmX13.3mm, Phenolic Material,UL REC:94V-0 -
Four Slots EFD15 Transformer Horizontal BobbinEFD15 ferrite core, 5+5 Pins horizontal transformer bobbin, pin pitch=2.5mm, Parallel Distance=14.6mm, Bobbin Size=17mmX15mmX8.5mm. We manufacture final EFD15 transformer. -
EF16 Vertical Transformer Bobbin 3+3 Pins3+3 pin EF16 transformer, vertical type coil bobbin. Size=13.1mmX11.6mmX13.5mm. Pin Pitch=3mm. Parallel Distance=9mm. -
6+6 Pins EFD20 SMD Ferrite Core BobbinSMD coil former EFD20. Transformer bobbin pin 6+6. Phenolic material transformer bobbin. Horizontal type SMD bobbin. Pin Pitch=3.mm. Parallel distance=20mm. Size=28.65mmX20mmX9.7mm. Customized designs are accepted. -
ER28 High Frequency Transformer Vertical Bobbin 8+8 Pin8+8 pins ER28 vertical bobbin. ER28 phenolic material bobbin. Bobbin Size=31.81mmX26.6mmX23.7mm. Pin Pitch=4mm. Parallel distance=22mm. We can make tooling. DIP bobbin. UL REC:94V-0 -
EF20 Horizontal High Frequency Transformer Bobbin 10 Pin5+5 pin EF20 power transformer bobbin. Single slot EF20 horizontal bobbin. Bobbin Size=22mmX18.2mmX14.6mm. Parallel Distance=15.24mm. Pin pitch=3.81mm. PET material EF20 bobbin. DIP transformer bobbin. -
EF25 Horizontal 9+9 Pin Coil Former For TransformerEF25 transformer horizontal bobbin. EF25 9+9 pin transformer bobbin. Bobbin Size=26mmX26mmX19.5mm. Parallel Distance=20.32mm. Pin pitch=2.54mm. Phenolic material bobbin. DIP transformer bobbin. -
Transformer EF25 Ferrite Core Four Slots BobbinEF(4+4pin) horizontal bobbin. Multi section coil former. Bobbin Size=26.2mmX25.4mmX21.0mm. Pin pitch=5.0mm. Parallel Distance=19.9mm. PA66 material transformer bobbin. DIP bobbin. -
EF30 Power Transformer Vertical Bobbin 6+6 PinEF30 rectifier transformer. 6+6 pins vertical EF30 coil former. Bobbin Size=35.3mmX19.0mmX34.8mm. Pin pitch=5.08mm. Parallel Distance=15.24mm. SMPS transformer has small size, high power and low cost, we design and manufacture high frequency transformer. -
EP7 Power Supply SMT Transformer 4+4 Pin BobbinTransformer for Lighting Lamp. 4+4 pin horizontal coil former, we make bobbin tooling to meet special requirement. Bobbin for power supply transformer. Customized design and OEM service are accepted. -
SMD Power Transformer EP7 Horziotnal BobbinEP7 drive power transformer bobbin. 4+4 pin horizontal coil former, we make bobbin tooling to meet special requirement. Bobbin for power supply transformer. Customized design and OEM service are accepted. -
EP7 High Frequency Transformer Ferrite Core BobbinEP7 drive transformer bobbin. Coil former EP7 pin 4+4 horizontal bobbin. Low loss power transformer. We make bobbin tooling to meet special requirement. Bobbin for power supply transformer. Low temperature rise power transformer. Welcome customized design and OEM service. -
SMD EP7 High Frequency Transformer BobbinEP7 4+4 pin SMD bobbin. EP7 horizontal type coil bobbin. Low loss power transformer. We make bobbin tooling to meet special requirement. Bobbin for power supply transformer. Low temperature rise power transformer. Welcome customized design and OEM service.
-
EF20 Flyback Transformer Horizontal 4+4+4 Pin BobbinEF20 MP4 ferrite core. Horizontal power transformer ef20 bobbin factory. Bobbin Size=19.5mmX12.78mmX20.1mm. Pin pitch=2.54mm. We have bobbin tooling to meet customer's requirement. -
PQ65 High Voltage Switching Transformer BobbinPQ65 power coil former. Vertical type PQ65 6+6 pins bobbin. Bobbin size=64.0mmX62.0mmX61.95mm. Pin pitch=7.5mm. Row distance=54.0mm. We are experienced IS09001:2015 certificated factory, our main products are various bobbins, magnetic cores, transformers and filter inductors. We have specialized after-sales team and offer technology support.Make bobbin tooling. -
SMPS High Frequency Transformer EE16 BobbinEE16 power transformer manufacturing. EE16 ferrite core bobbin for high frequency transformer. Parallel Distance=10.5mm. Bobbin Size=15.9mmX13.0mmX14.0mm. Pin distance=3.25mm. Inductor customise bobbin EE16. We have many private bobbin toolings. We manufacture final transformers and coils. -
EE30 Horizontal Switching Power Supply Transformer BobbinEE30 ferrite core transformer. 6+6 pins horizontal EE30 bobbin with single slot. Bobbin Size=32.0mmX29.0mmX28.8mm. Parallel Distance=25.0mm. Pin distance=5.0mm. Transformer bobbin factory, we have many private bobbin toolings. We can manufacture final transformers and inductors. -
EE33 6+6 Pin Bobbin For PCB Mounting TransformerEE33 horizontal bobbin for LED drive transformer. EE33 soft ferrite core supplier. Bobbin Size=33.2mmX33.0mmX26.7mm. Parallel Distance=25.0mm. Pin distance=5.0mm. 6+6 pins horizontal EE33 bobbin. We are China transformer bobbin factory, we have many bobbin toolings.
-
4+4 Pin EE19 Horizontal Flyback Transformer FrameEE19 power transformer bobbin. Single slot EE19 4+4 pin coil bobbin. Bobbin Size=19.0mmX13.6mmX14.8mm. Parallel Distance=12.6mm. Pin pitch=3.8mm. We have bobbin tooling. We supply matched EE42 ferrite cores and transformers. -
Vertical EE13 High Frequency Power Transformer BobbinEE13 mini electronic drive transformer. EE13 5+5 pin vertical frame. Coil former Size=13.3mmX12.3mmX19.85mm. Parallel Distance=8.5mm.Pin pitch=2.5mm. We supply EE13 PC40 material ferrite cores. Welcome customized EE13 transformer. Used in UPS, switching mode power supply, telecom communication systems, welding machines and other industries. -
EF16 Flyback Transformer SUS-301 Iron ClipsSupply power charge transformer. EF16 ferrite core transformer mounting clips. Clip Size=17.5mmX17.4mmX5.0mm. EF16 high frequency transformer widely used in SMPS, laptop, mobile phone devices, UPS, inverters, power supplies, welcome for customized wounded components. -
EE13 Vertical 5+5 Pin Coil Former For HF TransformerEE13 power inverter transformer, 5+5 pin EE13 vertical shape bobbin, Coil former Size=13.3mmX12.3mmX21.6mm. Parallel Distance=8.5±0.3mm. Pin pitch=2.5mm. We manufacture EE13 electronic transformer for lighting, UPS, computer equipment, telecom communication systems, welding machines and other industries. -
SMPS PQ32 Vertical Transformer 2+2 Pin BobbinPQ32 power charger transformer. Vertical PQ32 2+2 pin bobbin. Bobbin size=33.0mmX32.7mmX30.6mm. Pin pitch=9.2mm. Row distance=27.2mm. We are experienced IS09001 certificated factory, our main products are transformer bobbins, magnetic cores and coil products. We accept custom design and OEM service. -
High Frequency EE65 SMPS Transformer FrameHigh power transformer. EE65 8+8 pin horizontal coil former. Bobbin Size=58.4mmX49.3mmX59.0mm. Parallel Distance=45.8mm. Pin pitch=5.0mm. Good quality EE65 power transformer, singled packed with carton, accept custom made transformer. -
EE22 Switching Power Transformer Vertical BobbinEE22 soft ferrite core bobbin. 5+5 pin vertical version EE22 coil former. Bobbin Size=21.9mmX16.0mmX17.0mm. Parallel Distance=10.4mm. Pin pitch=4.0mm. We have over 10 years in producing and selling bobbins, we have many type bobbin toolings. We also manufacture final high frequency transformers for power supply. -
EE65 Switching Power Supply Transformer FrameHigh frequency EE65 transformer. No pin EE65 coil former. Bobbin Size=53.1mmX44.0mmX43.2mm. We have diferent size bobbin toolings, welcome custom made transformer and inductor. -
EE55 Horizontal High Frequency Transformator Frame 7+7 PinsEE55 MP4 core bobbin, horizontal EE55/25 transformer frame 7+7 pns. Bobbin Size=50.0mmX38.0mmX48.5mm. Parallel Distance=42.0mm. Pin pitch=5.5mm. Weclome customzied electronic transformers and indcutors for power supplies. -
Horizontal EE55 Transformer Bobbin With 7+7 PinsEE55 inverter transformer bobbin. 7+7 pin Horizontal EE55 bobbin. Bobbin Size=43.3mmX42.6mmX36.8mm. Parallel Distance=39.4mm. Pin pitch=5mm. China transformer manufacturer.
