Horizontal encapsulated common mode choke has excellent frequency characteristics and attenuation characteristics. The selection meets safety specifications. Low leakage flux (magnetic loss). The series inductance range: 10uH-1mH above (differential mode)
brand:
MCTitem no.:
MCT Case Potting H10C Series Common Mode Choke Standard Windingshipping port:
ShanghaiOur encapsulated mode choke coils mainly used in electronic devices EMI radiated noise suppression, PC USB interface cable for PC and peripheral, 1394 lines, DVC, set-top boxes, LCD panels, low-voltage differential signaling (LVDS). All common mode chokes accept custom design. The materials we used are ROHS and REACH compliant.
Quick Details
Part Number: MCT Case Potting H10CSeries Common Mode Choke |
|
Brand name: MCT |
Type: Choke Inductor |
|
Custom made: Available |
Testing frequency: 1KHz/0.25V |
|
Logo: Can be customized |
Operating temperature:-40°C~+105°C. |
|
Shipping: Air, Ship, etc |
Certification: ISO9001,ROHS,CE |
|
MOQ: Any quantity |
Lead time: 25 days after payment |
|
OEM: Available |
Part Information
Product Name: Encapsulated Toroidal Common Mode Choke Coils for RFI Suppression Choke
Applications: Low Frequency AC Reactor. PC USB interface cable. Solar Power System. LCD panels. Power Conditioning System. Wind Power System. Automatic Drive Machine. RFI Suppression Choke
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Product Specification
Typical electrical parameter
MCT Part No. |
Inductance(mH) min |
DC Resistance(Ω)max |
Rated Current(A) |
MCTH10C151A03 |
15.0 |
1.00 |
0.3 |
MCTH10C101A05 |
10.0 |
0.50 |
0.5 |
MCTH10C680A06 |
6.80 |
0.35 |
0.6 |
MCTH10C390A08 |
3.90 |
0.20 |
0.8 |
MCTH10C270A10 |
2.70 |
0.12 |
1.0 |
MCTH10C100A15 |
1.00 |
0.06 |
1.5 |
MCTH10C060A20 |
0.68 |
0.04 |
2.0 |
Welcome customized, we can design for you.
If you have any requests, please contact us, we will give you fast reply
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
Encapsulated common mode Chokes. MCT Case Potting Series Common Mode Choke Standard Winding. Compact and light weight. Testing frequency:1KHz/0.25V. Operating temperature:-40°C~+105°C
Encapsulated common mode choke is excellent EMI suppressor. It has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.
Vertical encapsulated common mode choke has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.It is excellent EMI suppressor.
Encapsulated vertical common mode choke mainly for RFI suppression, high frequency EMI suppresionhas. It has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.
Encapsulated common mode inductor mainly used in electronic devices EMI radiated noise suppression, PC USB interface cable for PC and peripheral, 1394 lines, DVC, set-top boxes, LCD panels, low-voltage differential signaling (LVDS).
Encapsulated common mode choke coils has excellent frequency characteristics and attenuation characteristics. Widely used in computers. Switches DVD/VCD color TV telephone DC-DC modules UPS uninterruptible power supply. Other electrical devices.
Encapsulated common mode choke coil filters, has high current, low temperature rise, low power consumption. Mainly used in electronic devices EMI radiated noise suppression, PC USB interface cable for PC and peripheral, 1394 lines, DVC, set-top boxes, LCD panels, low-voltage differential signaling (LVDS).
Toroidal encapsulated common mode choke has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor. It's an excellent EMI suppressor.
Encapsulated common mode chokes. Testing frequency:1KHz/0.25V. Operating temperature: -40°C~+105°C. Mainly used in power system, LCD panels, DC converters, RFI suppression. It has large current, high frequency and low power loss.
Customized encapsulated common mode chokes. Testing frequency:1KHz/0.25V. Operating temperature: -40°C~+105°C. Mainly used in power system, LCD panels, DC converters, RFI suppression. It has large current, high frequency and low power loss.
EFD25 iron bobbin clip. Magnetic high frequency bobbin. Clip size=23.6mmX8.0mmX5.5mm. We produce various bobbins, we make new tooling to meet special size requirements. EFD25 electronnic transformer widely used for PCB circuits, UPS, computers, switching power supplies,TVs, monitor, scanner and other electronics.
ER40 vertical transformer bobbin. 8+8 pins bobbin. Bobbin Size=40mmX31mmX41.8mm. ER40 phenolic bobbin. Parallel Distance=25mm. Pin Pitch=5.0mm. UL REC:94V-0
