Encapsulated common mode inductor mainly used in electronic devices EMI radiated noise suppression, PC USB interface cable for PC and peripheral, 1394 lines, DVC, set-top boxes, LCD panels, low-voltage differential signaling (LVDS).
brand:
MCTitem no.:
MCT Case Potting H22C Series Common Mode Choke Standard Windingshipping port:
ShanghaiHigh quality and factory price common mode choke, drum core inductor, rod core inductor, large current inductor, air coil inductor, three/four phase common mode choke, dimmer choke for EMI suppression, etc.
Quick Details
Part Number: MCT Case Potting H22C Series Common Mode Choke |
|
Brand name: MCT |
Type: Choke Inductor |
|
Custom made: Available |
Testing frequency: 1KHz/0.25V |
|
Logo: Can be customized |
Operating temperature:-40°C~+105°C. |
|
Shipping: Air, Ship, etc |
Certification: ISO9001,ROHS,CE |
|
MOQ: Any quantity |
Lead time: 25 days after payment |
|
OEM: Available |
Part Information
Product Name: Encapsulated Common Mode Chokes High Frequency Toroidal Inductor
Applications: Low Frequency AC Reactor. PC USB interface cable. Solar Power System. LCD panels. Power Conditioning System. Wind Power System. Automatic Drive Machine. RFI Suppression Choke
Packing Details: PP packing belt + Outer packing hard paper carton + inner packing pearl cotton or plastic tray
Samples time: 7-10 days for customized parts, 3-5 days for standard parts.
Product Specification
Typical electrical parameter
MCT Part No. |
Inductance(mH) min |
DC Resistance(Ω)max |
Rated Current(A) |
MCTH22C331A10 |
33.0 |
0.50 |
1.0 |
MCTH22C251A12 |
25.0 |
0.35 |
1.2 |
MCTH22C151A15 |
15.0 |
0.20 |
1.5 |
MCTH22C101A18 |
10.0 |
0.15 |
1.8 |
MCTH22C680A23 |
6.80 |
0.12 |
2.3 |
MCTH22C390A30 |
3.90 |
0.06 |
3.0 |
MCTH22C220A40 |
2.20 |
0.03 |
4.0 |
MCTH22C100A60 |
1.00 |
0.015 |
6.0 |
MCTH22C050A80 |
0.56 |
0.01 |
8.0 |
MCTH22C030AA0 |
0.33 |
0.007 |
10.0 |
We can decign it. If you have any requests, please contact us, we will give you fast reply
Email: sales003@mycoiltech.com
Skype: sales003_125
Contact: Miss Lily Yu
Encapsulated common mode Chokes. MCT Case Potting Series Common Mode Choke Standard Winding. Compact and light weight. Testing frequency:1KHz/0.25V. Operating temperature:-40°C~+105°C
Encapsulated common mode choke is excellent EMI suppressor. It has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.
Vertical encapsulated common mode choke has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.It is excellent EMI suppressor.
Horizontal encapsulated common mode choke has excellent frequency characteristics and attenuation characteristics. The selection meets safety specifications. Low leakage flux (magnetic loss). The series inductance range: 10uH-1mH above (differential mode)
Encapsulated vertical common mode choke mainly for RFI suppression, high frequency EMI suppresionhas. It has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor.
Encapsulated common mode choke coils has excellent frequency characteristics and attenuation characteristics. Widely used in computers. Switches DVD/VCD color TV telephone DC-DC modules UPS uninterruptible power supply. Other electrical devices.
Encapsulated common mode choke coil filters, has high current, low temperature rise, low power consumption. Mainly used in electronic devices EMI radiated noise suppression, PC USB interface cable for PC and peripheral, 1394 lines, DVC, set-top boxes, LCD panels, low-voltage differential signaling (LVDS).
Toroidal encapsulated common mode choke has small profile, large current, low resistance, high frequency and low loss, common mode filter and toroidal inductor. It's an excellent EMI suppressor.
Encapsulated common mode chokes. Testing frequency:1KHz/0.25V. Operating temperature: -40°C~+105°C. Mainly used in power system, LCD panels, DC converters, RFI suppression. It has large current, high frequency and low power loss.
Customized encapsulated common mode chokes. Testing frequency:1KHz/0.25V. Operating temperature: -40°C~+105°C. Mainly used in power system, LCD panels, DC converters, RFI suppression. It has large current, high frequency and low power loss.
3+3 Pins Dip Base,LCP Material,UL REC:94V-0 Pin Pitch=3.52mm Parallel Distance=3.52mm Inductor base size=9.06mmX6.04mmX4.83mm
5+5 Pins Horizontal Bobbin,Phenolic Material,UL REC:94V-0 Pin Pitch=2.8mm Parallel Distance=14.5mm Size=19.8mmX16.6mmX14.5mm
