High Voltage EE19 Transformer Horizontal BobbinEE19 power transformer bobbin. 4+4 pin horizontal coil former. Parallel distance=12.9mm. Pin Pitch=3.8mm. Bobbin Size=19.0mmX17.0mmX15.6mm. Nylon material transformer bobbin. -
PCB Mounting Encapsulated Transformer BobbinCustom transformer EE19. Horizontal 5+5 pin bobbin. Bobbin Size=19.0mmX17.0mmX14.8mm. Parallel distance=12.6mm. Pin Pitch=5.0mm. Nylon material transformer bobbin. -
EE65 Ferrite Core Transformer Bobbin No PinEE65 power transformer for DC converter. No pin large bobbin EE65. Bobbin Size=51.7mmX43.7mmX49.5mm. We can make bobbin tooling. PA66 material EE65 transformer bobbin. -
EE42 Power High Frequency Horizontal BobbinEE42 switching transformer. 6+6 pins horizontal EE42 coil bobbin. Bobbin Size=46.20mmX41.50mmX42.20mm. Parallel distance=37.55mm. Pin pitch1=7.62mm. Pin pitch2=5.08mm. We can make bobbin tooling. Phenolic material EE42 transformer bobbin. -
Switch Mode High Frequency Transformer SMD BobbinSMD EFD15 transformer bobbin. Horizontal bobbin pin 6+6 with single section. Pin Pitch=2.5mm. Parallel distance=15.0mm. Bobbin Size=21.3mmX17.0mmX7.4mm. EFD15 transformer bobbin made of PM9630 material. -
EF30 Power Transformer Vertical Bobbin 6+6 PinEF30 rectifier transformer. 6+6 pins vertical EF30 coil former. Bobbin Size=35.3mmX19.0mmX34.8mm. Pin pitch=5.08mm. Parallel Distance=15.24mm. SMPS transformer has small size, high power and low cost, we design and manufacture high frequency transformer. -
EEL19 Multi Section Transformer Bobbin Black CoverEEL19 bobbin case for transformer. LCP-E4008 material transformer cover, low cost and high quality. Case size=31.6mmX21.3mmX8.0mm. We use plastic tray to pack EEL19 bobbin. We can make tooling. UL REC:94V-0 -
EE42 Horizontal Transformer Bobbin Pin 8+8Horizontal plastic transformer bobbin. EE42 horizontal coil former. Bobbin Size=42.0mmX41.8mmX41.2mm. Parallel distance=37.0mm. Pin pitch=5.0mm. We can make bobbin tooling. PBT material bobbin. -
SMD EFD15 High Frequency Power TransformerSMD EFD15 driver transformer. 5+5 pins horizontal EFD15 horizontal bobbin. Pin Pitch=2.5mm. Parallel distance=15.0mm. Bobbin Size=21.55mmX14.9mmX7.25mm. EFD15 transformer bobbin made of PM9630 material. -
ETD54 PCB Circuit Transformer Ferrite Core BobbinETD54 two slots coil former. Horizontal transformer ETD54 bobbin 8+11 pins. Bobbin Size=60.8mmX60.8mmX50.0mm. Pin distance=5.08mm. Parallel Distance=45.72mm. Lead free transformer bobbin. DIP bobbin. -
SMPS Transformer ETD54 Horizontal BobbinETD54 power transformer with wide range, stable performance and low temperature rise. 11+11 pins horizontal ETD54 bobbin. Bobbin Size=61.5mmX61.2mmX44.8mm. Pin distance=5.08mm. Parallel Distance=45.9mm. DIP bobbin. -
High Frequency Transformer ETD59 Ferrite Core Bobbin9+13 pins horizontal ETD59 bobbin. Multi section coil former. Parallel Distance=51.4mm. Pin Pitch=5.08mm. Bobbin Size=66.8mmX66.2mmX48.95mm. PET material transformer bobbin. UL REC:94V-0 -
ETD59 Horizontal 12+12 Pin Flyback TransformerETD59 horizontal power transformer. 12+12 pin coil former ETD59. Parallel Distance=50.8mm. Pin Pitch=5.0mm. Bobbin Size=66.7mmX65.5mmX48.60mm. PET material transformer bobbin. UL REC:94V-0 -
EI33 SMPS Transformer Vertical BobbinEE33 coil former 7+7pin. Vertical EE33 transformer bobbin. Bobbin Size=33.8mmX27.5mmX27.2mm. Pin Pitch=5.0mm. Parallel distance=22.5mm. DIP transformer phenolic material bobbin. -
PCB Mounting Transformer EE30 Vertical BobbinPower supply EE30 transformer. Vertical EE30 coil former pin 5+5. Bobbin Size=25.9mmX21.8mmX23.9mm. Pin pitch=5.0mm. Parallel Distance=17.5mm. Low voltage and low frequency EE30 electronic winding transformer. -
5Ω RF Balun Transformer For Surface MountingManufacture RF balun transformer, available in various size, Our base pins are terminal treated,with low profile SMD balun coil. We make balun transformer for broadband transmission devices, impedance transmission. -
Vertical PQ35 Bobbin For PCB Mounted TransformerSMPS flyback transformer. PQ35 6+6 pins coil bobbin. Bobbin Size=34.0mmX32.0mmX31.5mm. Parallel Distance=22.8mm. Pin Pitch1=5.0mm. Pin Pitch2=7.5mm. PQ35 transformer has large transmission power and stable performance. -
High Voltage Transformer PQ35 Coil FormerElectrical transformer bobbin. Vertical type PQ35 bobbin 6+6 pins. Bobbin Size=39.6mmX35.0mmX24.26mm. Parallel Distance=36.4mm. Pin Pitch=5.0mm. PQ35 transformer has large transmission power and stable performance. -
EF20 High Frequency Flyback Transformer Vertical BobbinEF20 flyback transformer with 5+5 pins. Vertical type EF20 single slot coil former for electronic transformer. Bobbin made of phenolic material. We accept custom design EF20 transformer. -
PQ35 Power Transformer Bobbin Iron ClipsPCB mounting transformer manufacture. Clips for ferrite core. Electronic power transformer PQ35 bobbin. Transformer clips Material:C5191R-H-0.5T. Clip Size=50.0mmX37.20mmX13.1mm. -
EF12.6 Horizontal High Power Transformer BobbinEF12.6 high frequency current transformer for amplifier and electronics. 5+5 pins horizontal coil former. Bobbin Size=12.8mmX11.7mmX8.3mm. Pin pitch=5.0mm. Parallel Distance=10.0mm. We can make new tooling to meet special size. Use export standard carton with strong pallet to package. -
EF20 Case For Power Charge Transformer BobbinSwitching power transformer manufacture. EF20 coil former case. Case Size=16.0mmX14.0mmX3.0mm. EF20 bobbin and matched case are made of PM9820 material. We have bobbin tooling to meet customer's requirements. -
EP20 LED Drive Transformer Bobbin With Double SlotsEP20 ferrite core bobbin. Two slots 2+2 pins coil former. Phenolic material bobbin. Size=21.5mmX21.0mmX16.9mm. Parallel Distance=12.1mm. We manufacture EP20 electronic transformers, mainly for LCD televisions and monitor, medical equipment, computer devices, UPS, communication equipment, custom design also available. -
PQ32 Magnetic Core Transformer 6+6 Pins BobbinFlyback transformer manufacturer. 12 pins PQ32 vertical coil former. Bobbin Size=34.0mmX32.0mmX30.7mm. Parallel Distance=30.0mm. Pin pitch=5.0mm. PQ series electronic transformers have low leakage inductance and wide operating frequency range. -
PQ32 LED Driver Transformer Vertical 12 Pins BobbinFilter transformer PQ32 bobbin. Vertical PQ3230 6+6 pin coil former. Bobbin Size=34.0mmX32.0mmX29.0mm. Parallel Distance=30.5mm. Pin pitch=5.08mm. PQ series electronic transformers have low leakage inductance and wide operating frequency range. -
EF25 Power Charger Transformer Horizontal BobbinEF25 SMPS transformer. 5+5 pin horizontal bobbin EF25. Bobbin Size=24.0mmX23.8mmX21.5mm. Pin pitch=2.5mm. Parallel Distance=20.5mm. PC40 material EF25 ferrite core. DIP type transformer bobbin. -
PM50 Precision transformer Vertical Bobbin 7+7 PinsCustomized PM50 power transformer. Single slot vertical bobbin with 7+7 pins. Bobbin size=50.7mmX23.2mmX35.9mm. Pin pitch=5.0mm. Pin distance=45.7mm. We have many bobbin tooling and we can make final transformer for customers. -
Toroidal Choke Coil 3+3 Pins SMD CaseCoil inductor with case for PCB mounting. Supply customized transformer and inductor for customer. SMD case pin 3+3 with WH-9100F material. When transformer assembled by bobbin and magnet cores, we use case to cover the transformer. -
Choke Copper Coil Inductor SMD Base 3+3 PinsInductor base for circuit board. we manufacture various transformer and inductor for customer. WH-8100 material inductor SMD case with 3+3 pins. When transformer assembled by bobbin and magnet cores, we use case to cover the transformer. -
Power Transformer Bobbin SMD CaseElectronic transformer case. We manufacture and design high frequency transformer for customers. WH-8100 material filter SMD case with 3+3 pins. When transformer assembled by bobbin and magnet cores, we use case to cover the transformer.
